The Map View workspace will update automatically to display the new map in its position
in the hierarchy. The Submap icon itself will display the current status of its associated
map; double-clicking on a Submap icon will also open or activate the associated map.
You can only place a Submap symbol in the root map that was active when the Insert
Submap process was initiated.
TIP

Generating Submaps Automatically

If you prefer, NetSight Element Manager can create a map hierarchy for you
automatically, using the both the subnets you have defined via the Discover Manager and
those which have been automatically defined when you added devices to your central
node database.
For more information on using subnets as part of a discover, see
Subnets
TIP
that are currently defined, see
Once you have added your network devices to the central node database, you can
automatically create a map hierarchy as follows:
1. Select File—>New—>Subnet Mapping from the primary window menu bar.
Building Your Network Map
in Chapter 3, Discovering
Note that this menu option is always available, even when no map windows
are open or active. The Subnet Mapping window,
Figure 6-9. The Subnet Mapping Window
Nodes. For more information on viewing the subnets
Using the Subnets Window, also in Chapter 3.
Creating Network Maps
Defining and Selecting
Figure 6-9, opens.
6-15
