MAIN MENU
Press the button to display the main menu.
CAMERA SELECT
RECORD SELECT
RECORD MODE
RECORD FRAMERATE
VIDEO QUALITY
RECORD SCHEDULE
=SUB MENU=
HARD DRIVE SETUP
SENSOR SETUP
NETWORK SETUP
PRESS﹝∧,∨﹞THEN﹝SELECT﹞
PRESS ﹝MENU﹞TO EXIT
Use the ▼ and ▲ buttons to move the cursor up and down.
Press to enter the selected sub-menu.
Use the ▼ and ▲ buttons to position the cursor.
Press to cycle through until reaching the desired option.
Press to make the selection and return to the main directory.
Press to return to real time display.
Operation Guide: CAMERA SELECT
Used to select and display (on the menu bar) the number of cameras connected to the
DVR.
The Video Loss buzzer is enabled if a camera is selected in this menu but there is no
video signal presenting on that channel.
Use the to cycle through the options, some examples are shown below:
(1 2 3 4)：Cameras 1, 2, 3 and 4 have been selected.
(12--)：Cameras 1 and 2 have been selected.
(-2 3-)：Cameras 2 and 3 have been selected.
(----)： No cameras have been selected.
1234
1234
EACH
30
HIGH
