Batch Customization via AddTool, AddImage, and AddDevType
Small Image File
Use this field to specify the small (16x16 pixel) bitmap image file that will be used to
represent your image in a variety of places within the NetSight Element Manager
framework (in the appropriate Select Symbol window, in a List View or Tree View, etc.).
Be sure to specify the path to the bitmap image.
Large Image File
Use this field to specify the large (32x32 pixel) bitmap image file that will be used to
represent your image in a variety of places within the NetSight Element Manager
framework (in the appropriate Select Symbol window, in a List View or Tree View, etc.).
Be sure to specify the path to the bitmap image.
Image Identifier
Use this field to assign a unique numeric identifier for your image. This identifier must be
unique among the identifiers already defined for the image type (model, class, topology,
or enterprise) you are defining. You can check to see which identifiers have already been
used for each image type via the Node Class Properties window; see
Properties

Creating an AddImage Input File

You can create your AddImage input file in one of two formats: multi-line tag/data format,
or single-line comma-separated variable (CSV) format. Each method is described below.

Comma-Separated Variable (CSV) Format

To create an input file using the single-line CSV format, you need only string together the
fields you wish to use in a single line, with each value separated by a comma. There are no
optional parameters, so be sure you have included the correct number of values. Spaces
before and after commas are ignored. Use one line for each image you wish to add; extra
lines are ignored. You can include different image type definitions (model, class, etc.) in a
single input file. Note that the filename cannot contain spaces.
If you wish, the first line of your file can contain a comma-separated list of the available
field names; if you choose not to include this line, you must launch your CSV file with a
special switch (as described in
file with this descriptive line is the default file type expected by the AddImage utility.
The following CSV file would add one image of each type: Class, Topology, Model, and
Enterprise. This sample includes the optional initial descriptive line. Note that the line
breaks shown here are a publishing limitation only; be sure your file does not break the
single line required for each image entry.
CSV Sample File
Image type, Image name, Small image file, Large image file,
Image id
A-6
in Chapter 4, List Views, for more information.
Executing the AddImage
Editing Node Class
Command, page A-8). A CSV
Using the AddImage Utility
