INSTALLATION AND OPERATION MANUAL
FIGURE 1 – CNFE2MC STANDARD SIZE UNIT
OPTICAL FIBER
DETERMINED BY
SELECTION OF
SFP MODULE
CAT5e/6
FIGURE 2 – CNFE2MC STANDARD SIZE UNIT
FRONT PANEL
TECH SUPPORT: 1.888.678.9427
REAR PANEL
CNFE2MC[AC][/M] & CNFE22MC
BLACK
BLACK W/ WHITE STRIPE
Operating Voltage Range: 8-15 VDC
Power Consumption: 4W
NOTE: Remove Electrical Connector
for Rack Mount Units
INS_CNFE22MC_CNFE2MC[AC][/M]_REV– 04/09/10 PAGE 2
