Change your font settings as desired using the Fonts, Font Style, and Size fields, then
click on OK to set your changes.

Selecting the Nodes to Display: Using Filters

Using the View Filter window, you can set up filters that determine which of the nodes
stored in the central node database will be displayed in your tree view. You can filter
nodes based on specific Subnet, Status Group, Enterprise, Class, and/or Topology
attributes.
To open the View Filter window:
1. Click on Filter from the New Tree View or Tree View Properties window. The
The check boxes above
the filter categories allow
you to either select or
de-select all of the specific
attributes listed. You must
leave at least one attribute
selected in each category;
to logically eliminate a
category from the filter,
select all of its attributes.

Filter Categories

Available filter categories are:
Subnets
NetSight Element Manager automatically creates a subnet entry each time a node is added
to the database; subnet entries can also be defined via the Discover application and/or via
the View—>Subnets option in the primary window menu bar. All subnets which have
been created will be displayed in this list box; use this list to select the subnets whose
nodes you wish to display in your tree view.
Creating and Editing Tree Views
View Filter window, Figure
Figure 5-8. View Filter Window
5-8, will be displayed.
Tree Views
5-13
