Operation Guide: SCHEDULE RECORD
MAIN MENU
CAMERA SELECT
RECORD SELECT
RECORD MODE
RECORD FRAMERATE 30
VIDEO QUALITY
RECORD SCHEDULE
SUB MENU
HARD DRIVE SETUP
SENSOR SETUP
Use ▼ and ▲ buttons o position the cursor at each hourly interval.
Press button to choose one of the three settings.
Press to return to the main menu.
SETTING EXAMPLE:
0:00 ~ 7:00 SENSOR RECORDING
7:00 ~11:00 RECORDING DISABLED
11:00 ~18:00 RECORDING
18:00 ~24:00 SENSOR RECORDING
+ S S S S S S - - - - T T T T T T T S S S S S S +
: : :
0 6 11
NOTE
NOTICE : AUTO RECORD
In PC LINK mode the Auto Record Function is disabled. Recording will start again
automatically 55 seconds after the USB cable is disconnected.
Select this option to change a
1234
recording schedule during a day
1234
(24-hour period)
田
HI
Numbers below indicate the time duration
in 24 hour format.
(T) 24-hour recording.
(S) Motion recording.
The DVR only starts recording when an
event (motion or GPIO) is triggered.
:
18
SENSOR RECORDING INSTALLATION (MOTION)
The DVR has 4 alarm inputs that can be configured as
normally closed, normally open, motion detection +NC and
motion detection +NO on the "SENSOR SETUP" menu.
:
