Quick Start Guide
General Information
Read the instructions before commencing installation. The user is to retain the instructions for future reference.
•
Espire Alarms have been designed and developed for fixed residential installation and use.
•
After installation the Alarm is to be tested weekly: Press and hold the Test/ Hush button for at least 10 seconds to ensure the Alarm sounds and all
interconnected Alarms activate.
Product Description
•
ES1SL Optical Smoke Alarm Powered by a Sealed 10 Year Lithium Battery
•
ES1HL Heat Alarm Powered by a Sealed 10 Year Lithium Battery
•
ES1MUL Optical Smoke and Heat Multi-Sensor Alarm Powered by a Sealed 10 Year
Lithium Battery
The Alarm head must be fitted onto the supplied Lock-In Base.
The RF-Link (ES1RF2) module is supplied with the Alarm or available separately.
The Alarm battery is sealed and non-replaceable.
Alarm Installation
Step 1.
Using the base, mark the desired mounting
holes, drill and re-align the base, screwing into
place. Multiple mounting holes are available for
retro fit installations.
Alarm Testing
Test the Alarm after installation, and
weekly thereafter.
Alarm Powered by a Sealed 10 Year Lithium
Step 2.
Carefully line up the Alarm to the base and slide
on until secured and a 'click' is heard.
Step 1.
Press and hold the Test/Hush button for a
minimum of 10 seconds.
Battery with Optional RF-Link Module
ES1SL, ES1HL, ES1MUL
Red Alarm LED
Step 2.
The Alarm will sound and the Red LED will flash.
Amber
Fault LED
Test/Hush
Button
Sounder
1
Advertisement
Related Manuals for ESP espire ES1SL
Summary of Contents for ESP espire ES1SL
- Page 1 Alarm Powered by a Sealed 10 Year Lithium Battery with Optional RF-Link Module ES1SL, ES1HL, ES1MUL Quick Start Guide General Information Read the instructions before commencing installation. The user is to retain the instructions for future reference. • Espire Alarms have been designed and developed for fixed residential installation and use. •...
- Page 2 RF-Link Introduction Up to 28 Alarms can be interconnected wirelessly via the RF-Link function .Ensure RF Status LED Normal Status: RF Status LED; the Alarms have been fitted with the RF-Link Red Flashing: LED Off Green Flashing: MASTER Alarm Primary module.
- Page 3 Alternative RF-Link System Setup • Hybrid System; Systems that incorporate hardwired and RF-Link Alarms, consult the RF-Link module manual (ES1RF2) for limitations and further guidance. • Remote Control System; Systems that incorporate the Espire Remote Control, consult the Remote Control manual (ES1REM), for limitations and further guidance.
- Page 4 Memory Mode Green LED Amber LED Red LED Sounder Description (i) The Red LED flashes twice every 40 seconds to indicate the Alarm has stored an activation in the memory. (ii) Memory function assists identification of Alarms that have been activated. (iii) The memory will automatically clear after 24 hours of the activation or press and hold the ‘Test/ 2 x 40 sec Hush’...
