Enterasys

Network Access Control

Design Guide

P/N 9034385

Table of Contents

Need help?

Do you have a question about the 9034385 and is the answer not in the manual?

Questions and answers

Summary of Contents for Enterasys 9034385

Page 1 Enterasys ® Network Access Control Design Guide P/N 9034385...
Page 3 Notice Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made. The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES. Enterasys Networks, Inc. 50 Minuteman Road Andover, MA 01810 © 2008 Enterasys Networks, Inc. All rights reserved. Part Number: 9034385 March 2008 ENTERASYS, ENTERASYS NETSIGHT, ENTERASYS NETWORKS and any logos associated therewith, are trademarks or registered trademarks of Enterasys Networks, Inc., in the United States and other countries. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies. Documentation URL: http://www.enterasys.com/support/manuals Documentacion URL: http://www.enterasys.com/support/manuals Dokumentation im Internet: http://www.enterasys.com/support/manuals...
Page 5: Table Of Contents
About This Guide Intended Audience ... vii Related Documents ... vii Getting Help ... viii Chapter 1: Overview NAC Solution Overview ... 1-1 Key Functionality ... 1-1 Deployment Models ... 1-2 NAC Solution Components ... 1-4 The NAC Appliance ... 1-4 NAC Gateway Appliance ...
Page 6 Chapter 3: Use Scenarios Scenario 1: Intelligent Wired Access Edge ... 3-1 Policy-Enabled Edge ... 3-2 RFC 3580 Capable Edge ... 3-3 Scenario 1 Implementation ... 3-4 Scenario 2: Intelligent Wireless Access Edge ... 3-5 Thin Wireless Edge ... 3-5 Thick Wireless Edge ...
Page 7 Unregistered Policy ... 5-28 Inline NAC Design Procedures ... 5-28 1. Determine NAC Controller Location ... 5-28 2. Determine the Number of NAC Controllers ... 5-30 3. Identify Backend RADIUS Server Interaction ... 5-32 4. Define Policy Configuration ... 5-32 Failsafe Policy and Accept Policy Configuration ...
Page 9: About This Guide
The NAC Design Guide describes the technical considerations for the planning and design of the Enterasys Network Access Control (NAC) solution. The guide includes the following information: For information about... An overview of the Enterasys NAC Solution and a comparison between the inline NAC Controller and the out-of-band NAC Gateway appliances. The four different NAC deployment models and their requirements. Four NAC use scenarios that demonstrate the deployment of inline versus out-of-band network access control.
Page 10: Getting Help
The device history (for example, if you have returned the device before, or if this is a recurring problem) • Any previous Return Material Authorization (RMA) numbers viii About This Guide www.enterasys.com/support 1-800-872-8440 (toll-free in U.S. and Canada) or 1-978-684-1000 To find the Enterasys Networks Support toll-free number in your country: www.enterasys.com/support support@enterasys.com To expedite your message, type [NetSight] in the subject line.
Page 11: Chapter 1: Overview
This chapter provides an overview of the Enterasys Network Access Control (NAC) solution, including a description of key NAC functions and deployment models. It also introduces the required and optional components of the Enterasys NAC solution, and presents a comparison between the inline NAC Controller for implementation of inline network access control and the out‐of‐band NAC Gateway for implementation of out‐of‐band network access control. For information about... NAC Solution Overview NAC Solution Components Summary NAC Solution Overview Enterasys NAC is a centralized network access control solution that combines authentication, vulnerability assessment, and location services to authorize network access and determine the appropriate level of service for an end‐system. The NAC solution ensures that only valid users and devices connecting at the proper location, at the right time, and with appropriate security postures, are granted access to your network. For end‐systems which are not compliant with defined security guidelines, the NAC solution provides assisted remediation, allowing end users to perform self‐service repair steps specific to the detected compliance violation. Key Functionality The Enterasys NAC solution supports the five key network access control functions: detection, authentication, assessment, authorization, and remediation. These five functions can be deployed in various combinations, as described in the following section on deployment models. Here is a description of the five key NAC functions: Detection Identify when and where a device connects to the network. Authentication Verify the identity of the user or device connecting to the network. Enterasys NAC supports the “pass through” authentication (proxying to a backend RADIUS server) of 802.1X, web‐based (PWA), and MAC authentication requests, as well as local MAC authentication. This provides access control for both user‐centric and machine‐centric end‐systems in the enterprise environment. Overview Refer to page...
Page 12: Deployment Models
NAC Solution Overview Assessment Determine if the device complies with corporate security and configuration requirements, such as operating system patch revision levels and antivirus signature definitions. Other security compliance requirements might include the physical location of the device and the time of day the connection attempt is made. Authorization Determine the appropriate network access for the connecting device based on the authentication and/or assessment results, and enforce this authorization level to the end‐system. The authorization level can be determined based on the deviceʹs location, MAC address, and security posture (as determined by the assessment results), in addition to the identity of the user/device validated through authentication. The end‐system can be authorized for network access using different techniques, such as reconfiguring access edge switches or leveraging a specialized NAC appliance deployed in the transmission path of end‐system data traffic. Inline and out‐of‐band NAC implementations use different techniques for authorizing end‐systems on the network, each with unique advantages and disadvantages as discussed later in this chapter. Remediation Enable end users to safely remediate their non‐compliant end‐systems without impacting IT operations. With remediation, users can be notified when their system is quarantined for network security policy non‐compliance, and they can be directed to perform self‐service remediation techniques specific to the detected compliance violation. Notification methods include web redirection via a captive portal, email notification, pop‐up messages, and messenger service integration, among others. The remediation process includes updating the device to meet corporate security requirements (for example, updating operating system patches and antivirus signatures) and reinitiating the network access process. Network resources can be automatically reallocated to end‐systems that have successfully performed the remediation steps, without the intervention of IT operations. Deployment Models The five key NAC functions described above do not need to be implemented concurrently in a NAC deployment. For example, to support MAC registration for guests and other users on the network, the detection, authentication, and authorization functionalities can be implemented without the assessment functionality. This allows an IT department to gain visibility into who is using which devices on the network while allowing only valid users to enter the network. As another example, the assessment functionality can be added to the detection, authentication, and authorization of end‐systems without the remediation functionality, allowing for the auditing, but not quarantining, of connecting end‐systems. This provides visibility into the security posture and configuration of connecting end‐systems without impacting device network connectivity, and ...
Page 13 NAC Solution Overview Model 1: End-system Detection and Tracking This NAC deployment model implements the detection piece of NAC functionality. It supports the ability to track users and end‐systems over time by identifying where they are currently connected to the network and where they have connected to the network at any given time in the past. This information is useful for compliance and auditing purposes, as well as other management operations that require complete visibility into the current and historical connections of end‐ systems and users. Model 2: End-System Authorization This NAC deployment model implements the detection, authentication, and authorization NAC functionalities, to control access to network resources based on user and end‐system identity and location. The model supports MAC address or guest registration, where new end‐systems are forced to provide a valid user identity in a web page form before being allowed access to the network. Following successful registration, end‐systems are granted measured access, without requiring the intervention of network operations. Model 3: End-System Authorization with Assessment This NAC deployment model implements the detection, authentication, assessment, and authorization NAC functionalities, to control access to network resources based on the security posture of a connecting end‐system, as well as user and device identity and location. End‐systems that fail assessment can be dynamically quarantined with restrictive network access to mitigate the propagation of security threats on the network, while compliant end‐systems are permitted onto the network with a measured level of access. Alternatively, specific end‐systems and users can be assessed upon network connection and be permitted network access regardless of the assessment results. This approach allows an IT administrator to have visibility into the configuration of end devices on the network without impacting their network connectivity during or after assessment. This approach is usually ...
Page 14: Nac Solution Components
NAC Solution Components NAC Solution Components This section discusses the required and optional components of the Enterasys NAC solution, beginning with the following table that summarizes the component requirements for each of the four deployment models. Table 1-1 Component Requirements for NAC Deployment Models Model 1 Detection and NAC Component Tracking NAC Appliance Required NetSight NAC Required Manager NetSight Console Required Assessment Server Optional RADIUS Server Optional NetSight Policy Optional Manager...
Page 15: Nac Gateway Appliance
Enterasys offers two types of NAC appliances: the NAC Gateway appliance implements out‐of‐ band network access control, and the NAC Controller appliance implements inline network access control. The following section describes how each NAC appliance implements network access control for connecting end‐systems. NAC Gateway Appliance The NAC Gateway is utilized to implement out‐of‐band network access control for connecting end‐systems. With the NAC Gateway, connecting end‐systems are detected on the network through their RADIUS authentication interchange. Based on the assessment and authentication results for a connecting device, RADIUS attributes are added or modified during the authentication process to authorize the end‐system on the authenticating edge switch. Therefore, the NAC Gateway can be positioned anywhere in the network topology with the only requirement being that IP connectivity between the authenticating edge switches and the NAC Gateways is operational. The NAC Gateway requires the implementation of intelligent wired or wireless edge infrastructure devices as the authorization point for connecting end‐systems. Intelligent edge devices are capable of supporting authentication and authorization based on the authentication message interchange. Depending on the appliance model, the NAC Gateway provides either integrated assessment server functionality and/or the ability to connect to external assessment services, to determine the security posture of end‐systems connecting to the network. Three NAC Gateway models are available to meet the needs of different‐sized implementations and assessment server requirements. • SNS‐TAG‐ITA supports up to 3000 concurrent end‐systems and provides integrated assessment servers. (A separate license is required for integrated assessment.) This integrated NAC Gateway supports both agent‐less (network‐based) and agent‐based assessment. In addition to having the capability to run as an integrated appliance, it also has the capability to run as an assessment server (scanner) only. The SNS‐TAG‐ITA also supports the ability to connect to multiple external assessment servers including Nessus and Lockdown Enforcer. • SNS‐TAG‐HPA supports up to 3000 concurrent end‐systems and supports the ability to connect to multiple external assessment servers including Nessus and Lockdown Enforcer. • SNS‐TAG‐LPA supports up to 2000 concurrent end‐systems and supports the ability to connect to multiple external assessment servers including Nessus and Lockdown Enforcer. NAC Controller Appliance The NAC Controller is utilized to implement inline network access control for connecting end‐ systems. With the NAC Controller, connecting end‐systems are detected through the receipt of a ...
Page 16 NAC Solution Components of supporting authentication and/or authorization. The NAC Controller is also required in IPSec and SSL VPN deployments. The NAC Controller provides integrated vulnerability assessment server functionality and supports both agent‐less (network‐based) and agent‐based assessment. (A separate license is required for integrated assessment.) It also supports the ability to connect to multiple external assessment servers including Nessus and Lockdown Enforcer. The NAC Controller can be configured in one of two modes of operation: Layer 2 or Layer 3. The mode of operation controls how connecting end‐systems are detected by the NAC Controller on the network and is selected based on where the NAC Controller is positioned in the network in relation to these end‐systems. If the NAC Controller is positioned before the first routed boundary for connecting end‐systems, closer to the access edge of the network, the Layer 2 NAC Controller mode is utilized. In this mode of operation, the NAC Controller detects connecting end‐systems on the network by receiving traffic from a new MAC address. If the NAC Controller is positioned after the first routed boundary deeper inside the network, the Layer 3 NAC Controller mode is utilized. In this mode of operation, the NAC Controller detects connecting end‐systems on the network by receiving traffic from a new IP address. With the NAC Controller supporting both Layer 2 and Layer 3 modes of operation, the NAC Controller can be strategically positioned in the network topology to achieve the desired level of scalability and security. The NAC Controller is available in two models: • 2S4082‐25‐SYS ‐ 24‐Port 10/100/1000 NAC Controller supports up to 2000 concurrent end‐ systems. • 7S4280‐19‐SYS ‐ 18‐Port SFP NAC Controller supports up to 2000 concurrent end‐systems. 1-6 Overview...
Page 17: Appliance Comparison
Appliance Comparison The following table compares how the two NAC appliance types implement the five NAC functions. Table 1-2 Comparison of Appliance Functionality NAC Function Detection RADIUS authentication request is received from access edge switches. Authentication For user authentication, RADIUS authentication requests are proxied to an upstream RADIUS server which contains a database of valid user credentials.
Page 18: Comparison Of Appliance Advantages And Disadvantages
NAC Solution Components Table 1‐3 outlines the advantages and disadvantages of the two appliance types as they pertain to network security, scalability, and configuration/implementation. Table 1-3 Comparison of Appliance Advantages and Disadvantages Features Supported Connection Types Deployment Configuration Security 1-8 Overview NAC Gateway Disadvantage: Restricted to wired and wireless access edge with authentication and authorization functionality. Advantage: Less disruptive because no topology reconfiguration is required.
Page 19: Netsight Management
Table 1-3 Comparison of Appliance Advantages and Disadvantages (continued) Features NAC Granularity Scalability NetSight Management The NAC appliances are configured, monitored, and managed through management applications within the Enterasys NetSight Suite. NetSight is a family of products comprised of NetSight Console and a suite of plugin applications. Of the following NetSight applications, NetSight NAC Manager and NetSight Console are required for all four NAC deployment models, while NetSight Policy Manager and NetSight Inventory Manager are optional, depending on your network configuration and the network access control features you wish to implement. Following is a description of the NetSight applications. NetSight NAC Manager NetSight NAC Manager is a required core component in the Enterasys NAC solution. NAC Manager and NAC appliances work in conjunction to implement network access control. NAC Manager provides configurations for the assessment, authentication, authorization, and remediation parameters for all NAC appliances (NAC Gateways and NAC Controllers) from one centralized interface. After these configurations are enforced, the NAC appliances can detect, authenticate, assess, authorize, and remediate end‐systems connecting to the network according to those configuration specifications. NAC Gateway Advantage: The NAC Gateway is always aware of the MAC address of the device connecting to the network, and its associated IP address, username,...
Page 20: Netsight Console
Summary NetSight Console NetSight Console is used to monitor the health and status of infrastructure devices in the network, including switches, routers, Enterasys NAC appliances (NAC Gateways and NAC Controllers) as well as other security appliances. NetSight NAC Manager is a plugin to NetSight Console, and NetSight Console must be installed on a server with NAC Manager for the Enterasys NAC solution. NetSight Policy Manager The NetSight Policy Manager application provides the ability to centrally define and configure the authorization levels or “policies” for certain NAC deployments. Policy Manager is required for inline NAC deployments, and provides the ability to configure and manage policies on the NAC Controller appliance. Policy Manager is recommended for out‐of‐band NAC deployments that include Enterasys policy‐enabled switches in the access layer, and provides the ability to centrally manage policies on these switches. This central administration of policies using Policy Manager includes distribution of the “Enterprise User,” “Assessing,” “Quarantine,” and “Failsafe” policy roles to the policy enforcement points. NetSight Inventory Manager The NetSight Inventory Manager application is an optional component of the NAC solution, providing comprehensive network inventory and change management capabilities for your network infrastructure. RADIUS Server A RADIUS server with backend directory services must be implemented in the NAC solution if 802.1X or web‐based (PWA) authentication of end‐systems is utilized with out‐of‐band network access control. Furthermore, if RADIUS is utilized for authenticating management logins for infrastructure devices, a RADIUS server must be deployed on the network. Assessment Server If the NAC deployment model includes vulnerability assessment, one or more assessment servers must be deployed on the enterprise network either as integrated components of the NAC appliance or as external assessment services. Summary The Enterasys NAC solution supports the five key network access control functions: detection, authentication, assessment, authorization, and remediation. Four NAC deployment models provide support for diverse enterprise environments, with each model implementing particular ...
Page 21 • Model 3: End‐System Authorization with Assessment ‐ Implements detection, authentication, assessment, and authorization to provide network access control based on the security posture of a connecting end‐system, as well as user and device identity and location. This model requires the use of either integrated assessment server functionality or the ability to connect to external assessment services, in order to perform the end‐system assessment. • Model 4: End‐System Authorization with Assessment and Remediation ‐ Implements detection, authentication, assessment, authorization, and remediation, providing the additional ability to quarantine and remediate noncompliant devices. The NAC appliance is a core component of the Enterasys NAC solution and is required for all NAC deployment models. It provides the ability to detect, authenticate, and authorize end devices attempting to connect to the network. It also integrates with or connects to assessment services to perform assessment of end‐systems connecting to the network. Once authentication and assessment are complete, the NAC appliance authorizes devices on the network by allocating the appropriate network resources to the end‐system based on authentication and/or assessment results. The NAC appliance also provides remediation functionality, allowing end users to safely remediate their quarantined end‐system without impacting IT operations. Enterasys offers two types of NAC appliances: • The NAC Gateway appliance implements out‐of‐band network access control and requires the implementation of intelligent wired or wireless edge infrastructure devices on the network. • The NAC Controller appliance implements inline network access control and is applicable to scenarios where non‐intelligent wired or wireless edge infrastructure devices are deployed in the network. The NAC Controller is also required in IPSec and SSL VPN deployments. The NAC appliances are configured, monitored, and managed through Enterasys NetSight management applications. NetSight NAC Manager and NetSight Console are required for all four NAC deployment models. NAC Manager provides configurations for the assessment, authentication, authorization, and remediation parameters for all NAC appliances, while NetSight Console is used to monitor the health and status of infrastructure devices in the network, including switches, routers, and Enterasys NAC appliances. NetSight Policy Manager and NetSight Inventory Manager are optional NetSight applications. Policy Manager provides the ability to centrally define and configure the authorization levels or “policies” for certain out‐of‐band NAC deployments and all inline NAC deployments. Inventory Manager provides comprehensive network inventory and change management capabilities for your network infrastructure. The next chapter provides a more detailed description of the four NAC deployment models including their requirements and implementation. Summary Enterasys NAC Design Guide 1-11...
Page 22 Summary 1-12 Overview...
Page 23: Model 1: End-System Detection And Tracking
This chapter describes the four NAC deployment models and how they build on each other to provide a complete NAC solution. The first model implements a subset of the five key NAC functions (as described in Chapter functionality without the need to replace existing pieces of the NAC solution. This allows businesses who are still in the early stages of NAC deployment, to take a phased approach to implementing NAC while deriving value from the solution at each step along the way. For information about... Model 1: End-System Detection and Tracking Model 2: End-System Authorization Model 3: End-System Authorization with Assessment Model 4: End-System Authorization with Assessment and Remediation Summary Model 1: End-System Detection and Tracking This NAC deployment model implements the first key NAC function, detection. The detection of ...
Page 24: Inline Nac (Layer 2)
Model 1: End-System Detection and Tracking RADIUS Access‐Accept or Access‐Reject message received from the upstream RADIUS server, is returned without modification to the access edge switch, to permit end‐system access to the network. For MAC authentication, a RADIUS Access‐Accept message is returned to the access edge switch without modification, based on a RADIUS Access‐Accept message received from the upstream RADIUS server or local authorization of MAC authentication requests. The authenticating end‐system is provided access to the network based on the configuration of the access edge switch. Inline NAC (Layer 2) For inline NAC utilizing the Layer 2 NAC Controller, an end‐system can be detected in multiple ways. An end‐system can be detected simply by transmitting data traffic not previously seen by the NAC controller. In this case, the traffic is forwarded through the NAC Controller to the traffic destination, and has no impact on the connectivity of the end‐system. In another method, end‐ systems are detected with the authentication of downstream end‐systems via 802.1X, web‐based, and/or MAC authentication on the NAC Controller. These authentication requests may or may not be proxied upstream depending on the NAC configuration. Inline NAC (Layer 3) For inline NAC utilizing the Layer 3 NAC Controller, an end‐system is detected simply by transmitting data traffic sourced from an IP address not previously seen by the NAC controller. The traffic is forwarded through the NAC controller to the traffic destination, and has no impact on the connectivity of the end‐system. Features and Value There are two key pieces of functionality and value propositions supported by Model 1: End-System and User Tracking Model 1 supports the ability to track end‐systems by MAC address, as the device moves from ...
Page 25: Required And Optional Components
and information on the network. Enterasys NAC can be leveraged to provide information to SIM solutions, by mapping an IP address to an identity, such as a MAC address or username and location, for a more complete representation of the attack source or target on the network. In this way, the Enterasys NAC solution further enhances the operation of existing security technologies deployed on the network. Required and Optional Components This section summarizes the required and optional components for Model 1. Table 2-1 Component Requirements for Detection and Tracking Component NAC Appliance NetSight NAC Manager NetSight Console Assessment RADIUS Server NetSight Policy Manager NetSight Inventory Manager The NAC Gateway and NAC Controller are the NAC appliances used to implement the out‐of‐ band and inline network access control functionality on the network. NetSight NAC Manager is the software application used to centrally manage the NAC appliances deployed on the network. NetSight Console is the software application used to monitor the health and status of infrastructure devices in the network, including switches, routers, and Enterasys NAC appliances ...
Page 26: Implementation
Model 2: End-System Authorization device identity, user identity, and/or location information is used to authorize the connecting end‐ system with a certain level of network access. It is important to note that in this model, network access is not being controlled based on end‐system assessment results. Assessment will be introduced in the next NAC deployment model. Implementation In Model 2, end‐systems can be detected, authenticated, and authorized in different ways depending on whether inline or out‐of‐band network access control is implemented. Out-of-Band NAC For out‐of‐band NAC utilizing the NAC Gateway, NAC functions are implemented in the following way: Detection ‐ End‐systems are detected via the receipt of RADIUS packets from an access edge switch attempting to authenticate an end‐system. Authentication ‐ If the end‐system is 802.1X or web authenticating to the network, the NAC Gateway proxies the RADIUS authentication request to a backend authentication (RADIUS) server to validate the identity of the user/device connecting to the network. For end‐systems that are MAC authenticating to the network, the NAC Gateway can be configured to either proxy the MAC authentication requests to a RADIUS server or locally authorize MAC authentication requests at the NAC Gateway. If only MAC authentication is deployed on the network and the NAC Gateway is configured to locally authorize MAC authentication requests, then a backend RADIUS server is not required for the Enterasys NAC solution. Authorization ‐ The NAC Gateway allocates the appropriate network resources to the end‐system based on device identity, user identity, and location. For Enterasys policy‐enabled edge switches, the NAC Gateway formats information in the RADIUS authentication messages that directs the edge switch to dynamically assign a particular policy to the connecting end‐system. For RFC 3580‐ capable edge switches, the NAC Gateway formats information in the RADIUS authentication messages (in the form of RFC 3580 VLAN Tunnel attributes) that directs the edge switch to dynamically assign a particular VLAN to the connecting end‐system. The NAC Gateway may deny the end‐system access to the network by sending a RADIUS Access‐Reject message to the edge switch or assign the end‐system a set of network resources by specifying a particular policy or VLAN to assign to the authenticated end‐system on the edge switch. Inline NAC For inline NAC utilizing the Layer 2 or Layer 3 NAC Controller, NAC functions are implemented in the following way: Detection ‐ End‐systems are detected via the receipt of RADIUS packets from an access edge switch attempting to authenticate an end‐system.
Page 27: Features And Value
The NAC Controller may either deny the end‐system access to the network or assign the end‐ system to a particular set of network resources by specifying a particular policy. Features and Value In addition to the features and values found in Model 1, the following are key pieces of functionality and value propositions supported by Model 2, End‐System Authorization: Location-Based Authorization In addition to providing visibility into who, what, when, and where devices and users are connecting to the network, this deployment model allows IT operations to control access to the network with different levels of authorization based on these parameters. For location‐ based authorization, the Enterasys NAC solution can assign a level of access to a connecting end user or device based on which area of the network the end‐system is connected, through the configuration of Security Domains. For example, when an engineer connects to the network from a controlled area of the network such as the lab, or a faculty member connects to the network from a physically secured faculty office, the engineer and faculty member are appropriately authorized to access sensitive information residing on internal servers. However, if the same users connect to the network from an unsecured area of the network such as the open wireless LAN available in the enterpriseʹs lobby or campus, or in a student dormitory, then these end‐systems can be authorized with a different level of network access, possibly restricting communication to the internal servers and other resources on the network. Furthermore, the NAC solution can also lock a device to a specific switch or switch port, using the “Lock MAC” feature. If the device is moved to any other switch port on the network, it will not be able to connect. For example, a printer or a server containing sensitive data may be connected to the network at a specific location, such as behind a firewall or on a particular VLAN for security reasons. Physically moving the connection of these devices to an open area of the network increases the risk of these devices being attacked and compromised because they would no longer be protected by the security mechanisms that were put in place on the network. The “Lock MAC” feature can be used to limit the mobility of specific devices and avoid malicious or unintentional misconfigurations on the network, thereby reducing risk. Device-Based Authorization With this NAC deployment model, end‐systems are authorized with access to a specific set of network resources based on the end‐systemʹs MAC address. For initial implementation, the Enterasys NAC solution is configured in a mode where all MAC addresses of connecting end‐ systems are permitted onto the network and dynamically learned. The Enterasys NAC solution is then configured to allow only known MAC addresses onto the network, assigning each end‐system a particular authorization level. Any new MAC address connecting to the network is assigned a different authorization level, such as denied access, restricted access, or allowed access if the user is able to properly register their device to the network.
Page 28 Model 2: End-System Authorization is only provisioned by the Enterasys NAC solution when the devices connect to switches in the Network Operations Center (NOC). This level of granularity in provisioning access to connecting devices protects against possible MAC spoofing attacks. In addition to authorizing a particular device with a set of network resources, groups of devices such as IP phones, printers, and workstations can be provisioned a specific set of network resources using MAC address OUI prefix or custom MAC address mask. For example, IP phones may be identified by the Polycom MAC address OUI prefix 00:04:F2:XX:XX:XX and assigned the Voice VLAN and a high QoS. In summary, device‐based authorization supports the provisioning of network resources to a connecting end‐system based on the deviceʹs identity as well as location. This provides the ability to restrict end‐systems that pose a threat to the network, provide special access to particular devices, and provision end‐systems or sets of end‐systems with access to required sets of network resources to ensure business continuity. User-Based Authorization With this NAC deployment model, end‐systems can be authorized with access to a specific set of network resources based on the user logged into the end‐system and their organizational role within the enterprise. For example, a user who is an engineer may be allocated prioritized access to the engineering servers deployed on the network while being denied access to servers utilized by the HR or legal departments. Furthermore, a user who is known to be launching malicious attacks against critical resources on the network or was terminated from a position within the company may be authorized a restrictive set of network resources or outright denied network access, regardless of where and when this user connects to the network. In contrast, a user in the IT operations group or a technician sent to repair a device on the network may be permitted unrestricted access to network resources for troubleshooting and maintenance purposes, regardless of where and when the user connects to the network, or only from inside the NOC. In summary, user‐based authorization supports the provisioning of network resources to connecting users based on the userʹs identity and successful authentication, as well as their location on the network, affording such capabilities as denying users that pose a threat to the network, providing particular employees with special access, and provisioning users in general with appropriate access to the required sets of network resources, to ensure business continuity. MAC Registration Enterasys NAC provides support for MAC Registration, also known as Network or Guest Registration. This solution forces any new end‐system connected on the network to provide ...
Page 29: Required And Optional Components
a password in the registration web page. This sponsor username and password can be validated against an existing database on the network to authenticate the sponsorʹs identity. Sponsors may be allowed to securely access an administrative web page where they can delete, add, and modify registered end‐systems on the network that they have sponsored. With sponsored registration enabled, IT operations can hold trusted users accountable for guests brought on the enterprise network, while controlling access for only appropriate guests. Post-Connect NAC integration with NetSight Automated Security Manager NetSight Automated Security Manager (ASM), a software application that is part of the NetSight Suite, has the capability to search the infrastructure and locate the switch port of connection, based on the receipt of a security event for a particular IP address. ASM responds to this event by disabling the port or assigning a VLAN (such as the quarantine VLAN) to the port. In response to a real‐time security threat detected on the network, ASM can be configured to notify NAC Manager on this event, dynamically quarantining the MAC address. This effectively restricts the quarantined end‐system from accessing the network from any location, enterprise‐wide. If ASM reverses the quarantine action, it notifies NAC Manager, and the quarantine is automatically removed and the end‐system is dynamically re‐ admitted access to network resources. Therefore, the deployment of Enterasys NAC further increases the security posture of the network by integrating with the reactive threat response capabilities of ASM, in addition to controlling access and authorizing connecting devices. Required and Optional Components This section summarizes the required and optional components for Model 2. Table 2-2 Component Requirements for Authorization Component NAC Appliance NetSight NAC Manager NetSight Console Assessment...
Page 30: Model 3: End-System Authorization With Assessment
Model 3: End-System Authorization with Assessment A RADIUS server is only required if out‐of‐band network access control using the NAC Gateway, or inline network access control using the Layer 2 NAC Controller, is implemented with web‐ based and/or 802.1X authentication. NetSight Policy Manager is required for all inline NAC deployments, and recommended for out‐ of‐band NAC deployments that utilize Enterasys policy‐capable switches. Policy Manager provides the ability to centrally define and configure the authorization levels or policies. NetSight Inventory Manager is an optional component, providing comprehensive network inventory and change management capabilities. Model 3: End-System Authorization with Assessment This NAC deployment model implements the detection, authentication, assessment and authorization NAC functionalities for connecting end‐systems. In Model 2, end‐systems and end users connected to the network are authorized based on the device identity, user identity, and/or location information. Model 3 extends the authorization decision in NAC to one additional dimension — the security posture of the end‐system as determined from an assessment. The assessment can be executed through agent‐based or agent‐less techniques and can identify different pieces of information about the device, such an antivirus software configuration, operating system patches installed, software applications installed and running, processes running, services configured, and registry values set. It is important to note that it is not necessary to configure the Enterasys NAC solution to quarantine end‐systems that fail assessment. In fact, during the initial rollout of NAC on the enterprise network, it is highly recommended that end‐systems are not restricted access to the network in any way before, during, or after failed assessment. This passive NAC configuration allows the IT administrator to baseline the configuration of devices on the network and understand the current landscape of its assets without impacting network connectivity for connecting end‐systems. In this configuration, it is not necessary to inform the end users that they are being assessed or have failed assessment because there is little‐to‐no impact on network connectivity during this assessment. End‐systems can be scanned in the background providing the network administrator with important visibility into how devices are configured on their network, while end users can utilize the network as desired. Then, when the network administrator is ready, the Enterasys NAC solution can be configured with the click of a button to ...
Page 31: Inline Nac
Model 3: End-System Authorization with Assessment server is running or if the HTTP server is out‐of‐date) and client‐side checks (running applications, software configurations, installed operating system patches) provided end‐system administrative credentials are available for remote login to connecting devices. Additionally, the NAC Gatewayʹs local assessment services also include agent‐based assessment using a Java Web Start‐based client application that allows execution of server‐side and client‐side checks without requiring administrative credentials or special host firewall configurations. The NAC Gatewayʹs remote assessment services include agent‐less and agent‐based assessment on other NAC Gateways deployed on the network and/or third‐party vulnerability scanners such as Nessus and Lockdown Enforcer. As end‐systems connect to the network, assessments can be load‐balanced among all of the configured assessment services or a defined pool. This provides maximum scalability and flexibility, and minimizes the amount of time necessary to complete an end‐system assessment. Authorization ‐ The NAC Gateway allocates the appropriate network resources to the end‐system based on authentication, location, and/or assessment results. For Enterasys policy‐enabled edge switches, the NAC Gateway formats information in the RADIUS authentication messages that directs the edge switch to dynamically assign a particular policy to the connecting end‐system. For RFC 3580‐capable edge switches, the NAC Gateway formats information in the RADIUS authentication messages in the form of RFC 3580 VLAN Tunnel attributes that directs the edge switch to dynamically assign a particular VLAN to the connecting end‐system. If authentication fails and/or the assessment results indicate a noncompliant end‐system, the NAC Gateway can either deny the end‐system access to the network by sending a RADIUS access reject message to the edge switch or quarantine the end‐system with a highly restrictive set of network resources (or possibly permit network access) by specifying a particular policy or VLAN to assign to the authenticated end‐system on the edge switch. Inline NAC For inline Enterasys NAC deployments utilizing the Layer 2 or Layer 3 NAC Controller, the NAC functions are implemented in the following way: Detection ‐ As described in Model 2. Authentication ‐ As described in Model 2. Assessment ‐ The NAC Controller can leverage either local assessment services and/or remote assessment services deployed on the network, as previously described for the NAC Gateway. The NAC Controllerʹs local assessment services include agent‐less assessment which can execute various server‐side checks and client‐side checks. Local assessment services also include agent‐ based assessment using a Java Web Start‐based client application that allows execution of server‐...
Page 32: Features And Value
Model 3: End-System Authorization with Assessment Features and Value In addition to the features and values found in Model 1 and Model 2, the following are key pieces of functionality and value propositions supported by Model 3, End‐System Authorization with Assessment: Extensive Security Posture Compliance Verification The following describes a few examples of tests that can be executed for connecting end‐ systems and the relevance of these tests from a compliance and security standpoint: • Antivirus software configuration The NAC solution can determine if an end‐system has antivirus software installed, if it is properly configured (real‐time protection is enabled), if it is up‐to‐date with the most recent virus definition file, and if it is enabled. Antivirus software has the ability to detect infections as they happen, and to prevent further propagation of the virus to other end‐systems. It is important to verify that end‐systems are protected with antivirus software when they connect to the network, in case the end‐system is subsequently infected with a worm or virus after connectivity is established. • Operating system patch level The NAC solution can determine if the end‐system is up‐to‐date with the latest operating system patches. This ensures that any vulnerabilities present in services running on unpatched laptops are appropriately remediated, so that attacks that target those vulnerabilities are not successful, if they reach the device on the network. • Malware infection The NAC solution can determine if the end‐system is infected with malware (worms, viruses, spyware, and adware) by identifying backdoor ports on which the end‐system is listening, running processes and services, and/or registry key settings. By identifying infected end‐ systems prior to network connection, the NAC solution protects other end‐systems on the network from possible infection and prevents the unnecessary consumption of network ...
Page 33 • Application configuration The NAC solution can determine which services and applications are installed and enabled on the end‐system. Certain applications should be removed from the device prior to establishing connectivity because they may have a negative impact on the operation of the end‐system, distract the end user from business functions, or be used to launch attacks on the network. Furthermore, particular services may be outdated and vulnerable to attack. These services should either be updated or disabled to minimize the risk to connecting end‐systems on the network. The NAC solution facilitates this reconfiguration of applications on an end‐system prior to network connection, to ensure maximum security and productivity when the device connects. Diverse Security Posture Compliance Verification In order for a NAC solution to be effective, inclusion of all end‐systems in the network environment must be addressed when detecting, authenticating, assessing, and authorizing devices. The Enterasys NAC solution supports a diverse end‐system environment, and provides integrated security and management regardless of what type of devices are connected to the business network. Enterasys leverages two assessment models: agent‐based and agent‐less. An agent‐based assessment and an agent‐less assessment are both critical to ensuring that any end‐system of any type can be included in the NAC process. There are several reasons why both assessment models are critical to a complete NAC solution. Security agents loaded onto managed end‐ systems offer extensive assessment capabilities. If an agent is required, a new end‐system connecting to the network that has not downloaded the agent can be quarantined and redirected to a web page. The web page provides information on how the agent can be downloaded and installed on the end‐system to begin its assessment. However, there are types of end‐systems in a typical network that may not be able to load a software agent, such as IP phones, security cameras, or printers. If a security agent is not available for a device (or the operating systems running the device), an agent‐less approach is the only way to assess the end‐system. In addition, consider end‐systems that could normally hold an agent, but are not under the control of the IT organization. In the case of guest networking that provides support for contractors, vendors, and the public, the desire may be to support minimal or specific network services, but still ensure the safety and security of the network and the people using it. It is not enough to simply use a network usage policy to restrict the services a guest user is allowed to access. Because the guest is leveraging the same network infrastructure as the critical business users, it is important that proactive security measures are applied to the guest just as they are to a managed user. This is another case where an agent‐less approach to end‐system assessment can be critical to ensuring a ...
Page 34: Required And Optional Components
Model 4: End-System Authorization with Assessment and Remediation Required and Optional Components This section summarizes the required and optional components for Model 3. Table 2-3 Component Requirements for Authorization with Assessment Component NAC Appliance NetSight NAC Manager NetSight Console Assessment Service RADIUS Server NetSight Policy Manager NetSight Inventory Manager The NAC Gateway and NAC Controller are the NAC appliances used to implement the out‐of‐ band and inline network access control functionality on the network.
Page 35: Implementation
Model 4: End-System Authorization with Assessment and Remediation Assisted remediation informs end users when their end‐systems have been quarantined due to network security policy non‐compliance, and allows end users to safely remediate their non‐ compliant end‐systems without assistance from IT operations. The process takes place when an end‐system connects to the network and assessment is performed. End users whose systems fail assessment are notified via web redirection that their systems have been quarantined, and are instructed in how to perform self‐service remediation specific to the detected compliance violations. Once the remediation steps have been successfully performed and the end‐system is compliant, the end user can initiate an on‐demand reassessment of the end‐system and can be allocated the appropriate network resources, again without the intervention of IT operations. Implementation In Model 4, end‐systems can be detected, authenticated, assessed, authorized, and remediated in different ways depending on the whether inline or out‐of‐band network access control is implemented in the Enterasys NAC solution. Out-of-Band NAC For out‐of‐band Enterasys NAC deployments utilizing the NAC Gateway, NAC functions are implemented in the following way: Detection ‐ As described in Model 2. Authentication ‐ As described in Model 2. Assessment ‐ As described in Model 3. Authorization ‐ As described in Model 3. Remediation ‐ When end‐systems are quarantined by the NAC Gateway, the network must be configured to direct all traffic from the quarantined end‐systems to the NAC Gateway. This can be implemented by configuring policy‐based routing on a router inline with the traffic sourced from quarantined end‐systems. This router would be configured to send all web traffic from quarantined end‐systems to the NAC Gateway, which then serves back the remediation web page to the end user. The way the router identifies the traffic from quarantined end‐systems differs between a network composed of policy‐enabled switches in the access edge or a network composed of switches implementing RFC 3580 dynamic VLAN assignment in the access edge. For an Enterasys policy‐ enabled edge, the Quarantine policy can be configured to rewrite the Type of Service (ToS) value of HTTP traffic to a particular setting that matches the policy‐based routing configuration. For an ...
Page 36: Inline Nac
Model 4: End-System Authorization with Assessment and Remediation Inline NAC For inline Enterasys NAC deployments utilizing the Layer 2 or Layer 3 NAC Controller, the NAC functions are implemented in the following way: Detection ‐ As described in Model 2. Authentication ‐ As described in Model 2. Assessment ‐ As described in Model 3. Authorization ‐ As described in Model 3. Remediation ‐ When an end‐system is quarantined by the NAC Controller, all web traffic sourced from the quarantined end‐system is redirected to the local Remediation Web Service running on the NAC Controller. The NAC Controller then returns the remediation web page to the noncompliant end‐system. No additional configurations are required on the network because the NAC Controller exists inline with the traffic from quarantined end‐systems. Features and Value In addition to the features and values found in Model 1, Model 2, and Model 3, the following are key pieces of functionality and value propositions supported by Model 4, End‐System Authorization with Assessment and Remediation: Self-Service Remediation If a userʹs PC is suddenly quarantined and the user is not able to access the expected types of services, it is not only important that information of this event is available to IT, but also that the user is directly notified of the cause of service disruption. If they are not notified about the quarantine action, the user will likely believe that there is a network communication problem. Implementing a NAC solution that can quarantine users without notification, may inadvertently increase calls to the IT help desk from users who are not able to access needed services. With the Enterasys NAC solution, network‐based notification and remediation are integrated. Once an end‐system is put into a quarantine state, notification is achieved by redirecting the non‐compliant end‐systemʹs web traffic to a remediation web page. The web page can be maintained by the IT organization and can include details about why the end‐system has been quarantined and how a user can fix issues that are causing the non‐compliant state. The layout ...
Page 37: Required And Optional Components
traffic with specific source and destination characteristics as well as specific application identifiers (UDP/TCP ports). In addition, the Enterasys NAC solution will support an unlimited number of different quarantine policy roles, which means that the solution can support varying degrees of network usage restrictions depending upon the severity of the non‐compliance or security breach. This is different from many other NAC solutions that only offer a VLAN “parking lot” for end‐systems that need to be quarantined. Required and Optional Components This section summarizes the required and optional components for Model 4. Table 2-4 Component Requirements for Authorization with Assessment and Remediation Component NAC Appliance NetSight NAC Manager NetSight Console Assessment Service RADIUS Server NetSight Policy Manager NetSight Inventory Manager The NAC Gateway and NAC Controller are the NAC appliances used to implement the out‐of‐ band and inline network access control functionality on the network.
Page 38: Summary
Summary Summary Enterasys supports all of the five key NAC functions: detection, authentication, assessment, authorization, and remediation. However, not all five functions need to be implemented concurrently in a NAC deployment to derive value from the solution. The four NAC deployment models each yield unique value propositions to the IT personnel managing the network, and provide a logical progression to deploying the full Enterasys NAC solution. The following table summarizes the value and features of each deployment model. Table 2-5 Enterasys NAC Deployment Models Deployment Model Model 1: End-System Detection and Tracking Model 2: End-System Authorization Model 3: End-System Authorization with Assessment Model 4: End-System Authorization with Assessment and Remediation 2-16 NAC Deployment Models Value •...
Page 39: Use Scenarios
This chapter describes four NAC use scenarios that illustrate how the type of NAC deployment is directly dependent on the infrastructure devices deployed in the network. For some network topologies, inline network access control utilizing the NAC Controller may be required while for other network configurations, the NAC Gateway implementing out‐of‐band NAC may be used. The Enterasys NAC solution is capable of implementing network access control for all four use scenarios as well as environments with mixed use scenarios that may require the concurrent deployment of the NAC Gateway and the NAC Controller. Regardless of the scenario that is deployed, all NAC Gateways and NAC Controllers are centrally managed by the NetSight NAC Manager software application. For information about... Scenario 1: Intelligent Wired Access Edge Scenario 2: Intelligent Wireless Access Edge Scenario 3: Non-intelligent Access Edge (Wired and Wireless) Scenario 4: VPN Remote Access Summary For the intelligent wired access edge and intelligent wireless access edge use scenarios, the term “intelligent” refers to a network topology where the access edge is composed of Enterasys policy‐ enabled switches capable of supporting authentication and policy enforcement, or third‐party ...
Page 40: Policy-Enabled Edge
Scenario 1: Intelligent Wired Access Edge within the same Quarantine VLAN because the authorization point is usually implemented at the exit point of the VLAN via Access Control Lists (ACLs). Policy-Enabled Edge The following figure illustrates how the NAC Gateway and the other Enterasys NAC components work together in a network with policy‐enabled edge switches to provide a comprehensive NAC solution. Figure 3-1 Intelligent Wired Access Edge with Enterasys Policy-Enabled Devices Remediation Web Page Matrix/SecureStack Policy Role=Quarantine 3-2 Use Scenarios Enterasys Switch NAC Functions Detect Authenticate Assess Authorize Remediate Enterasys NAC Manager...
Page 41: Rfc 3580 Capable Edge
RFC 3580 Capable Edge In this figure the NAC Gateway and the other Enterasys NAC components provide network access control for a network with third‐party switches that support RFC 3580. Figure 3-2 Intelligent Wired Access Edge with RFC 3580 Capable Devices VLAN=Quarantine VLAN=Production Remediation Web Page 3rd Party Switch (RFC 3850-compliant) NAC Functions Detect Authenticate Assess Authorize Remediate Scenario 1: Intelligent Wired Access Edge Enterasys NAC Manager NAC Gateway...
Page 42: Scenario 1 Implementation
Scenario 1: Intelligent Wired Access Edge Scenario 1 Implementation In the intelligent wired edge use scenario, the five NAC functions are implemented in the following manner: 1. Detection ‐ The userʹs end‐system connects to the network. The edge switch sends a RADIUS authentication request (802.1X, web‐based, or MAC authentication) with the associated credentials to the NAC Gateway. 2. Authentication ‐ If the end‐system is authenticating to the network using 802.1X or web‐based authentication, the NAC Gateway proxies the RADIUS authentication request to a backend authentication (RADIUS) server to validate the identity of the end user/device. For end‐systems that are MAC authenticating to the network, the NAC Gateway can be configured to either proxy the MAC authentication requests to the RADIUS server or locally authorize MAC authentication requests. If only MAC authentication is deployed on the network, and the NAC Gateway is configured to locally authorize MAC authentication requests, a backend RADIUS server is not required for the Enterasys NAC solution. 3. Assessment ‐ After the identity of the end‐system or end user is validated via authentication, the NAC Gateway requests an assessment of the end‐system according to predefined security policy parameters. The assessment can be agent‐based or agent‐less, and is executed locally by the NAC Gatewayʹs assessment functionality and/or remotely by a pool of assessment servers. 4. Authorization ‐ Once authentication and assessment are complete, the NAC Gateway allocates the appropriate network resources to the end‐system based on authentication and/or assessment results. For Enterasys policy‐enabled edge switches, the NAC Gateway formats information in the RADIUS authentication messages that directs the edge switch to dynamically assign a particular policy to the connecting end‐system. For RFC 3580‐capable edge switches, the NAC Gateway formats information in the RADIUS authentication messages (in the form of RFC 3580 VLAN Tunnel attributes) that directs the edge switch to dynamically assign a particular VLAN to the connecting end‐system. If authentication fails and/or the assessment results indicate a noncompliant end‐system, the NAC Gateway can either deny the end‐system access to the network by sending a RADIUS access reject message to the edge switch, or quarantine the end‐ system by assigning a Quarantine policy or VLAN to the end‐system on the edge switch. 5. Remediation ‐ When the quarantined end user opens a web browser to any web site, its traffic is dynamically redirected to a Remediation web page that describes the compliance violations and provides remediations steps for the user to execute in order to achieve compliance. After taking the appropriate remediation steps, the end user clicks on a button on the web page to reattempt ...
Page 43: Scenario 2: Intelligent Wireless Access Edge
Scenario 2: Intelligent Wireless Access Edge intelligent edge on the network. The Matrix N‐series switch is capable of authenticating and authorizing multiple devices connected to a single port for a variety of network topologies, ranging from an IP phone cascaded with a PC on a single Matrix N‐series port, to a stack of non‐ intelligent edge switches uplinked to a single Matrix N‐series port where over 1000 end‐systems connect. In this configuration, the Matrix N‐series acts as the intelligent edge switch on the network, although not physically located at the access edge. Each individual end‐system is authenticated using 802.1X, web‐based, and/or MAC authentication and is subsequently authorized on the Matrix N‐series inter‐switch link to the access edge. By provisioning access to network resources on the Matrix N‐series using MUA, end‐system traffic destined to adjacent switches on the network can be securely contained with policy at the Matrix N‐series port. Scenario 2: Intelligent Wireless Access Edge In the intelligent wireless access edge use scenario, thick Access Points (APs) or wireless switches with thin APs provide authentication and authorization for connecting end‐systems. For this use scenario, the NAC Gateway appliance is deployed for out‐of‐band network access, leveraging the intelligent wireless infrastructure devices as the authorization point for connecting end‐systems. Thin Wireless Edge In a thin wireless deployment, wireless switches tunnel wireless end‐system traffic to and from access points deployed on the network. Most thin wireless deployments are categorized under the intelligent wireless access edge use scenario because the wireless switches are capable of providing authentication (802.1x, web‐based, or MAC) and are also capable of being an authorization point either through dynamic VLAN assignment as specified in RFC 3580 or application of user‐based ACLs or policy. The following figure illustrates how the NAC Gateway and the other Enterasys NAC components work together in a thin wireless deployment. Enterasys NAC Design Guide 3-5...
Page 44: Intelligent Wireless Access Edge - Thin Aps With Wireless Switch
Scenario 2: Intelligent Wireless Access Edge Figure 3-3 Intelligent Wireless Access Edge - Thin APs with Wireless Switch User Laptop VLAN=Quarantine Wireless Access Point VLAN=Production 3-6 Use Scenarios Remediation Web Page Intelligent Wireless Controller (RFC 3850-compliant) NAC Functions Detect Authenticate Assess Authorize Remediate...
Page 45: Thick Wireless Edge
Thick Wireless Edge In a thick wireless deployment, access points forward wireless end‐system traffic directly onto the wired infrastructure without the use of a wireless switch. Thick wireless deployments may or may not be categorized under the intelligent wireless access edge use scenario depending on the functionality supported by the APs. The following figure illustrates how the NAC Gateway and the other Enterasys NAC components provide network access control in a thick wireless deployment. Figure 3-4 Intelligent Wireless Access Edge - Intelligent AP (RFC 3580 Compliant VLAN=Quarantine VLAN=Production Remediation Web Page Wireless Access Point NAC Functions Detect Authenticate Assess Authorize Remediate Scenario 2: Intelligent Wireless Access Edge Enterasys NAC Manager NAC Gateway...
Page 46: Scenario 2 Implementation
Scenario 2: Intelligent Wireless Access Edge Scenario 2 Implementation In the intelligent wireless access edge use scenario, the five NAC functions are implemented in the following manner: 1. Detection ‐ The userʹs end‐system connects to the network. The wireless switch or thick AP sends a RADIUS authentication request (802.1X, web‐based, or MAC authentication) with the associated credentials to the NAC Gateway. 2. Authentication ‐ If the end‐system is authenticating to the network using 802.1X or web‐based authentication, the NAC Gateway proxies the RADIUS authentication request to a backend authentication (RADIUS) server to validate the identity of the end user/device. For end‐systems that are MAC authenticating to the network, the NAC Gateway may be configured to either proxy the MAC authentication requests to the RADIUS server, or locally authorize MAC authentication requests. If only MAC authentication is deployed on the network and the NAC Gateway is configured to locally authorize MAC authentication requests, a backend RADIUS server is not required with the Enterasys NAC solution. 3. Assessment ‐ After the identity of the end‐system or end user is validated via authentication, the NAC Gateway requests an assessment of the end‐system according to predefined security policy parameters. The assessment can be agent‐based or agent‐less, and is executed locally by the NAC Gatewayʹs assessment functionality and/or remotely by a pool of assessment servers. 4. Authorization ‐ Once authentication and assessment are complete, the NAC Gateway allocates the appropriate network resources to the end‐system based on authentication and/or assessment results. For Enterasys policy‐enabled wireless switches and access points, the NAC Gateway formats information in the RADIUS authentication messages that directs the edge switch to dynamically assign a particular policy to the wireless end‐system on the wireless switch or AP, depending on the type of wireless implementation. For RFC 3580‐capable wireless switches and APs, the NAC Gateway formats information in the RADIUS authentication messages (in the form of RFC 3580 VLAN Tunnel attributes) that directs the edge switch to dynamically assign a particular VLAN to the wireless end‐system. If authentication fails and/or the assessment results indicate a noncompliant end‐system, the NAC Gateway can either deny the end‐system access to the network by sending a RADIUS access reject message, or quarantine the end‐system by assigning a Quarantine policy or VLAN to the wireless end‐system. 5. Remediation ‐ When the quarantined end user opens a web browser to any web site, its traffic is dynamically redirected to a Remediation web page that describes the compliance violations and provides remediations steps for the user to execute in order to achieve compliance. After taking ...
Page 47: Scenario 3: Non-Intelligent Access Edge (Wired And Wireless)
Scenario 3: Non-intelligent Access Edge (Wired and Wireless) It is important to note that if the wireless edge of the network is non‐intelligent and not capable of authenticating and authorizing wireless end‐systems, it is possible to augment the network topology to implement out‐of‐band NAC with the NAC Gateway. This can be accomplished without replacing the physical edge of the network, by adding an intelligent edge switch that possesses specialized authentication and authorization features. The Enterasys Matrix N‐series switch is capable of authenticating and authorizing numerous end‐ systems connected on a single port through Multi‐User Authentication (MUA), and may be positioned upstream from non‐intelligent third‐party wireless APs to act as the intelligent edge on the network. The Enterasys Matrix N‐series switch is capable of authenticating and authorizing over 1000 end‐systems uplinked to a single Matrix N‐series port from an AP, a set of APs, or wireless switches. In this configuration, the Matrix N‐series acts as the intelligent edge switch on the network, although not physically located on the access edge. By provisioning access to network resources on the Matrix N‐series via MUA, end‐system traffic destined to adjacent switches on the network can be securely contained at the Matrix N‐series port. Scenario 3: Non-intelligent Access Edge (Wired and Wireless) In the non‐intelligent access edge use scenario, the edge switches and access points that compose the network access layer are not capable of authenticating and authorizing the connecting end‐ systems on the network. In this scenario, inline NAC is implemented by positioning the NAC Controller at a strategic point in the network topology, as the authorization point for end‐system traffic enforcement. The NAC Controller may be positioned directly within the VLAN where end‐systems are connected or across one or more routed boundaries. When the NAC Controller is positioned within the VLAN where end‐systems are connected, each device is uniquely identified by its associated MAC address. When the NAC Controller is positioned across a routed boundary (for example, behind a WAN router located in an enterpriseʹs central site), each end‐system is identified by its associated IP address.
Page 48: Non-Intelligent Access Edge (Wired And Wireless)
Scenario 3: Non-intelligent Access Edge (Wired and Wireless) Figure 3-5 Non-intelligent Access Edge (Wired and Wireless) Layer 3 Wired LAN Remediation Web Page Role=Quarantine Layer 2 Wired LAN Remediation Web Page Role=Quarantine Layer 2 Wireless LAN 3-10 Use Scenarios Enterasys NAC Manager Remediation Web Page...
Page 49: Scenario 3 Implementation
Scenario 4: VPN Remote Access Scenario 3 Implementation In the non‐intelligent access edge use scenario, the five NAC functions are implemented in the following manner: 1. Detection ‐ The userʹs end‐system connects to the network and transmits data traffic onto the network that traverses the NAC Controller. This traffic is sourced from a MAC address or IP address not previously seen by the controller. 2. Authentication ‐ One of two configurations may be implemented on the NAC Controller for end user authentication. Authentication can be disabled altogether, trusting that the downstream infrastructure devices authenticated the end‐system to the network (802.1X authentication to the wireless LAN, web‐based authentication to the wired LAN). Alternatively, MAC registration can be implemented, where an end user username and password and/or sponsor username and password must be validated against a backend LDAP‐compliant database before network access is permitted. 3. Assessment ‐ After the identity of the end‐system or end user is validated by authentication, the NAC Controller requests an assessment of the end‐system according to predefined security policy parameters. The assessment can be agent‐based or agent‐less, and is executed locally by the NAC Controllerʹs assessment functionality and/or remotely by a pool of assessment servers. 4. Authorization ‐ Once authentication and assessment are complete, the NAC Controller allocates the appropriate network resources to the end‐system based on authentication and/or assessment results. This is implemented locally on the NAC Controller by assigning a policy to traffic sourced from this end‐system. If authentication fails and/or the assessment results indicate a noncompliant end‐system, the NAC Controller can either deny the end‐system access to the network or quarantine the end‐system by specifying a particular policy on the NAC Controller. 5. Remediation ‐ When the quarantined end user opens a web browser to any web site, its traffic is dynamically redirected to a Remediation web page that describes the compliance violations and provides remediations steps for the user to execute in order to achieve compliance. After taking the appropriate remediation steps, the end user clicks on a button on the web page to reattempt network access, forcing the re‐assessment of the end‐system. At this point, the Enterasys NAC solution transitions the end‐system through the entire NAC cycle of detection, authentication, assessment, and authorization, re‐assessing the security posture of the end‐system to determine if the remediation techniques were successfully followed. If the end‐system is now compliant, the NAC Controller authorizes the end‐system with the appropriate access policy. If the end‐system is not compliant, the end‐system is restricted access to the network by assigning a policy to the end‐ system on the NAC Controller, and the process starts again.
Page 50: Scenario 4 Implementation
Scenario 4: VPN Remote Access Figure 3-6 VPN Remote Access Remediation Web Page Scenario 4 Implementation In the VPN remote access use scenario, the five NAC functions are implemented in the following manner with the deployment of the NAC Controller for inline network access control. 1. Detection ‐ The userʹs end‐system successfully establishes a VPN tunnel with the VPN concentrator, and the VPN concentrator transmits unencrypted data traffic onto the network that traverses the NAC Controller. This traffic is sourced from an IP address not previously seen by the controller. 2. Authentication ‐ Authentication is most likely disabled altogether on the NAC Controller, trusting that the downstream VPN concentrator authenticated the connecting user. 3. Assessment ‐ The NAC Controller requests an assessment of the end‐system according to predefined security policy parameters. The assessment can be agent‐based or agent‐less, and is executed locally by the NAC Controllerʹs assessment functionality and/or remotely by a pool of assessment servers. 4. Authorization ‐ Once authentication and assessment are complete, the NAC Controller allocates the appropriate network resources to the end‐system based on authentication and/or assessment results. This is implemented locally on the NAC Controller by assigning a policy to traffic sourced from the end‐system. If authentication fails and/or the assessment results indicate a noncompliant end‐system, the NAC Controller can either deny the end‐system access to the network, or quarantine the end‐system by assigning a particular policy on the controller. 3-12 Use Scenarios Enterasys NAC Manager Role=Quarantine (inline appliance) VPN Concentrator...
Page 51: Summary
5. Remediation ‐ When the quarantined end user opens a web browser to any web site, its traffic is dynamically redirected to a Remediation web page that describes the compliance violations and provides remediations steps for the user to execute in order to achieve compliance. After taking the appropriate remediation steps, the end user clicks on a button on the web page to reattempt network access, forcing the re‐assessment of the end‐system. At this point, the Enterasys NAC solution transitions the end‐system through the entire NAC cycle, re‐assessing the security posture of the end‐system to determine if the remediation techniques were successfully followed. If the end‐system is now compliant with network security policy, the NAC Controller authorizes the end‐system with the appropriate access policy. If the end‐system is not compliant, the end‐ system is restricted access to the network by assigning a policy to the end‐system on the NAC Controller, and the process starts again. Summary The decision whether to deploy inline or out‐of‐band network access control depends on the infrastructure devices deployed in your network. For some network topologies, inline NAC utilizing the NAC Controller appliance may be required while for other network configurations, out‐of‐band NAC utilizing the NAC Gateway appliance may be used. The following table summarizes four NAC use scenarios and their NAC appliance requirements. The Enterasys NAC solution is capable of implementing network access control for all four use scenarios as well as environments with mixed use scenarios that may require the concurrent deployment of inline and out‐of‐band NAC. Table 3-1 Use Scenario Summaries Use Scenario Scenario 1: Intelligent wired access edge Scenario 2: Intelligent wireless access edge Scenario 3: Non-intelligent access edge (wired and wireless)
Page 52 Summary Table 3-1 Use Scenario Summaries (continued) Use Scenario Scenario 4: VPN remote access 3-14 Use Scenarios Summary and Appliance Requirements Summary: VPN concentrators act as a termination point for remote access VPN tunnels into the enterprise network. Appliance Requirement: NAC Controller Inline network access control is implemented by deploying the NAC Controller appliance to locally authorize connecting end-systems.
Page 53: Identify The Nac Deployment Model
This chapter describes the steps you should take as you begin planning your NAC deployment. The first step is to identify the deployment model that best meets your business objectives. Then, the current network infrastructure must be evaluated in order to determine NAC component requirements. Based on this evaluation, you will be able to decide whether to deploy inline or out‐ of‐band network access control. For information about... Identify the NAC Deployment Model Survey the Network Identify Inline or Out-of-band NAC Deployment Summary Identify the NAC Deployment Model When planning your NAC deployment, the first step is to identify the NAC deployment model, or a phased implementation of multiple deployment models, that meets your NAC business objectives. The four deployment models are summarized below. For more in depth information on each model, see Chapter • Model #1: End‐System Detection and Tracking Enterasys NAC detects devices as they connect to the network, identifying the location, MAC address, IP address, and username of the person using the end‐system. This information is maintained over time for each device on the network, yielding complete historical information about a device as it interacts with the network. • Model #2: End‐System Authorization Enterasys NAC detects, authenticates, and authorizes connecting end‐systems, to control ...
Page 54: Survey The Network
Survey the Network access to a web browser to safely remediate their quarantined end‐system without impacting IT operations. Once a deployment model is selected, the current network infrastructure must be examined to identify the technical dependencies and requirements imposed by the NAC solution. Survey the Network The steps in this section will help you identify and evaluate the current network infrastructure so that you can make design decisions regarding NAC component requirements. 1. Identify the Intelligent Edge of the Network The first step in surveying your network is to determine whether or not your network has an “intelligent edge.” This information will help you decide whether the NAC Gateway or NAC Controller appliance best suits your network infrastructure. The term “intelligent” refers to a network topology where the access edge is composed of Enterasys policy‐enabled switches capable of supporting authentication and policy enforcement, or third‐party switches capable of supporting authentication and dynamic VLAN assignment as defined in RFC 3580. Non‐intelligent infrastructure devices, such as repeaters and hubs, are not capable of supporting authentication and/or authorization of end‐systems, and simply provide connectivity to the infrastructure. An intelligent edge is required when the NAC Gateway is utilized for implementing out‐of‐band NAC. The NAC Gateway appliance leverages the intelligent edge of the network to implement the authentication and authorization of connecting end‐systems. The NAC Gateway effects the assignment of policies or VLANs on Enterasys switches or RFC 3580‐capable switches located at edge of the network, to authorize a level of network access to connecting end‐systems. These assignments are based on various parameters, such as the location of the end‐system and security posture assessment results. The intelligent edge of the network also implements an authentication method (802.1X, web‐based, or MAC authentication) for validating the device and/or user identity of connecting end‐systems. However, in networks with non‐intelligent devices at the access edge, it is not necessary to replace these non‐intelligent devices to be able to implement out‐of‐band NAC with the NAC Gateway. ...
Page 55: Network With Intelligent Edge
The network shown in Figure 4‐1 below, illustrates the following three examples of how the intelligent edge can be implemented in a network. • Policy‐enabled Enterasys devices at the physical edge of the network. The SecureStack B2/B3, SecureStack C2/C3, and Matrix N‐series switches are the intelligent edge of the network as well as the physical edge of the network. These policy‐enabled devices provide authentication and authorization via policy enforcement to the connecting end‐ systems. • Third‐party switches that support RFC 3580 with dynamic VLAN assignment at the physical edge of the network. RFC 3580‐compliant switches (Enterasys and third‐party), are also part of the intelligent edge of the network, because they are able to authenticate and authorize connecting end‐systems with a particular level of network access, using dynamic VLAN assignment. • Policy‐enabled Enterasys devices at the distribution layer of the network, upstream from non‐intelligent third‐party devices. The intelligent edge of the network may or may not be the physical edge of the network where end‐systems actually connect. The Matrix N‐series switch in the distribution layer of the network, upstream from the non‐intelligent third‐party device, is also considered part of the intelligent edge of the network. This is because the Matrix N‐series switch can individually authenticate and uniquely allocate network resources for the end‐systems connected downstream to the non‐intelligent third‐party access layer device. Figure 4-1 Network with Intelligent Edge Survey the Network Enterasys NAC Design Guide 4-3...
Page 56: Evaluate Policy/Vlan And Authentication Configuration
Survey the Network For the inline implementation of the Enterasys NAC solution, the NAC Controller authenticates and authorizes end‐systems locally on the appliance, and does not rely on the capabilities of downstream infrastructure devices. Because of this, the NAC Controller can be utilized in networks where non‐intelligent and/or intelligent infrastructure devices exist at the edge of the network. If the network does not have an intelligent edge, then the NAC Controller must be deployed in order to provide the authentication and authorization capabilities required for implementing network access control, as shown in Figure Figure 4-2 Network with Non-Intelligent Edge 2. Evaluate Policy/VLAN and Authentication Configuration Note: This step is not necessary if in step 1 you determined that the network does not have an intelligent edge and the inline NAC Controller appliance will be deployed to provide the authentication and policy enforcement capabilities.
Page 57: Case #2: Authentication Methods Are Deployed On The Network
Survey the Network to locally authorize all MAC authentication requests for connecting end‐systems, thereby not requiring a list of known MAC addresses. In fact, Enterasys NAC can be configured in a “learning mode” to dynamically learn the MAC addresses of all devices connecting to the network, permitting network access to all of these end‐systems for a period of time. After the MAC addresses are learned, NAC can be reconfigured to permit access only to these end‐systems, requiring all other devices connecting to the network to go through a registration process. With MAC authentication deployed on the network, a backend RADIUS server with associated directory services is not required, simplifying the implementation. Furthermore, because MAC authentication only requires the end‐system to generate an Ethernet packet onto the network, both human‐centric and machine‐centric end‐systems have the capability to authenticate to the network, regardless of whether the end‐system is a PC or a printer. Case #2: Authentication methods are deployed on the network. If authentication is currently deployed on the network with 802.1X, web‐based, and/or MAC authentication, then a RADIUS server with associated backend directory services must be deployed for user/device 802.1X and web‐based credential validation. Moreover, if RADIUS authentication for switch management logins is implemented, a RADIUS server must be deployed on the network. In this scenario, out‐of‐band NAC is configured to seamlessly proxy RADIUS authentication requests received from the switches at the intelligent edge of the network to the backend RADIUS server, without requiring complex configuration changes to the RADIUS server and associated directory services. In addition, NAC can also be configured to locally authorize MAC authentication requests. Overview of Supported Authentication Methods Following is an overview of authentication methods supported by Enterasys and some third‐party switches, and proxied by out‐of‐band NAC. 802.1X Authentication The IEEE 802.1X standard for port‐based network access control, provides network administrators ...
Page 58 Survey the Network Similar to 802.1X, web‐based authentication requires the input of credentials and is normally used on user‐centric end‐systems that have a concept of an associated user, such as a PC. Therefore, this authentication method is inappropriate for machine‐centric devices such as printers and IP cameras. Note that web‐based authentication is a user‐initiated authentication method where the user must manually begin the network login process by opening a web browser and entering credentials. This user‐initiated method prevents seamless network connectivity because the end user must initiate the reauthentication after assessment is complete. Since Enterasys NAC only acts as a pass‐through to an upstream RADIUS Server, it is mandatory that a full authentication deployment is configured on the network if web‐based authentication is used. MAC Authentication MAC authentication authenticates the source MAC address of an end‐system and grants the appropriate level of access by validating the MAC address on the RADIUS authentication server. This authentication method only requires that the end‐system generate a packet; it requires no special software on the end‐system. Unlike 802.1X and web‐based authentication, MAC authentication can be used to authenticate machine‐centric end‐systems that have no concept of an associated user, such as a printer or IP camera. With this authentication method, Enterasys NAC can act as a pass‐through to an upstream RADIUS Server or can locally authorize MAC authentication attempts. Therefore, if a full authentication deployment has not been configured on the network, MAC authentication should be used. End-System Capabilities When authentication is configured on the network, it is important to consider end‐system capabilities and their ability to interact with the authentication process. Machine‐centric end‐ systems that do not possess an 802.1X supplicant, such as IP cameras and printers, may only be capable of MAC authenticating to the network. Some human‐centric end‐systems such as PCs, may be capable of 802.1X and web‐based authentication while other PCs not installed with an 802.1X supplicant, are only capable of web‐based authentication. If end‐systems are implementing 802.1X and web‐based authentication, Enterasys NAC should leverage these authentication methods for end‐system detection. For end‐systems not implementing 802.1X or web‐based authentication, MAC‐based authentication can be enabled on these switch ports. Support of Multiple Authentication Methods In order to support an enterprise network consisting of a diverse environment of machine‐centric ...
Page 59: Authentication Considerations
system at a time, then it is suggested that MAC locking (also known as Port Security) be enabled on the edge switches to restrict the number of connecting devices. If multiple end‐system connection is supported, then the intelligent edge switch must support the authentication and authorization of multiple devices (possibly using multiple authentication methods) concurrently on the network. If this is not supported, then a security hole exists where a noncompliant end‐ system can “piggyback” on the open network connection of a compliant end‐system. For example, NAC is often deployed on an IP telephony converged network where IP phone handsets are cascaded with PCs connected to a single intelligent edge infrastructure port. If the intelligent edge infrastructure devices do not support the authentication and authorization of both the PC and IP phone connected to the same port, then a noncompliant PC may be allowed network access when the security posture of an IP phone that connected to the network first, is deemed compliant. Furthermore, if the authentication and authorization of multiple devices connecting to a single port is not supported, certain devices may lose connectivity when NAC is deployed. For example, an IP phoneʹs network connection may be lost when a PC is quarantined on the network. Authentication Support on Enterasys Devices Following is information on the authentication support provided by Enterasys devices: • The Matrix N‐series Multi‐User Authentication (MUA) feature allows the enabling of any combination of authentication methods (802.1X, web‐based, and/or MAC) both globally and per port. While the Matrix N‐series Gold supports the authentication and authorization of two users/devices per port, the Matrix N‐series Platinum supports the authentication and authorization of over 2000 users and devices per port, providing the highest degree of authentication method configuration flexibility. • The SecureStack C2/C3 and B2/B3 User + IP Phone authentication allows the configuration of multiple authentication methods globally and per port (802.1X, web‐based, and/or MAC) with the limitation of a PC and an IP phone authenticating on a single port. • The Matrix E1ʹs Hybrid authentication allows the enabling of both 802.1X and MAC authentication on the same port, and supports the authentication of a single end‐system using only one of these authentication methods at a time. • If web‐based authentication is globally enabled on the Matrix E1 and the Matrix E‐series Generation 2/3 platforms, each port on the switch can only be configured to implement web‐ based authentication. Authentication Considerations If authentication is currently deployed on the network, here are considerations that should be ...
Page 60: Identify The Strategic Point For End-System Authorization
Survey the Network authenticated to the network and interact with Enterasys NAC for authentication, assessment, authorization, and remediation. Note however, that this configuration may not be possible if trusted users are also being MAC authenticated to the network in the same Security Domain. In this case, MAC or user overrides would need to be configured for the trusted users, and the default NAC configuration of the Security Domain would specify the NAC implementation for guest users. • If guest access is implemented with web‐based authentication using the guest networking feature on Enterasys policy‐capable switches (supplying default credentials in the web login page for guest users), the guest networking feature must be configured to send the default credentials to a backend RADIUS server and not locally authenticate them. This is because in the out‐of‐band NAC configuration, the NAC Gateway must receive the authentication attempt via RADIUS in order to detect the connecting end‐systems. A RADIUS server with the guest networking credentials must be deployed on the network so the NAC Gateway can proxy the RADIUS requests to the upstream RADIUS server. If a RADIUS Filter‐ID or VLAN Tunnel attribute is not configured for the guest networking credentials on the upstream RADIUS server, Enterasys NAC can be configured to include a Filter‐ID or VLAN Tunnel attribute in the RADIUS Access‐Accept packet returned to the switch by implementing a user override for the guest networking username. 3. Identify the Strategic Point for End-System Authorization In this step, you will identify the strategic point in the network where end‐system authorization should be implemented. The most secure place for implementing authorization is directly at the point of connection at the edge of the network, as supported by Enterasys policy‐capable switches. In this configuration, the implementation of out‐of‐band NAC using the NAC Gateway appliance leverages policy on Enterasys switches to securely authorize connecting end‐systems. RFC 3580‐capable switches can be used for authentication and authorization by assigning end‐ systems to particular VLANs based on the authentication and assessment results. However, this is not as secure as using Enterasys policy‐capable switches, for the two following reasons: • VLANs authorize end‐systems by placing them into the same container, with the traffic ...
Page 61: Identify Network Connection Methods
If the network infrastructure does not contain intelligent devices at the edge or distribution layer, then inline NAC using the NAC Controller as the authorization point for connecting end‐systems must be implemented. This is not as secure as out‐of‐band NAC because the authorization point for end‐systems is located deeper into the network at the NAC Controller. With inline NAC, a quarantined end‐system, while restricted from network access to resources upstream from the NAC Controller, is still able to interact openly with resources and assets on the network downstream from the NAC Controller. However, an advantage of the NAC Controller is that it provides network access control without requiring the upgrade of the access layer or distribution layer of the network. Furthermore, it is important to note that the NAC Controller and NAC Gateway can be deployed concurrently in the network for the simultaneous implementation of inline and out‐of‐band NAC, all centrally managed from the NetSight NAC Manager. The NAC Gateway can be utilized for areas of the network where intelligent switches reside, while the NAC Controller can be positioned inline for segments of the network where non‐intelligent devices exist. If the deployment of out‐of‐band NAC is desired for a network with non‐intelligent access layer devices, the following options should be considered: • Distribution layer infrastructure devices can be strategically upgraded to Enterasys Matrix N‐ Series devices that are capable of individually authenticating and uniquely authorizing multiple devices connected to a single port. Most of the security benefits of out‐of‐band NAC using Enterasys policy can be obtained by implementing authorization at the distribution layer instead of at the port of connection in the access layer. • Access layer infrastructure devices can be upgraded to Enterasys policy‐capable switches or RFC 3580‐capable switches to obtain the security benefits of out‐of‐band NAC. 4. Identify Network Connection Methods The previous steps have been concerned with implementing NAC for the internal LAN. In this step, various types of network connection methods are discussed, along with their impact on NAC deployment. Wired LAN Out‐of‐band or inline NAC can be implemented, depending on the capabilities of the access edge infrastructure devices. Wireless LAN Wireless LAN deployments may be categorized into either thick wireless deployments where access points (APs) operate independently on the network, or thin wireless deployments where ...
Page 62: Remote Access Wan
Survey the Network this case, the thick AP deployment falls into the category of non‐intelligent edge devices with the same NAC implementations as a non‐intelligent wired edge. These non‐intelligent APs must be configured with inline NAC, positioning the NAC Controller at a strategic point in the network upstream from the non‐intelligent APs where it will implement the authentication and authorization of connecting end‐systems. Thin Wireless Deployments For thin wireless deployments, the wireless switch usually supports the authentication and authorization of the wireless end‐systems connected to the APs on the network. Therefore, thin wireless deployments can be configured with out‐of‐band NAC using the NAC Gateway, with the authentication and authorization implemented on the wireless switch. If the wireless switch does not support dynamic VLAN assignment via RFC 3580, inline NAC may be used by positioning the NAC Controller behind the wireless switch to implement the authentication and authorization of wireless end‐systems. Remote Access WAN In many enterprise networks, larger remote sites are connected to the main network site over a WAN connection, affording remote users access to corporate resources. If the remote sites are composed of intelligent edge devices supporting the authentication and authorization of the remotely connected end‐systems, then the NAC Gateway can be utilized in the deployment of out‐of‐band NAC. The NAC Gateway may be positioned either locally at the remote site (which may not be practical) or at the main site of the enterprise network. Either way, the NAC Gateway leverages the authentication and authorization capabilities of the switches in the remote site to implement network access control for remote users. If the NAC Gateway is implemented at the main site, then it is important to consider what impact a WAN link disconnection would have on the NAC process and remote end‐system connectivity. It is recommended that switches in remote sites be configured with a default VLAN or policy that will be applied to the end‐system in the case that connectivity to the main site goes down. If the remote sites are composed of non‐intelligent switches, then the NAC Controller can be strategically positioned inline with traffic sourced from remote end‐systems to implement the authentication and authorization of these devices. The NAC Controller is most often positioned at the central siteʹs WAN connection to the remote sites. In this configuration, the NAC Controller is able to implement NAC for multiple remote sites, which is important when you consider that some remote sites may have only a few end‐systems concurrently connected. Site-to-Site VPN In multi‐site enterprise environments, it is common to have a VPN concentrator located at the ...
Page 63: Remote Access Vpn
Remote Access VPN In many enterprise environments, a VPN concentrator located at the main site connects to the Internet to provide VPN access to remote users. In this scenario, there is no concept of intelligent and non‐intelligent edge switches because the entry point to the main site is the VPN concentrator. In this scenario, the NAC Controller must be used to implement NAC for remote access VPN end‐ systems, and it should be positioned behind the VPN concentrator that provides remote access VPN. Again, reverse proxy VPN or many‐to‐one NAT implemented on a downstream device from the NAC Controller is not supported in the Enterasys NAC solution. Identify Inline or Out-of-band NAC Deployment Based on the NAC deployment model you selected, and the results of your network infrastructure evaluation, you must identify whether out‐of‐band NAC or inline NAC will be deployed in the different areas of your network. With the decision to implement out‐of‐band NAC with the NAC Gateway, and/or inline NAC with the NAC Controller, the next design step is to determine your specific enterprise requirements for the selected NAC solution, and identify the number of NAC appliances, and their location and configuration on the network. Summary The first step when planning your NAC deployment, is to identify the NAC deployment model, or a phased implementation of multiple deployment models, that meets your NAC business objectives. Once you have selected a deployment model, you can use the four following steps to evaluate your current network infrastructure and determine your NAC component requirements. Identify the “intelligent edge” in your network, if it exists. This information will be used to help you select which NAC appliance, the NAC Gateway or NAC Controller, best suits your network infrastructure. An intelligent edge is required when the NAC Gateway is utilized for implementing out‐of‐ band NAC. The NAC Gateway appliance leverages the intelligent edge of the network to implement the authentication and authorization of connecting end‐systems. In networks with non‐intelligent devices at the access edge, it is not necessary to replace these non‐intelligent devices to be able to implement out‐of‐band NAC with the NAC Gateway. Instead, the Enterasys Matrix N‐series switch can be positioned upstream from non‐intelligent devices (such as in the distribution layer) to implement the authentication and authorization functions for downstream connected devices. If the network does not have an intelligent edge, then the NAC Controller must be deployed in order to provide the authentication and authorization capabilities required for implementing network access control.
Page 64 Summary server. In addition, NAC can also be configured to locally authorize MAC authentication requests. Identify the strategic point in the network where end‐system authorization should be implemented. The most secure place for implementing authorization is directly at the point of connection at the edge of the network, as supported by Enterasys policy‐capable switches. In this configuration, the implementation of out‐of‐band NAC using the NAC Gateway appliance leverages policy on Enterasys switches to securely authorize connecting end‐systems. If the network infrastructure does not contain intelligent devices at the edge or distribution layer, then inline NAC using the NAC Controller as the authorization point for connecting end‐systems must be implemented. Identify the network connection types being used. The previous steps have been concerned with implementing NAC for the internal LAN. In this step, the following connection types are discussed along with their impact on the Enterasys NAC solution. – Wired LAN – Wireless LAN – Remote Access WAN – Site‐to‐Site VPN – Remote Access VPN Based on the NAC deployment model you select, and the results of your network infrastructure evaluation, you will be able to identify whether out‐of‐band NAC or inline NAC will be deployed in the different areas of your network. 4-12 Design Planning...
Page 65: Chapter 5: Design Procedures
This chapter describes the design procedures for Enterasys NAC deployment on an enterprise network. The first section discusses procedures for both out‐of‐band and inline NAC deployments. The second section discusses procedures for deployments implementing assessment. Subsequent sections present design steps relating specifically to out‐of band deployments using the NAC Gateway and inline deployments using the NAC Controller. For information about... Procedures for Out-of-Band and Inline NAC Assessment Design Procedures Out-of-Band NAC Design Procedures Inline NAC Design Procedures Additional Considerations Procedures for Out-of-Band and Inline NAC This section presents design procedures that are applicable to both out‐of‐band and inline NAC deployments. 1. Identify Required NetSight Applications As discussed in “NetSight Management” on page 1‐9, the Enterasys NAC solution requires the ...
Page 66: Define Network Security Domains
Procedures for Out-of-Band and Inline NAC Policy Manager is not required for out‐of‐band NAC that utilizes RFC 3580‐compliant switches (Enterasys and third‐party switches). In this case, a VLAN is specified in NAC Manager to authorize connecting end‐systems with a particular level of network access, using dynamic VLAN assignment. Refer to the Enterasys Networks web site http://www.enterasys.com/products/management/ downloads/NetSight.html for NetSight software licensing and download information. 2. Define Network Security Domains A different Security Domain should be defined for each area of the network that has its own unique requirements for end‐system authentication, assessment, and authorization. A Security Domain defines a set of NAC Gateways and NAC Controllers that have common authentication, assessment, and authorization requirements for end‐systems connecting to the network. For NAC Gateways, the domain also includes the associated switches that are uniquely assigned to the gateways. A Security Domain can be composed of both NAC Controller and NAC Gateway appliances. Each NAC Gateway can only be assigned to one Security Domain and therefore all ports on a particular switch (for example, a stack of SecureStack C2 switches or a Matrix N7 chassis) can only be associated to one Security Domain. Likewise, a NAC Controller can only be assigned to one Security Domain. 5-2 Design Procedures...
Page 67: Nac Configurations
Procedures for Out-of-Band and Inline NAC Figure 5-1 Security Domain NAC Configurations Each Security Domain has a default “NAC configuration” that defines the authentication, assessment, and authorization parameters for all end‐systems connecting in that domain. A Security Domain can also include MAC or user override rules that are used to override the NAC configuration parameters with a special NAC configuration to be used for specific end‐systems or end users. Enterasys NAC Design Guide 5-3...
Page 68: Nac Configuration
Procedures for Out-of-Band and Inline NAC Figure 5-2 NAC Configuration Authentication The Authentication settings define how RADIUS requests are handled for authenticating end‐ systems (this does not apply to Layer 3 NAC Controllers.) This includes identifying whether MAC authentication requests are proxied upstream or locally authorized, and whether Filter‐ID and Tunnel RADIUS attributes are added to RADIUS messages during the authentication process. Assessment The Assessment Configuration defines the following requirements for end‐system assessment: • What assessment tests to run. The Assessment Configuration determines what types of assessment tests are executed and what parameters are used. For example, you can specify a Nessus assessment utilizing a specific Nessus configuration file that determines end‐system compliance with the SANS Top 20 vulnerabilities. The same Nessus server can be used to assess Windows machines for Windows‐related vulnerabilities and also assess MAC OS‐based machines for MAC‐related vulnerabilities. In addition, you can specify Nessus as well as other assessment services to jointly determine the security posture of a connecting device. • What resources to use to run the assessment. The Assessment Configuration determines what assessment servers are used to perform the assessment. You can balance the assessment load between all your assessment servers, or you can select a specific assessment server pool to use. For example, assuming Nessus is chosen for assessment, end‐systems connecting to the network in the companyʹs headquarters can be assessed with the Nessus server deployed in the headquarters, while end‐systems in a branch office will be assessed with Nessus servers deployed in the branch office, conserving bandwidth utilization on the network. 5-4 Design Procedures...
Page 69 • How health results are processed. When an assessment is performed on an end‐system, a “health result” is generated. For each health result, there may be several “health result details.” A health result detail is a result for an individual test performed during the assessment. Each health result detail is given a score ranging from 1 to 10, and based on this score, the health result is assigned a risk level. However, it is possible to override the score with a different value that better aligns the score with the enterpriseʹs compliance policy. For example, Wireshark is a popular network traffic analysis application that can be used for both informational and malicious intentions. If IT operations determines that Wireshark is an application that should not be installed on end‐ systems connecting to the network, a scoring override can be configured to associate a high‐ risk score if Wireshark is detected on an end‐system. • Which end‐systems are quarantined. NAC Manager uses risk levels to determine whether or not an end‐system will be quarantined. Based on the scores from the health result details, end‐system are classified into one of four risk levels: high risk, medium risk, low risk, and no risk. Depending on the risk level to which the end‐system is classified, the end‐system may be quarantined. Authorization The NAC configuration also specifies the authorization levels, referred to as “access policies,” that will be applied to the end‐system, depending on the authentication and assessment results. • Accept Policy – the policy that is assigned to compliant end‐systems. • Quarantine Policy– the policy that is assigned to noncompliant end‐systems that have failed assessment. • Assessment Policy – the policy that is (optionally) assigned to end‐systems while they are being assessed. • Failsafe Policy – the policy that is assigned to end‐systems when an error occurs in the NAC process. Procedures for Out-of-Band and Inline NAC Enterasys NAC Design Guide 5-5...
Page 70: Nac Configuration For A Security Domain
Procedures for Out-of-Band and Inline NAC The following figure shows the NAC Manager window used to create or edit a NAC Configuration and define its authentication, assessment, and authorization attributes. Figure 5-3 NAC Configuration for a Security Domain 5-6 Design Procedures...
Page 71: Security Domain Configuration Guidelines
The following table provides examples of various network scenarios that should be considered when identifying the number and configuration of Security Domains in your NAC deployment. Table 5-1 Security Domain Configuration Guidelines Network Scenario Area of the network that is configured to authenticate end- systems with a secure authentication method, such as 802.1X or web-based authentication. Area of the network that is configured to MAC authenticate end-systems solely for the purpose of end-system detection.
Page 72 Procedures for Out-of-Band and Inline NAC Table 5-1 Security Domain Configuration Guidelines (continued) Network Scenario Area of the network that provides access to a group of users or devices that pose a potentially high risk to the security or stability of the network.
Page 73 Table 5-1 Security Domain Configuration Guidelines (continued) Network Scenario Area of the network that is configured to allow access only to specific end-systems or users. Area of the network that provides access to a group of users or devices that pose a guaranteed low risk to the security and stability of the network.
Page 74: Security Domain Configuration Guidelines For Assessment
Procedures for Out-of-Band and Inline NAC The following table provides network scenarios from an assessment standpoint that should be taken into account when identifying the number and configuration of Security Domains. Table 5-2 Security Domain Configuration Guidelines for Assessment Network Scenario Area of the network, or a group of end-systems or users, that require end-system assessment with either the same set of assessment parameters, or a distinct set of parameters different from other areas of the network...
Page 75 Table 5-2 Security Domain Configuration Guidelines for Assessment (continued) Network Scenario Area of the network, or a group of end-systems or users, that require assessment with immediate network access. Area of the network, or group of end-systems or users, that require assessment before network access is allowed.
Page 76: Identify Required Mac And User Overrides
Procedures for Out-of-Band and Inline NAC 3. Identify Required MAC and User Overrides MAC and user overrides are used to handle end‐systems that require a different set of authentication, assessment, and authorization parameters from the rest of the end‐systems in a Security Domain. A MAC or user override can be defined within the scope of a specific Security Domain or all Security Domains. An override scoped to a specific Security Domain lets you specify how an end‐system is authenticated, assessed, and authorized whenever the end‐system connects to the network in that particular Security Domain. A global override lets you specify how an end‐system is authenticated, assessed, and authorized whenever the end‐system connects to any Security Domain on the network. Use the network scenarios and examples provided in this section to determine what MAC and user overrides are required for your NAC deployment. MAC Overrides A MAC override lets you create a configuration for a single end‐system (based on a full MAC address) or for a group of end‐systems (based on a MAC OUI, a MAC OUI Group or a Custom MAC Mask). For example, you could create a MAC override that allocates VoIP services to certain IP phones based on a MAC OUI group. Or, you could deny a specific end‐system by creating a MAC override that quarantines the MAC address of that end‐system and restricts its network access. 5-12 Design Procedures...
Page 77: Mac And User Override Configuration
Procedures for Out-of-Band and Inline NAC The following figure displays the windows used for MAC and user override configuration in NAC Manager. Notice that either an existing NAC Configuration can be used or a custom configuration can be specified for the override. Figure 5-4 MAC and User Override Configuration Enterasys NAC Design Guide 5-13...
Page 78: Mac Override Configuration Guidelines
Procedures for Out-of-Band and Inline NAC The following table describes scenarios where a MAC override may be configured for a particular end‐system. Table 5-3 MAC Override Configuration Guidelines Network Scenario A device, or class of devices, that utilize a distinct set of parameters for authentication, assessment, and authorization. 5-14 Design Procedures Examples Allocating VoIP services to IP phones on the network.
Page 79 Table 5-3 MAC Override Configuration Guidelines (continued) Network Scenario A device or class of devices needs to be restricted network access (“blacklisted”) in a particular Security Domain or in all Security Domains. Examples Denying access or quarantining the MAC addresses of laptops used by guests or contractors in those areas of the network designated to provide access only to trusted employees.
Page 80: User Overrides
Procedures for Out-of-Band and Inline NAC Table 5-3 MAC Override Configuration Guidelines (continued) Network Scenario A device, or class of devices, needs to be permitted a special level of network access (“whitelisted”) in a particular Security Domain or in all Security Domains.
Page 81: Assessment Design Procedures
Manager will not match this end‐system and the end‐system is assigned the Security Domain’s default NAC configuration. In addition, the Layer 3 NAC Controller is not able to determine the username associated to the downstream end‐system for matching against user overrides, and the end‐system is assigned the Security Domain’s default NAC configuration. Assessment Design Procedures The following section provides the design procedures for implementing assessment in your NAC deployment. 1. Determine the Number of Assessment Servers Assessment servers are used to implement assessment functionality in NAC deployments. Use the following parameters to determine the number of required assessment servers for your deployment: • Load‐sharing requirements. More than one assessment server may be required to handle the number of end‐systems being assessed at any one time. The number of end‐systems that can be assessed at the same time and the amount of time required to complete an assessment is determined by the number of vulnerabilities being assessed, throughput limitations on the network, and the hardware specifications of the assessment server machine. Load‐sharing of end‐system assessment is implemented in a round robin fashion between the assessment servers available in the assessment resource pool. • Assessment server redundancy. To provide redundancy, at least two assessment servers should be configured per NAC deployment, with additional assessment servers added for load‐balancing and scalability purposes. The same assessment server can be used for multiple Security Domains, and each assessment server can assess end‐systems using different sets of assessment parameters, depending on the device, user, or location is in the network. Here are some examples: • If guests and other untrusted users are to be assessed for a different set of security vulnerabilities than trusted users, a Security Domain can be associated to the areas of the network where untrusted users connect, and can specify an Assessment Configuration that uses assessment servers configured for the assessment of untrusted users. If trusted users ...
Page 82: Determine Assessment Server Location
Assessment Design Procedures 2. Determine Assessment Server Location When determining the location of the assessment servers on the network, the following factors should be considered: • The type of assessment: agent‐less or agent‐based. Agent‐less assessment consumes more bandwidth than agent‐based assessment during the scan of an end‐system. However, it is important to understand that the amount of bandwidth consumed by agent‐less assessment should only be considered when a large number of end‐ systems are being assessed over a severely bandwidth‐restricted link. For example, if 1000 end‐systems are connected to a branch office over a 512 Kbps connection that is also carrying latency‐sensitive VoIP and other real‐time applications, it is recommended to position an assessment server at the branch office to execute assessment for connecting devices and avoid congestion on the bandwidth restricted link. • End‐system configuration for the associated Security Domain. If agent‐less assessment is implemented and connecting end‐systems are running personal firewalls, the assessment server location may be relevant to the effectiveness of the assessments. For example, Microsoft XP SP2 is enabled by default with a personal firewall that denies all unsolicited inbound connection attempts. Therefore, a Microsoft XP SP2 personal firewall will prevent the successful execution of an end‐system assessment unless the firewall is configured to allow specific types of unsolicited inbound connections, such as from specific IP addresses or over specific protocols as defined in the Exceptions list. This may be configured by the end user via web‐based remediation or through a Windows domain controller group policy definition. 3. Identify Assessment Server Configuration An assessment server utilizes third‐party assessing software to execute scans against connecting end‐systems, and this software must be locally configured with the security assessment parameters. The third‐party assessing software on all assessment servers belonging to the same Security Domain must be configured identically so that consistency is maintained in the assessment of all connecting end‐systems within that domain. The selection of the vulnerabilities ...
Page 83: Out-Of-Band Nac Design Procedures
configuration if the security vulnerability is considered a risk for the organization. For more information on Nessus, refer to http://nessus.org/. Out-of-Band NAC Design Procedures The following section continues the Enterasys NAC design procedure with steps specifically relating to the implementation of out‐of‐band NAC with the NAC Gateway. 1. Identify Network Authentication Configuration Since NAC Gateways utilize authentication for the detection of connecting end‐systems, it is necessary to identify which authentication methods are to be configured in the intelligent edge of the network. For more information on evaluating authentication on the network, see “Survey the Network” (page 4‐2). The following considerations should be taken into account when deploying authentication on the network: • The capabilities of end‐systems connecting to the network. Human‐centric devices may support user‐based authentication methods such as 802.1X or web‐based authentication only if an 802.1X supplicant or a web browser is supported on the end‐system. Machine‐centric devices most likely only support device‐based authentication methods like MAC authentication. • The types of users connecting to the network. It is necessary to understand how authentication affects the different type of users connecting to the network and what implications this has on the NAC solution. For example, while trusted users authenticate using a set of valid credentials held in a directory on the network, untrusted or guest users may fail authentication upon connection. • The complexity involved in deploying authentication on the network, if it is not yet deployed. Rolling out 802.1X authentication on the network requires extensive planning and mandates configuration and possible upgrade of infrastructure devices and end‐systems, and the dissemination of credentials to connecting users and devices. Since this is a significant undertaking, it may be desirable to utilize MAC‐based authentication for the initial rollout of NAC and migrate over to 802.1X over a period of time. This way, most benefits of NAC can be obtained in the short term while the infrastructure is readied for a full 802.1X authentication rollout. ...
Page 84: Determine The Number Of Nac Gateways
Out-of-Band NAC Design Procedures 2. Determine the Number of NAC Gateways The number of NAC Gateways to be deployed on the network is a function of the following parameters: • The number of Security Domains configured on the network. Each NAC Gateway appliance may be associated to only one Security Domain. Therefore, the number of NAC Gateways deployed on the network will be greater than or equal to the number of Security Domains configured in NAC Manager. To support redundancy per Security Domain, at least two NAC Gateways must be deployed per Security Domain, as discussed below. • The number of authenticating users and devices that are connected to each Security Domain. Each NAC Gateway appliance has the capability of supporting a maximum number of authenticating devices as shown in the following table: Table 5-4 End-System Limits for NAC Gateways NAC Gateway Model NSTAG-FE100-TX 7S-NSTAG-01(-NPS) NSTAG-GE250-TX SNS-TAG-LPA SNS-TAG-HPA SNS-TAG-ITA To roughly determine the number of required NAC Gateways per Security Domain, use the ...
Page 85: Nac Gateway Redundancy
Figure 5-5 NAC Gateway Redundancy It is important that the secondary NAC Gateway does not exceed maximum capacity if the primary NAC Gateway fails on the network. For example, let’s say that two NAC Gateways, both running at maximum load on the network, are being used by six switches. NAC Gateway #1 is the primary gateway for switch A, switch B, and switch C, and NAC Gateway #2 is the primary gateway for switch D, switch E, and switch F. In this scenario, NAC Gateway #1 should not be configured to serve as secondary for NAC Gateway #2 and vice versa. This is because if NAC Gateway #1 fails, NAC Gateway #2, which is already running at maximum capacity before NAC Gateway #1ʹs failure, will not be able to handle the end‐systems failing over from NAC Gateway #1. To avoid exceeding these limits, extra NAC Gateway appliances must be deployed on the network to serve as secondary NAC Gateways for these six switches. To summarize, NAC Gateway redundancy may be accomplished using two different approaches: • Active‐standby redundancy In this redundancy approach, a set of switches are configured to use the same primary NAC Gateway (assuming these switches observe the NAC Gatewayʹs capacity limitations previously described) and use the same secondary NAC Gateway as a backup (assuming the secondary NAC Gateway is the same model as the primary). The secondary NAC Gateway is not configured as a primary NAC Gateway for any switch on the network and therefore is inactive until a primary NAC Gateway fails. For example, if switch A, switch B, and switch C use NAC Gateway #1 as a primary gateway, then all three switches can be configured to use NAC Gateway #2 on the network as the backup. In this configuration, if switch A, switch B, or switch C loses connectivity to NAC Gateway #1, the switch would seamlessly transition to using NAC Gateway #2. In the worst‐case scenario where all three switches lose connectivity to NAC Gateway #1, NAC Gateway #2 would be able to handle all authentication requests from these three switches. In this redundancy configuration, NAC Gateway #2 is completely idle on the network and only utilized if one of the switches cannot communicate to NAC Gateway #1. • Active‐active redundancy In this redundancy approach, the primary NAC Gateway for one switch is a secondary NAC Gateway for another switch. For this configuration, the same primary NAC Gateway is utilized for a group of switches, with this NAC Gateway running at only half the maximum load. Another group of switches utilizes a different primary NAC Gateway (assuming it is the same model) also running half the maximum load. Then, each group of switches can use the other NAC Gateway as the secondary gateway. This redundancy configuration guarantees that in the worst‐case scenario, when all switches in one group lose communication to their ...
Page 86: Determine Nac Gateway Location
Out-of-Band NAC Design Procedures primary NAC Gateway, the transition to the secondary NAC Gateway will not exceed maximum capacity. To support redundancy within a Security Domain for either approach, one additional NAC Gateway (of the same model or with increased capacity) must be deployed per Security Domain in addition to the NAC Gateways deployed to handle the maximum number of concurrent end‐ systems connecting to the network. It is important to note that each NAC Gateway can be configured to proxy RADIUS authentication requests to a particular RADIUS server. Therefore, if two switches in the network provide access to 802.1X or web‐based authenticating users, and the credentials for the users connected to each switch are located on different RADIUS servers deployed on the network, then each switch must be configured to use its own NAC Gateway. Each NAC Gateway is then configured to use its respective RADIUS server. For example, an enterprise network that utilizes a particular RADIUS server for the 802.1X authentication of wireless users, would use a different RADIUS server for authenticating wired users. In this case, the same NAC Gateway could not be used for the switch providing wireless access and the switch providing wired access. 3. Determine NAC Gateway Location After determining the number of NAC Gateways required for the NAC deployment, the next step is to determine NAC Gateway location on the network. This is dependent on the NAC deployment model that is implemented on the network. If the NAC deployment does not implement remediation of quarantined end‐systems or MAC (network) registration of new devices on the network, then the NAC Gateways are located in the authentication path of connecting end‐systems as a proxy RADIUS server. This means that the RADIUS client on the access layer switches communicates directly to the NAC Gateway over UDP/IP, and the NAC Gateway in turn communicates to a backend RADIUS server. Therefore, the only requirement for NAC Gateway placement is that a routable IP forwarding path exists between each NAC Gateway and its associated access layer switches. One option is to place all NAC Gateways in the data center, possibly adjacent to the RADIUS servers deployed on the network. Because the end‐system assessment is not directly executed from the NAC Gateways, the choice of the location for the NAC Gateway does not impact the NAC operation, assuming IP connectivity between the access layer switches and the NAC Gateways is maintained. For a branch office deployment of NAC, a NAC Gateway may be installed at the branch office or at the main site. The advantage of the NAC Gateway being installed at the branch office is that ...
Page 87: Identify Backend Radius Server Interaction
It is important to note that only the NAC Gateways that are configured with remediation and registration functionality need to be positioned in such a manner. All other NAC Gateways may be positioned at any location on the network, with the only requirement being that access layer switches are able to communicate to the gateways. Typically, the NAC Gateway with remediation and registration functionality is positioned on a network segment directly connected to the distribution layer routers on the enterprise network, so that any HTTP traffic sourced from quarantined end‐systems that are connected to the networkʹs access layer can be redirected to that NAC Gateway. As an alternative, the NAC Gateway may be positioned on a network segment directly connected to the router providing connectivity to the Internet or internal web server farm. In this scenario, the HTTP traffic sourced from quarantined end‐systems would be redirected to the NAC Gateway before reaching the Internet or internal web servers. 4. Identify Backend RADIUS Server Interaction If a NAC Gateway is receiving 802.1X and/or web‐based authentication requests for connecting end‐systems, then a backend RADIUS server must be configured to validate end user credentials in the authentication process. For each NAC Gateway, a primary and secondary RADIUS server can be specified for the validation of user/device network login credentials on the network. If 802.1X, web‐based, or RADIUS authentication for switch management logins is implemented, a RADIUS server with backend directory services must be deployed on the network. A RADIUS server is not necessary if only MAC authentication is deployed on the network. All RADIUS servers supporting RFC2865 and subsequent RADIUS standards are supported by Enterasys NAC appliances when proxying RADIUS authentication requests. Tests have been conducted on the following RADIUS servers: • FreeRADIUS • Microsoft IAS • Funk Steelbelted RADIUS • Cisco ACS 5. Determine End-System Mobility Restrictions While Security Domain‐specific MAC and user overrides can be configured to control end‐system ...
Page 88: Vlan Configuration
Out-of-Band NAC Design Procedures 6. VLAN Configuration This step is for NAC deployments that use RFC‐3580‐compliant switches in the intelligent edge of the network to implement dynamic VLAN assignment of connecting devices. NAC leverages VLAN Tunnel RADIUS attribute modification in RADIUS authentication messages for network resource allocation to end‐systems connected to these RFC 3580‐compliant switches. This requires that before NAC is deployed on the network, each RFC 3580‐compliant switch in the intelligent edge of the network is configured with the appropriate VLANs that may be returned from the NAC Gateways. A list of VLANs that may be assigned to connecting end‐ systems for each Security Domain must be generated by analyzing the Accept Policy, Assessment Policy, Failsafe Policy, and Quarantine Policy of the following NAC configurations: • The Security Domains’ default NAC configurations • MAC overrides for the Security Domains • User overrides for the Security Domains • Global MAC and user overrides 7. Policy Role Configuration This step is for NAC deployments that use Enterasys policy‐enabled switches in the intelligent edge of the network to implement dynamic policy assignment of connecting devices. NAC leverages Filter‐ID RADIUS attribute modification in RADIUS authentication messages for network resource allocation to end‐systems connected to these Enterasys switches. Therefore, before NAC is deployed on the network, each Enterasys switch in the intelligent edge of the network must be configured with the appropriate policy roles that may be returned from the NAC Gateways. A list of policy roles that may be assigned to connecting end‐systems for each Security Domain can be generated by analyzing the Accept Policy, Assessment Policy, Failsafe Policy, and Quarantine Policy of the following NAC configurations: • The Security Domains’ default NAC configuration • MAC overrides for the Security Domains •...
Page 89: Failsafe Policy And Accept Policy Configuration
previously specified in the NAC configuration must be defined in NetSight Policy Manager to ensure the consistent allocation of network resources to connecting end‐systems. Failsafe Policy and Accept Policy Configuration The Failsafe Policy is assigned to end‐systems when an error occurs in the NAC process. An error state results if the end‐systemʹs IP address could not be determined from its MAC address, or if there was an assessment error and an assessment of the end‐system could not take place. For Enterasys policy‐enabled switches, a corresponding policy role (created in Policy Manager) should allocate a nonrestrictive set of network resources to the connecting end‐system so it can continue its connectivity on the network, even though an error occurred in the NAC process. The Accept Policy is assigned to an end‐system when it has been authorized locally by the NAC Gateway and when an end‐system has passed an assessment (if an assessment was required), or if the Accept Policy has been configured to replace the Filter‐ID information returned in the RADIUS authentication messages. For Enterasys policy‐enabled switches, a corresponding policy role (created in Policy Manager) would allocate the appropriate set of network resources for the end‐system depending on their role in the enterprise. For example, you might associate the Accept Policy to the “Enterprise User” role that is defined in the NetSight Policy Manager demo.pmd file. Assessment Policy and Quarantine Policy Configuration The Assessment Policy and Quarantine Policy are used when end‐system assessment is implemented in the NAC deployment. The policy roles shown in the Policy Manager window below correspond to the access policies used in NAC Manager. For example, the Assessing Policy role in Policy Manager corresponds to the Assessment Policy in NAC Manager. Note that the Administrator, Enterprise User, Enterprise Access, and Guest Access policy roles are also defined in the Policy Manager demo.pmd file. Out-of-Band NAC Design Procedures Enterasys NAC Design Guide 5-25...
Page 90: Policy Role Configuration In Netsight Policy Manager
Out-of-Band NAC Design Procedures Figure 5-6 Policy Role Configuration in NetSight Policy Manager Assessment Policy The Assessment Policy may be used to temporarily allocate a set of network resources to end‐ systems while they are being assessed. For Enterasys policy‐enabled switches, a corresponding policy role (created in Policy Manager) should allocate the appropriate set of network resources needed by the assessment server to successfully complete its end‐system assessment, while restricting the end‐systemʹs access to the network. For example, if the assessment server is configured to scan for FTP vulnerabilities, and the Assessment Policy does not allow FTP traffic from the end‐system onto the network, then the assessment server will not detect the FTP vulnerabilities on the end‐system. To achieve this trade off, the Assessing policy role can be configured by default to deny all traffic, and be associated to classification rules that permit traffic to all assessment servers, using destination IP address Permit classification rules, as shown in Figure 5‐7. Therefore, all traffic involved with the end‐systemʹs assessment is allowed onto the network. In addition, other basic network services such as ARP, DHCP, and DNS are allowed onto the network so the end‐system can establish IP connectivity in the network while being assessed. The Assessment Policy can also be configured to implement web notification during the execution of the assessment, to inform the end user that access to the network has been temporarily restricted while the assessment takes place. This is implemented by allowing HTTP traffic onto the network in addition to the other services previously described. 5-26 Design Procedures...
Page 91: Service For The Assessing Role
Out-of-Band NAC Design Procedures Figure 5-7 Service for the Assessing Role Note that it is not mandatory to assign the Assessment Policy to a connecting end‐system while it is being assessed. NAC can be configured to assign the policy role received from the RADIUS server or the Accept Policy to the end‐system while it is being assessed. In this way, the end‐ system can be granted immediate network access without mandating that the end user wait for assessment to be complete before full network resource allocation is granted. If NAC is configured to return the policy role received from the RADIUS Server, it is necessary that the enterpriseʹs business‐specific policy roles are configured to allow access to the appropriate network resources for communication with the assessment servers during assessment. This can be implemented by associating the Assessing service shown in Figure 5‐7 to all business‐specific policy roles in the NetSight Policy Manager configuration. Quarantine Policy The Quarantine Policy is used to restrict network access to end‐systems that have failed assessment. For Enterasys policy‐enabled switches, a corresponding Quarantine policy role (created in Policy Manager) should deny all traffic by default while permitting access to only required network resources such as basic network services (ARP, DHCP, and DNS). If the NAC deployment implements remediation, the services associated to the Quarantine Policy must be configured to allow all HTTP traffic onto the network, in addition to other basic IP services such as ARP, DNS, and DHCP as shown in Figure 5‐8. Enterasys NAC Design Guide 5-27...
Page 92: Unregistered Policy
Inline NAC Design Procedures Figure 5-8 Service for the Quarantine Role Furthermore, the Quarantine Policy and other network infrastructure devices must be configured to implement HTTP traffic redirection for quarantined end‐systems to return web notification of the quarantined state of an end‐system. Unregistered Policy If MAC (network) registration is configured in the NAC deployment, an “Unregistered” policy can be assigned to connecting end‐systems while they are unregistered on the network. This policy must be configured to allow basic services such as ARP, DNS, DHCP, and to implement HTTP traffic redirection to return web‐based notification for unregistered end‐systems. (Because this configuration is similar to the Quarantine Policy and the Assessment Policy, those policies could be assigned to unregistered end‐systems, if desired). Inline NAC Design Procedures The following section continues the Enterasys NAC design procedure with steps specifically relating to the implementation of inline NAC with the NAC Controller. 1. Determine NAC Controller Location Because the NAC Controller is placed inline with traffic sourced from connecting end‐systems, the location of NAC Controllers is directly dependent on the network topology. NAC Controllers are typically placed between the edge where end‐systems connect to the network (for example, the wired and wireless access edge, or the remote access edge behind a VPN concentrator) and the networkʹs core and data center where mission critical infrastructure resources reside. This way, noncompliant end‐systems can be restricted from communicating to mission critical resources. With the NAC Controller acting as the authorization point for traffic enforcement with inline NAC, there is a fundamental trade‐off when positioning the NAC Controller in the network ...
Page 93 However, the closer the NAC Controller is placed to the edge of the network, the more NAC Controllers are required on the network, increasing NAC deployment cost and complexity. Conversely, when moving the NAC Controller towards the core of the network, fewer NAC Controllers are required, decreasing NAC deployment cost and complexity, but also decreasing the level of security. For implementing NAC on wired and wireless LANs, it is recommended that the Layer 2 NAC Controller is positioned between the access layer and distribution layer before the first routed hop in the network. As an alternative, the NAC Controller may be positioned deeper into the network after the first routed hop using the Layer 3 configuration. The Layer 3 NAC Controller can also be positioned after a VPN concentrator or WAN connection to implement NAC for remote users. Unlike the out‐of‐band NAC design, the implementation of remediation and/or MAC (network) registration does not affect the location of the NAC Controller. The NAC Controller will appropriately intercept web traffic for the purpose of remediation and registration. Lastly, it should be understood that some advantages exist with the deployment of a Layer 2 NAC Controller over a Layer 3 NAC Controller, which may affect the decision of how NAC Controllers are positioned. While a Layer 2 NAC Controller always knows the MAC address of the downstream connected end‐system, the Layer 3 NAC Controller may not be able to determine the MAC address of a downstream end‐system (denoted as “Unknown” in NAC Manager.) Techniques such as NetBIOS lookups and DHCP snooping are implemented to attempt to resolve the IP address of the downstream connected end‐systems; however, scenarios exist where the IP address of the downstream end‐system may not be determined. The MAC address of a downstream end‐system will be determined by the NAC Controller in the following scenarios: • End‐systems support NetBIOS and a host firewall does not drop inbound NetBIOS requests for the LAN connection. • DHCP is implemented and the DHCP server exists upstream from the NAC Controller. Since the Layer 3 NAC Controller may not be able to determine the MAC address of a downstream end‐system, “Lock MAC” and MAC overrides are not applicable to Layer 3 NAC Controllers. Furthermore, MAC (network) registration may not be implemented when the MAC address of a downstream connected end‐system is unknown. In this case, the end‐system is assigned the Security Domain’s default NAC configuration. Inline NAC Design Procedures Enterasys NAC Design Guide 5-29...
Page 94: Determine The Number Of Nac Controllers
Inline NAC Design Procedures 2. Determine the Number of NAC Controllers The number of NAC Controllers to be deployed on the network is a function of the following parameters: • The network topology. Because the NAC Controller is placed inline with traffic sourced from connecting end‐ systems, the number of NAC Controllers required is directly dependent on the network topology. After the location of the NAC Controller is identified from the network topology, the minimum number of NAC Controllers can be determined. • The number of Security Domains configured on the network. Each NAC Controller can be associated to only one Security Domain. Therefore, the number of NAC Controllers deployed on the network will be greater than or equal to the number of Security Domains configured in NAC Manager. To support redundancy per Security Domain, at least two NAC Controllers must be deployed per Security Domain, as discussed below. • The number of users and devices that are connected to each Security Domain. Each NAC Controller appliance has the capability of supporting up to 2000 end‐systems connected downstream as shown in the following table. Table 5-5 End-System Limits for NAC Controllers NAC Controller Model 7S4280-19-SYS 2S4082-25-SYS To identify the minimum number of NAC Controllers required to support inline NAC, use the ...
Page 95: Layer 2 Nac Controller Redundancy
Figure 5-9 Layer 2 NAC Controller Redundancy For a Layer 3 NAC Controller, redundancy is achieved by implementing redundant Layer 3 NAC Controllers on adjacent, but separate networks as shown in Figure Controllers must be in different networks, and a dynamic routing protocol such as OSPF or RIP must be configured between the upstream and downstream routers that are positioned on either side of the NAC Controllers. Redundant Layer 3 NAC Controllers are active‐active, in that traffic from a downstream router may pass through either of the redundant Layer 3 NAC Controllers with equal cost multipath forwarding implemented for the configured dynamic routing protocol. If NAC Controller #1 (PEP or NAC Engine) stops forwarding traffic, the network will automatically converge using the configured routing protocol to forward traffic through NAC Controller #2. Note that the NAC Controllers do not route packets and do not participate in the layer 3 topology. Figure 5-10 Layer 3 NAC Controller Redundancy Inline NAC Design Procedures 5‐10. The NAC Enterasys NAC Design Guide 5-31...
Page 96: Identify Backend Radius Server Interaction
Inline NAC Design Procedures 3. Identify Backend RADIUS Server Interaction Layer 2 NAC Controllers detect downstream end‐systems via authentication: MAC, web‐based, or 802.1X. If web‐based or 802.1X authentication is implemented, then a backend RADIUS server must be configured to validate end user credentials in the authentication process. For each Layer 2 NAC Controller, primary and secondary RADIUS servers may be specified for the validation of user/device network login credentials on the network. 4. Define Policy Configuration Policies are assigned to downstream end‐systems on the NAC Controller to authorize connecting devices with a level of network access. A default set of policies are automatically configured on each NAC Controller after installation and initialization of the appliance. This set of policies includes all policies defined by default in NAC Manager, such as Enterprise User, Quarantine, Assessing, Unregistered, and Failsafe. It is strongly recommended that the policy configurations of all NAC Controllers are imported into NetSight Policy Manager, reviewed, and appropriately modified, prior to the full rollout of inline NAC. Failsafe Policy and Accept Policy Configuration The Failsafe Policy is assigned to end‐systems when an error occurs in the NAC process. The Failsafe policy role is configured by default on the NAC Controller to be used as the Failsafe Policy in NAC Manager. This policy is restrictive, allowing DNS and DHCP, and redirecting web traffic to serve back a web page stating an error has occurred on the network, while discarding all other types of traffic. If it is desired to open network access when an error is encountered, the Enterprise User policy role can be selected as the Failsafe Policy in the NAC Configuration. The Enterprise User policy role is fairly open, permitting most types of communication onto the network. For security purposes the Enterprise User policy role does deny communication to the NAC Controller over ...
Page 97: Unregistered Policy
assessment servers to reach the end‐system while it is being assessed, regardless of whether the Assessing policy, Enterprise User policy, or any other policy role is utilized for assessment. The Quarantine Policy is used to restrict network access to end‐systems that have failed assessment. The Quarantine policy role is configured by default on the NAC Controller to be used as the Quarantine Policy in NAC Manager. This policy is restrictive, allowing DNS and DHCP, and redirecting web traffic to serve back a web page stating the end‐system has been restricted access because it is deemed noncompliant. All other types of traffic are discarded. If it is desired to open network access when an end‐system fails the assessment, the use of the Quarantine Policy can be disabled in the NAC Configuration or the Enterprise User policy role can be selected as the Quarantine Policy. Unregistered Policy If MAC (network) registration is to be configured on Layer 2 NAC Controllers, the Unregistered policy role configured by default on the NAC Controller can be used for the Accept Policy of unregistered devices. This policy is restrictive, allowing DNS and DHCP, and redirecting web traffic to serve back a registration web page stating the end‐system has been restricted access because it has not yet registered. All other types of traffic are discarded. Additional Considerations This section presents additional design considerations for both inline and out‐of‐band NAC deployments. NAC Deployment With an Intrusion Detection System (IDS) NAC deployments that implement end‐system assessment complement networking environments with IDS technologies that detect real‐time security events on the network. While end‐system assessment determines the security posture of connecting devices and mitigates threats posed by vulnerable end‐systems, it does not determine the end userʹs intentions, whether malicious or benevolent. Therefore, IDS technologies can monitor how an end‐system utilizes network resources after NAC has validated the security posture compliance of the end‐system. However, end‐system assessments utilized in NAC may be classified by an IDS (depending on its configuration) as an attack. Therefore, if the traffic from the assessment server traverses a network link that is monitored by an IDS sensor, the IDS must be configured to not generate security events for traffic sourced from the assessment server’s IP address. The same applies for IPS systems. NAC Deployment With NetSight ASM NetSight ASM can be configured to notify the locally installed NAC Manager to dynamically ...
Page 98 Additional Considerations 5-34 Design Procedures...
