Summary of Contents for Extron electronics MAC
- Page 1 P/2 DA1 P/2 DA2 PLUS P/2 DA2 LC P/2 DA2 MT P/2 DA2 WM P/2 DA4 PLUS P/2 DA6 PLUS SW2 VGA DA2 A SW2 VGA DA2 AF VGA, M , & 13W3 D ISTRIBUTION MPLIFIERS Mac DA2 PLUS 13W3 DA2...
-
Page 2: Application Diagram
P/2 DA1 Extron’s P/2 DA1, “The Peaker,” is an extremely small, one input, one buffered output VGA/SVGA/XGA/SXGA line driver. This DA drives a high resolution computer-video signal up to 250 feet through high-quality cable, such as Extron’s VGA cable. The P/2 DA1 provides amplification and peaking. - Page 3 I Compatibility – Compatible with all modes/resolutions of VGA, SVGA, XGA, and SXGA graphic cards, monitors, and projectors. Compatible with Mac sources and Mac-compatible displays with optional Mac/VGA adapter. I Input connector – Features a 15-pin HD female connector for video input.
-
Page 4: Part Numbers
I Bandwidth – 300 MHz (-3dB) RGB video bandwidth. I Compatibility – Compatible with all modes/resolutions of VGA, SVGA, XGA, and SXGA graphic cards, monitors, and projectors. Compatible with Mac sources and Mac- compatible displays with optional Mac/VGA adapter. I Video connectors – Features 15-pin HD female connec- tors for video input, buffered video outputs, and buffered local monitor output. - Page 5 Mac computer-video signal up to 200 feet through high-quality cable, such as Extron’s Mac/Quadra cable. For Mac boot-up, with or without a monitor, the Mac DA2 PLUS includes a sense line (ID bit) rotary switch with twelve resolutions available.
-
Page 6: Specifications
• All others ... 1 VGA, SVGA, XGA, SXGA Connectors • P/2 DA2 WM ... 1 15-pin HD male • Mac DA2 PLUS ... 1 15-pin D female • 13W3 DA2 ... 1 13W3 female • SW2 VGA DA2 A/AF ... 2 15-pin HD female •...
