Operation Guide: RECORD SELECT
Used to select the cameras whose video inputs will be recorded on the HDD. Desired
cameras must be pre-selected in the "Camera Menu" in order to perform recording properly.
Use
to cycle through the options.
Press
to make the selection and return to the main directory.
NOTE: Desired channels cannot be recorded properly if the corresponding cameras are not
pre-selected in the "Camera Menu."
Operation Guide: RECORD MODE
Can be set to either "EACH" or "QUAD". When set to "EACH" all selected cameras (in the
Record Select menu) are recording on the HDD in full screen. When set to "QUAD" all
selected cameras (in the Record Select menu) are recorded on the HDD as a quad screen
image.
Use
to cycle through the options.
Press
to make the selection and return to the main directory.
Operation Guide: RECORD FRAME RATE
The default value is 30 fps for NTSC and 25 fps for PAL. There are a number of different
frame rate settings:
NTSC: 30fps, 15fps, 10fps, 7fps, 5fps, 4fps, 3fps, 2fps, 1fps
PAL: 25fps, 12fps, 8fps, 6fps, 4fps, 3fps, 2fps, 1fps
Higher frame rate makes the video stream look more real when it's played back but will use
the greatest amount of HDD storage.
The frame rate is divided by the number of cameras selected in the Record Select menu, for
example:
If the frame rate is set to 25fps (PAL) and four cameras have been selected then each
camera will be recorded at 6.25fps.
Use
to cycle through the options.
Press
to make the selection and return to the main directory.
Operation Guide: VIDEO QUALITY
There are three options for video quality, HIGH, NORMAL and LOW. Higher video quality
makes video more clear and real.
Use
to cycle through the options.
Press
to make the selection and return to the main directory.
