Creating Network Maps
1. If necessary, open or activate the map to which you wish to add a submap
2. In primary window menu bar, select Insert—>Sub Map.
If no other maps have yet been created, inserting a submap will launch the New Map View
window directly.
TIP
3. To create an entirely new map, click on Create New. The New Map View
Remember, any map can only be defined as the submap of one root map. If you select a
map which is already a submap of another map, the original submap link will be broken,
NOTE
and the new link established. This change will be reflected in the Map View workspace,
and the invalid submap icon will be automatically removed from the original map, but
you will not be notified in any other way that a submap relationship has been changed.
4. If you have chosen to create a new map, closing the New Map View
6-14
icon.
or
In the toolbar, click the Insert Sub Map
window, Figure 6-8, displays.
Figure 6-8. The Insert SubMap Window
window (as illustrated in
and display parameters as desired, then click OK.
To link an existing map, select the name of the map you wish to link, then
click OK. Only the maps available for submap linkage will be listed.
window changes the arrow cursor to a crosshair cursor; click this cursor in
your root map to place the submap icon.
If you have selected an existing map, it will be opened and placed behind
the active map, and the arrow cursor will change to a crosshair cursor. Click
this cursor in your root map to place the submap icon.
icon. The Insert SubMap
Figure 6-4 on page 6-8) opens. Configure the name
Building Your Network Map
