Solectria Renewables PVI 3000S Installation And Operation Manual

Residential/commercial grid-tied photovoltaic inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PVI 3000S
PVI 4000S
PVI 5000S
PVI 5300
INSTALLATION AND OPERATION MANUAL
Revision A
Residential/Commercial
Grid-Tied Photovoltaic Inverter
© 2012, Solectria Renewables LLC
All information subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PVI 3000S and is the answer not in the manual?

Questions and answers

Related Manuals for Solectria Renewables PVI 3000S

Summary of Contents for Solectria Renewables PVI 3000S

  • Page 1 PVI 3000S PVI 4000S PVI 5000S PVI 5300 INSTALLATION AND OPERATION MANUAL Revision A Residential/Commercial Grid-Tied Photovoltaic Inverter © 2012, Solectria Renewables LLC All information subject to change without notice.

  • Page 2: Warranty Information

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters IMPORTANT REGISTRATION AND WARRANTY INFORMATION For warranty to become active, this inverter must be registered. To activate warranty and register inverter, please visit the link below. www.solren.com/registration Installation and Operation Manual (Rev A)

  • Page 3: Important Safety Instructions

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters IMPORTANT SAFETY INSTRUCTIONS In this manual “inverter” or “inverters” refers to the inverter models: PVI 3000S, PVI 4000S, PVI 5000S, and PVI 5300 unless one of the specific models is noted. This manual contains important instructions that shall be followed during installation and maintenance of the PVI inverter.
  • Page 4 • Le PVI 3000S, PVI 4000S, PVI 5000S, et PVI 5300 ne contient aucune pièce requérant un entretient effectué par l‘utilisateur. Pour toute maintenance, veuillez consulter Solectria Renewables ou un installateur agrée par Solectria Renewables (les coordonnées de Solectria Renewables et des installateurs agrées sont indiquées sur...

  • Page 5: Table Of Contents

    Input DC (PV) Specifications ......................61 Output AC Specifications ......................62 General Specifications ......................... 62 10.0 Appendices ............................64 10.1 Appendix A – PVI 3000S, PVI 4000S, PVI 5000S, PVI 5300 Data Sheet ........64 Installation and Operation Manual (Rev A)
  • Page 6 10.6 Appendix F – Weatherproof Shield for Wind-Driven Snow and Rain ......... 67 10.7 Appendix G – PVI 3000S-5300 PV Inverter Fault Report Form ........... 68 10.8 Appendix H – UL1741 / IEEE 1547 / CSA22.2#107.1 Listing Letter ..........69...

  • Page 7: Introduction

    PV inverters designed to be inter-connected to the electric utility grid. With this manual the PVI 3000S, PVI 4000S, PVI 5000S, and PVI 5300 can be installed and operated safely. This installation guide is used as reference for commissioning and as a guideline on how to use the inverter most effectively.
  • Page 8 600V DC maximum system voltage for the power levels of the PVI 3000S, PVI 4000S, PVI 5000S and PVI 5300 for use with 1kW to 7kW PV arrays per inverter. Data acquisition, display and communication The integrated data acquisition, display and communication capability of the PVI 3000S - PVI 5300 allows comprehensive tracking of data for understanding of system performance.
  • Page 9 PVI 3000S - PVI 5300. The maximum power processed from the PV array is automatically reduced to limit excessive inverter temperature. The PVI 3000S - PVI 5300 will only operate in parallel with the utility grid. AC grid monitoring is done by microcontrollers configured to meet the requirements of UL1741/IEEE1547. The inverter shuts down immediately if the grid goes down, or if the grid gives surges, sags, changes frequency or otherwise shows signs of instability.
  • Page 10 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Fig. 1.2 Features of the PVI 3000S/4000S/5000S/5300 (1) AC knockouts (bottom, side, and back) (2) PV array ground fault interrupt (GFDI) fuse (3) DC/AC disconnect (4) DC knockouts (bottom, side, and back) (5) Fan assembly (on back at bottom of heatsink, used on PVI...

  • Page 11: Site Preparation And Inverter Placement

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters 2.0 Site Preparation and Inverter Placement The inverter is comprised of a rainproof NEMA 3R industrial enclosure containing electrical and electronic components. NOTE: If the inverter is mounted outside, during the installation process and in case of rain, do not open the inverter.
  • Page 12 PVI 3000S, 4000S, 5000S, 5300 Series Inverters CAUTION: Please follow these guidelines: • The inverters weigh up to 60 lbs (27.2 kg) depending on inverter model. Be sure to use a mounting method that will safely hold this weight. Refer to Table 9.3.1 for specific weights for each inverter model.

  • Page 13: Inverter Positioning And Mounting

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters Inverter Positioning and Mounting Correct mounting position for the inverter is vertical with back of inverter mounted to a wall. Figure 2.1.1 – PVI 3000S-4000S Dimensional Diagram Figure 2.1.2 – PVI 5000S-5300 Dimensional Diagram...
  • Page 14 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Figure 2.1.3 – Inverter clearances WARNING: Severe injury or death could occur if the inverter mounting fails and the unit tips over or falls on a person. NOTE: The weight of the inverter will exert an added load to the wall where mounted.

  • Page 15: Installation

    Please inspect the inverter thoroughly after it is delivered. If any damage is seen please immediately notify the shipping company to make a claim. If there is any question about potential shipping damage, contact Solectria Renewables, LLC. Photos of the damage may be helpful in documenting potential shipping damage.

  • Page 16: Removing Inverter From Cardboard Box And Moving Inverter Into Place

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters Removing Inverter from Cardboard Box and Moving Inverter Into Place WARNING: The inverter may tip over if improperly moved, potentially causing damage to equipment, personal injury or death. After taking the inverter out of the cardboard box, you will find the mounting bracket in the bag behind the heatsink.
  • Page 17 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Figure 3.2.2 – The Mounting Bracket with dimensions Use the mounting bracket as a template to mark the locations on the wall where holes should be drilled. After drilling the holes, the mounting bracket should be fastened to the wall with screws or screw-anchors.
  • Page 18 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Once the mounting bracket is fastened to the wall, then the inverter and the wiring box can be hooked onto the mounting bracket and slipped down into place. Make sure the lower lip on the bracket hooks into the window on the back of the inverter as shown in Figure 3.2.4.
  • Page 19 PVI 3000S, 4000S, 5000S, 5300 Series Inverters After the inverter is hooked properly on the bracket, secure it with screws at the bottom flange as shown in Figure 3.2.5. Figure 3.2.5 – Fasten the Inverter with the screws at the bottom flange...

  • Page 20: Dc Connections From The Pv Array And Ac Connections To The Electrical Utility Grid

    AC and DC (PV) Connections: The PVI 3000S-5300 inverters are equipped with covered holes and knockouts to fit conduit fittings that are NEC code-compliant for use with several sizes of rigid and flexible metallic or non- metallic conduit. All conduit and wiring installation is done in the wiring box. This design allows installation and wiring of the inverter to be done without opening the main inverter enclosure which should not be opened during installation.
  • Page 21 The PVI 3000S-5300 are grid connected devices, suitable for both 240V AC and 208V AC grid- connected use. For example, connection to 2 phase legs of a 208V AC, 3-phase service (where acceptable by code). No unit (PVI 3000S, 4000S, 5000S, or 5300) can be used with just a 120V AC connection.

  • Page 22: Connecting The Inverter Wiring

    A dedicated AC circuit breaker in the home or building circuit panel is required for the PV inverter. Every PVI requires a 208/240V AC rated 2–pole circuit breaker. The following is a table showing the appropriate circuit breaker for the PVI 3000S, 4000S, 5000S, and 5300 (based on number of Amps).
  • Page 23 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Figure 4.1.1 – Turn the DC/AC Disconnect Switch off Figure 4.1.2 – Remove the 4 Screws on the Wiring Box and Remove the Cover Installation and Operation Manual (Rev A)
  • Page 24 4 PV strings that will parallel connected in the wiring box (3 strings for the PVI 3000S), or the fuse bypass terminal can be used if the fused combiner feature is not needed. The RJ-45 connectors are used for external communication to a remote computer or communication gateway.
  • Page 25 The utility configuration jumpers, J210, are located on the control board as shown in Figure 4.1.5 are used to set the PVI 3000S-5300 inverter to be connected to the commonly used utility configuration types shown in Figure 4.1.6. As shown in Figure 4.1.5, the P1 and P2 pins are used to configure the PVI 3000S-5300 inverter for the connection types of 208V and 240V AC outputs with or without neutral.
  • Page 26 PVI 3000S, 4000S, 5000S, 5300 Series Inverters J210 Figure 4.1.5 – Building/Utility Configuration Jumpers Installation and Operation Manual (Rev A)

  • Page 27: Ac Wiring

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters Figure 4.1.6 –Utility Configurations AC Wiring WARNING: Reconfirm that the circuit breaker to the grid/utility is switched OFF before connecting the power wires from the breaker to the inverter AC terminal block. Use #10 AWG to #6 AWG, 90 °C (194 °F) copper wire for all AC wiring connections to the PVI 3000S-5300 inverters.

  • Page 28: Dc Wiring

    • Reconfirm that all connections are correct as described above and all screws are properly tightened. WARNING: Each connection to a PVI 3000S-5300 inverter must be installed with a dedicated circuit breaker. No other appliances may be connected to the circuit breaker.
  • Page 29 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Wiring inverters in parallel PVI 3000S-5300 inverters can be connected in parallel when more power is needed. In the parallel configuration, each inverter shall connect to its own PV array. Do not connect one PV array to more than one inverter.
  • Page 30 (4) independent PV strings to be fused and connected in parallel in the wiring box and then fed into the inverter (or 3 fused inputs in the case of the PVI 3000S). The PVI 3000S- 5300 inverter is shipped with up to four (4) 15A, 600Vdc PV string fuses in the wiring box for the PV strings.

  • Page 31: Connection Of Communication Wiring

    “Grounded (-)” terminal block. Connection of Communication Wiring The PVI 3000S-5300 inverter supports RS-485 which is used to communicate to the remote computer or communication gateway. As shown in Figure 4.4.1, there are two RJ-45 connectors, RJ45-R and RJ45-L that are located on the bottom of the wiring box.
  • Page 32 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Termination ON/OFF RS232 Termination RJ45-R RJ45-L Figure 4.4.1 – Position of the Communications Ports and Termination Switches Figure 4.4.2 – RJ-45 Pinouts and Signals If RS-485 interface is selected, both RJ-45 connectors will be used for the daisy-chained/cascaded RS-485 connections shown in the Figure 4.4.3.

  • Page 33: Communication Id Adjustment

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters WIH-020081 RS485 Daisy chain To gateway or computer WIH- 020082 Figure 4.4.3 – RS-485 Connection Description Part Number Typical Use Length Cable, RS485 comm. PVI 3000S- WIH-020082 RS485 cable for communication 7 ft...

  • Page 34: Turning On The Inverter

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters NOTE: Make sure all tools, parts, etc. are removed from the vicinity of the inverter before turning on. WARNING: Make a final check of all AC and DC wiring to the inverter and in the system before turning on.

  • Page 35: Lcd Display

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters into the grid. The LCD display and LED indicators on the front of the inverter provide valuable inverter operating information. LCD Display Figure 6.1.1 – LCD Display The green LED "Power" shows the current operating condition.

  • Page 36: Led Indicators

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters LED Indicators LED indicators Operating status Description Green Initialization The PVI 3000S-5300 is initializing. Yellow Green System Check The inverter is in System Check Yellow mode mode. Green Monitor mode The inverter is in Monitoring Yellow mode.

  • Page 37: Lcd Display Messages

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters LCD Display Messages The PVI 3000S-5300 inverter is supplied ready to operate so there are no settings that need to be made by the user for fully automatic operation. The device comes standard with an LCD display on which various data can be read.
  • Page 38 PVI 3000S, 4000S, 5000S, 5300 Series Inverters S / N X X X X X X X X X X X X X X X X X X X X 3 seconds ↓ Then three (3) seconds later, it displays the setting of the nominal grid voltage configuration. The grid type setting of 208/240 with neutral is used as the display example shown below.
  • Page 39 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Then three (3) seconds later, it displays the setting of the VacH which is the phase-to-phase (rms) high threshold voltage setting at which point the inverter disconnects itself from the grid when abnormally high phase-to-phase AC voltage is detected. Also, the setting of the clearing time which is the total duration of time to disconnect the output from the AC grid is displayed.
  • Page 40 PVI 3000S, 4000S, 5000S, 5300 Series Inverters V a c H L i m i t L - N X X X . X V 3 seconds ↓ Then the setting of the re-connection time will be displayed. The re-connection time is the duration of delay time for the inverter to re-connect to the grid after the fault(s) is(are) cleared.
  • Page 41 PVI 3000S, 4000S, 5000S, 5300 Series Inverters XXX seconds and then show the measured data of the DC input voltages and the existing voltage and frequency on the grid side. M o d e M o n i t o r i n...
  • Page 42 PVI 3000S, 4000S, 5000S, 5300 Series Inverters V a c X X X . X V F a c X X . X H z 3 seconds ↓ After the system enters the grid feeding mode, it will show the following information in order and repeat this until the system goes to another operating mode.
  • Page 43 PVI 3000S, 4000S, 5000S, 5300 Series Inverters The next message shows the cumulated energy in kWh and period of time in hours for the inverter delivering the power to the grid since the inverter has been power on and operated for today.
  • Page 44 PVI 3000S, 4000S, 5000S, 5300 Series Inverters M o d e D e r a t i n g P a c M o d e D e r a t i n g V a c H There are three possible warning messages that may be displayed with different failures. These messages occur in grid feeding mode.
  • Page 45 PVI 3000S, 4000S, 5000S, 5300 Series Inverters 3 seconds ↓ M o d e F a u l t e r r o r m e s s a g e 3 seconds ↓ There are several error messages that show the detailed conditions that cause the system to go into the fault mode, such as the messages shown below that show that the frequency of the AC grid is too high (H) or too low (L).
  • Page 46 PVI 3000S, 4000S, 5000S, 5300 Series Inverters The message below shows the PV DC voltage is too high…. M o d e F a u l t V p v H 3 seconds ↓ T r i p X X X . X V P r e s e n t X X X .
  • Page 47 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Solectria PVI 4000S Figure 6.3.1 – LCD Display Flow Chart Installation and Operation Manual (Rev A)

  • Page 48: Troubleshooting And Inverter Messages

    7.0 Troubleshooting and Inverter Messages Identifying and resolving faults The PVI 3000S-5300 is fitted with a self-diagnostic system, which can recognize a majority of possible faults and show these on the display. This allows the operator to rapidly identify possible problems in the solar inverter or system.
  • Page 49 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Error Description Possible Solutions Message GridNA No AC voltage is detected. Verify AC voltage disconnect on Verify AC circuit breaker is on/operational Verify and measure AC voltage present in Inverter disconnect Contact installing company or...
  • Page 50 PVI 3000S, 4000S, 5000S, 5300 Series Inverters solar array needs to be inspected Contact installing company Do not turn on the inverter until the condition is repaired Imax_AC Over current on the AC side. The inverter will continue to operate at a lower current...
  • Page 51 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Measure the AC voltage and compare to the voltage on the inverter display Contact Solectria Renewables for assistance if the range needs to be adjusted MOV Fault, High voltage protection function failed Verify MOV appearance is OK on the AC side.
  • Page 52 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Temp. Sensor Offset check for grid monitoring failed. Turn off the inverter and restart. If the error re-occurs Contact installing company or Solectria Renewables Turn off the inverter and restart. RAM Test The internal temperature sensor failed.

  • Page 53: Maintenance

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters Ibuck Over Internal converter over current Turn off the inverter and restart. If the error re-occurs Contact installing company or Solectria Renewables Converter DC/DC hardware failed. Turn off the inverter and restart. Error...
  • Page 54 PV string fuses. Figure 7.2.2 – Replacement of the PV String Fuses Factory Service Please contact Solectria Renewables customer service for documentation to remove and replace inverter section without removing the wiring box. Installation and Operation Manual (Rev A)

  • Page 55: Product Warranty & Rma Policy

    Solectria Renewables Warranty Coverage is voidable, at Solectria Renewables’ sole option, if full payment for products and associated shipping charges are not received in full and in a timely manner by Solectria Renewables. Please contact Solectria Renewables Customer Service for further details on other products.
  • Page 56 Limited Warranty. Solectria Renewables will, at its sole option, use new and / or reconditioned parts in performing warranty repair and/or replacements. Solectria Renewables reserves the right to use parts or products of original or improved design in the repair or replacement of the product.
  • Page 57 Solectria Renewables Limited Warranties do not cover normal wear and tear of the product or costs related to the removal, installation, or troubleshooting of the customer's electrical systems. These warranties do not apply to and Solectria Renewables will not be responsible for any defect in or damage to:...
  • Page 58 The product, if its original identification (trademark, serial number) markings have been defaced, altered, or removed; The product, if it has been damaged in shipping (unless approved in writing by Solectria Renewables); Any installation and operation beyond the scope covered by relevant safety regulations (UL1741, NFPA 70, etc.);...

  • Page 59: Return Material Authorization Policy

    Please refer to your product user manual for limitations on uses of the product. Specifically, please note that Solectria Renewables’ products are not intended for use in connection with life support systems and Solectria Renewables makes no warranty or representation in connection with any use of the product for such purposes.
  • Page 60 A contact telephone number where you can be reached during work hours. d. A brief description of the problem. Ship the unit prepaid to the address provided by your Solectria Renewables’ customer service representative. Returning a product from outside of the USA or Canada: In addition to the above, you MUST include return freight funds and are fully responsible for all documents, duties, tariffs, and deposits.

  • Page 61: Technical Data

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters 9.0 Technical Data Input (DC) from PV array: • Maximum open circuit voltage of PV array is 600V DC WARNING: NEC 690-7 must be followed to calculate the maximum number of PV modules allowed for a maximum inverter open circuit voltage (OCV) of 600V DC in extreme cold temperatures for the installation location.

  • Page 62: Output Ac Specifications

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters Output AC Specifications The PVI 3000S-5300 is designed to feed power into a standard 60Hz, 240 or 208V AC utility service or 208V AC provided within a facility by a step down transformer (for example, from 480V AC service).
  • Page 63 PVI 3000S, 4000S, 5000S, 5300 Series Inverters Figure 9.3.2 – DC Voltage and AC Output 7~8 digit: Produce month (MM) 6~7 digit: year (YY) Table 9.3.3 – Serial Number Key Installation and Operation Manual (Rev A)

  • Page 64: Appendices

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters 10.0 Appendices 10.1 Appendix A – PVI 3000S, PVI 4000S, PVI 5000S, PVI 5300 Data Sheet http://www.solren.com/downloads/PVI3000-7500_datasheet.pdf 10.2 Appendix B – String Sizing Tool http://www.solren.com/stringSizing.html 10.3 Appendix C – Contact Information Solectria Renewables LLC...
  • Page 65 “Ungrounded (-)“ and the right terminal block must be labeled “Grounded (+)”. Optional: add “Warning, Positively Grounded Unit” label to outside of unit at bottom right corner of wiring box. (a label kit is available from Solectria if requested). • Tighten the set screws to a torque of 1.7Nm (15.6 in-lb.))
  • Page 66 PVI 3000S, 4000S, 5000S, 5300 Series Inverters JP15 JP14 Red wire connected to DCIN- Black wire connected to DCIN+ Figure 10.5.1 – Positive Ground Setting and DC Wire Connections connect to PV+ UNGROUNDED GROUNDED CONDUCTOR CONDUCTOR Figure 10.5.2 – DC Wiring to Terminal Blocks for Positive Ground...

  • Page 67: Appendix F - Weatherproof Shield For Wind-Driven Snow And Rain

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters 10.6 Appendix F – Weatherproof Shield for Wind-Driven Snow and Rain The weather proof shield is to be installed on inverters when the chance of rain, snow or severe weather may occur. Examples of installations needing the shields are units installed on trackers or units installed outdoors, fully exposed to elements and in climates where severe weather can occur.

  • Page 68: Appendix G - Pvi 3000S-5300 Pv Inverter Fault Report Form

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters 10.6 Appendix G – PVI 3000S-5300 PV Inverter Fault Report Form Basic information Model (i.e. “PVI 3000S”) Serial number Purchased from Purchased date Installation information Type of installation Residential Commercial Installation date First operation date...

  • Page 69: Appendix H - Ul1741 / Ieee 1547 / Csa22.2#107.1 Listing Letter

    PVI 3000S, 4000S, 5000S, 5300 Series Inverters 10.7 Appendix H – UL1741 / IEEE 1547 / CSA22.2#107.1 Listing Letter Installation and Operation Manual (Rev A)
