Harman 300i Woodburning Fireplace Insert Installation & Operating Manual
Woodburning fireplace insert
Hide thumbs
Also See for 300i Woodburning Fireplace Insert:
- Installation & operating manual (26 pages) ,
- Owner's manual (26 pages)
Table of Contents
Advertisement
Quick Links
NOTICE: SAVE THESE INSTRUCTIONS
model(s):
300i Woodburning Fireplace Insert
Use & Care Video
PlEASE rEAd ThIS ENTIrE mANuAl bEFOrE YOu INSTAll ANd uSE YOur NEw rOOm hEATEr. FAIlurE TO
FOllOw INSTruCTIONS mAY rESulT IN PrOPErTY dAmAgE, bOdIlY INjurY, Or EvEN dEATh.
FOr uSE IN ThE u.S. ANd CANAdA. NOT SuITAblE FOr INSTAllATION IN mObIlE hOmES
IF ThIS APPlIANCE IS NOT PrOPErlY INSTAllEd, A hOuSE FIrE mAY rESulT. FOr YOur SAFETY, FOllOw
INSTAllATION dIrECTIONS.
CONTACT lOCAl buIldINg Or FIrE OFFICIAlS AbOuT rESTrICTIONS ANd INSTAllATION INSPECTION
rEQuIrEmENTS IN YOur ArEA.
CONTACT YOur lOCAl AuThOrITY (SuCh AS muNICIPAl buIldINg dEPArTmENT, FIrE dEPArTmENT, FIrE
PrEvENTION burEAu, ETC.) TO dETErmINE ThE NEEd FOr A PErmIT.
CETTE guIdE d'uTIlISATION EST dISPONIblE EN FrANCAIS. ChEz vOTrE CONCESSIONNAIrE dE hArmAN
hOmE hEATINg.
Installation & Operating manual
Wood Stove
SAFETY NOTICE
SAvE ThESE INSTruCTIONS.
!
hOT SurFACES!
Glass and other surfaces are hot during
operation and cool down.
hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
stove.
• Alert children and adults to hazards of high temperatures.
high temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other flammable
materials away.
To obtain a French translation of this manual, please
contact your dealer or visit www.harmanstoves.com
Pour obtenir une traduction française de ce manuel, s'il
vous plaît contacter votre revendeur ou visitez www.
harmanstoves.com
Contact your local dealer with questions on installation,
operation or service.
WARNING
NOTE
3-90-300101R11_05/14
Advertisement
Table of Contents
Related Manuals for Harman 300i Woodburning Fireplace Insert
Summary of Contents for Harman 300i Woodburning Fireplace Insert
-
Page 1: Safety Notice
IN YOur ArEA. CONTACT YOur lOCAl AuThOrITY (SuCh AS muNICIPAl buIldINg dEPArTmENT, FIrE dEPArTmENT, FIrE PrEvENTION burEAu, ETC.) TO dETErmINE ThE NEEd FOr A PErmIT. CETTE guIdE d'uTIlISATION EST dISPONIblE EN FrANCAIS. ChEz vOTrE CONCESSIONNAIrE dE hArmAN hOmE hEATINg. SAvE ThESE INSTruCTIONS. -
Page 2: Table Of Contents
For Installation In Masonry Fireplace Only Harman 300i Wood Insert Index Specifications ......3 Operation ......5 building a Fire . -
Page 3: Specifications
* heating capacity is a guideline and may differ based on climate, building construction and condition, as well as other variables. Illustrations Not To Scale The Harman 300i meets the U.S. Environmental Protection Agency’s emission limits for wood heaters sold after July 1, 1990. NOT FOr uSE IN mObIlE hOmES. SAFETY NOTICE: IF THIS WOOD INSERT IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. FOR YOUR SAFETY, FOLLOW THE INSTALLATION DIRECTIONS. CONTACT LOCAL bUILDING OR FIRE OFFICIALS AbOUT... - Page 4 Air Control Lever Bypass Damper Control Andirons Surround Side 6.75” 300i Woodburning Fireplace Insert The Safety/ Certification label is attached by a chain under the ash Poêle Du Bois 300i Tests réalisés par OMNI-Test Laboratories, Inc. lip. The label includes the appliance serial number and important Report #/Rapport #135-S-18-6, #135-S-18b-6.2 Serial No.
-
Page 5: Operation
Firedome combustion system, Maintenance section.) and are not recommended for use in harman wood stoves. use of chemical creosote removal products FOr uSE IN ThE u.S. ANd CANAdA will void the warranty of the Firedome combustion system. - Page 6 Harman 300i Wood Insert Operation The Combustion Process Controls Combustion in the Harman 300i is precisely controlled and Two important controls - the damper bypass handle and the is best explained in two parts. air control lever regulate the operation and output of the stove. During a wood fire, combustion air enters at the bottom To open the front loading door, you must open the damper front of the stove where it travels upward through channels bypass, or smoke will spill into the room. In this mode of at either side of the front door. From the manifold located operation the combustion gases go directly from the main above the front door, it is directed into the firebox as a sheet combustion chamber to the flue collar and exit into the of air flowing between the glass and the wood. This concept...
-
Page 7: Building A Fire
Harman 300i Wood Insert Operation Air Control The air control slide is located on the ash lip below the firebox door. Using this lever you will be able to vary the amount of air delivered to the fire, creating a range of heat outputs. The low heat output setting is with the control located all the way to the left. The high setting is with the control located all the way to the right. There are notches cut into the ash lip to provide reference points for consistent adjustments. Do not, under any circumstances, alter the configuration or operation of the air control slide. Air Control shown in the full open position which is to be... - Page 8 Harman 300i Wood Insert Operation Always remember to open the bypass damper when you are medium-high burn rate - air control set between the second loading, this allows the exhaust gases to pass directly into and third notch. This setting may be used to burn wood that is the flue outlet and reduces the chance of smoke spillage damp in order to keep it burning, but will consume seasoned, into the room. dry wood very fast. reloading: Once you have prepared and maintained a thick high burn rate - air control fully to the right. This setting is charcoal bed, and the secondary combustion is established, for refueling and starting a fire. Continuous burning at this you should be able to reload the stove at any time by simply setting will cause premature failure of consumable parts such opening the bypass damper, then the load door, add fuel and as the "FireDome and/or the firebricks. If continuous burning close the door then the damper. Depending on coal bed size, at maximum setting is needed, the appliance is too small for load size and moisture content of fuel, you may need to burn the space you are heating, or the wood fuel is too wet.
-
Page 9: Maintenance
The viewing glass is a specially designed 5 mm ceramic section to guarantee safe and efficient operation. material. If the insert’s glass is cracked or broken, you must replace it before operating your insert. Remove pieces The Insert carefully. Replace the glass only with Harman supplied Surface replacement glass, part # 3-40-06932; do not use substitutes. The insert’s exterior surface should be dusted periodically To replace the glass panel, you will need to remove the door. with a soft cloth. For more thorough cleaning, wait until... -
Page 10: Door Latch
Harman 300i Wood Insert maintenance gaskets The chimney connector and chimney should be inspected at least once every 2 months during the heating season to Gaskets are used at strategic positions for controlling the determine if a creosote buildup has occurred. Checking your path that incoming and outgoing air and gases take through chimney and chimney connector more frequently, especially the insert. You must check these gaskets from time to time, while you are getting used to your insert, is recommended. To and replace them when necessary. You can test the seal inspect this system, let the insert cool. Using a flashlight and by closing the component onto a piece of paper. When... -
Page 11: Installation
For Installation In Masonry Fireplace Only Harman 300i Wood Insert Installation Fireplace / Opening Requirements; Masonry fireplace ONLY. dimension Inches Millimeters Minimum Width 28.5 Minimum Depth Minimum Height* Minimum Hearth Height** Minimum Hearth Depth 12.5 *hEIghT mEASurEmENT dOES NOT ACCOuNT FOr FlOOr PrOTECTION mATErIAl whICh mAY bE NECESSArY. - Page 12 For Installation In Masonry Fireplace Only Harman 300i Wood Insert Floor Protection requirements - cont'd; Installation Flush hearth or raised hearths less Than 6" (152 mm) - The masonry hearth must measure a minimum of 12.5" (318 mm) from the face of the fireplace opening. The insert may not overhang the masonry hearth. For raised hearths less than 6 inches (152 mm) in height, floor protection meeting a minimum 2.02 R-value, must be installed in front of the masonry hearth and may not exceed the height of the masonry. If the masonry hearth is flush with the combustible floor, floor protection must be placed under the insert, extending to the required distance. It is not permissable to place a floor protector in front of the insert base, as it will block the air inlets and create a safety hazard. Floor protection for these examples must be a minimum of R= 2.02 25.5"...
- Page 13 For Installation In Masonry Fireplace Only Harman 300i Wood Insert Installation Surround Installation Standard Surround #1-00-300130 Oversize Surround #1-00-300134 Custom Surround #1-00-300130-SPL The surround is made up of six (6) pieces; • Left Side • Right Side • Top • Top cap • (2) Support brackets The Bottom Hole is Threaded begin by installing the support brackets on each end of the top panel as shown. Notice the bottom hole is the one that is threaded. Next, install the top panel by inserting the four (4) studs through the holes in the fin on the insert. Secure with the...
- Page 14 For Installation In Masonry Fireplace Only Harman 300i Wood Insert Installation dO NOT CONNECT TO ANY AIr dISTrIbuTION duCT Or SYSTEm distribution blowers The blowers are already mounted to the insert for installer convenience. Each blower is secured to the insert body with three screws, as shown. First, make a determination of which side you'll want the power cord coming from. On the determined side, install the short ground wire with ring terminal to the ash lip below and behind the blower, using the green screw and tooth washer from the hardware kit. Notice the high temperature insulated wire pair that runs across the back of the air chamber beneath the insert, and attaches to each blower. This is what links the two blowers together. On the...
- Page 15 For Installation In Masonry Fireplace Only Harman 300i Wood Insert Installation Clearances WARNING Clearance is the empty space required between the insert and the nearest combustible surface or object, such as walls, ceilings, floors, or furniture. Clearance distances may dO NOT INSTAll IN SlEEPINg rOOm. only be reduced by methods listed in the standard CAN/ CSA b365 (Canada) or NFPA 211 (USA). Contact your...
- Page 16 For Installation In Masonry Fireplace Only Harman 300i Wood Insert Installation For direct connect and positive connect installations, ensure masonry Fireplace requirements that the liner is securely connected to the insert flue collar. 1. The chimney must be at least 15 feet high but not more than 33 feet high. 2. This room heater must be connected to; 1) a chimney complying with the requirements for Type HT in the Standard For Chimneys, Factory built, Residential Type, and building Heating Appliance, UL103 or 2) a code approved masonry chimney with a flue liner.
- Page 17 For Installation In Masonry Fireplace Only Harman 300i Wood Insert Installation Installation When installing the insert, you'll need to connect the flue liner to the insert collar with a minimum of three fasteners. The flue adapter is removable for ease of installation in tighter fireplaces. Remove the flue collar from the insert by loosening the two bolts in the top. Attach the flue collar to the liner using three sheetmetal screws. There are two lines etched into the top of the flue collar bracket. These lines should line up with the front of the fireplace opening. Keep the height of the bracket at approximately 24" from the floor. While sliding the insert into the firplace, guide the flue collar bracket onto the top of the insert. The bracket will pull itself into position as the stove body comes back. The bend on the front of the flue bracket, Holes are provided for securing pipe with a and the hooks on the rear will secure the flue collar tightly to minimum of three (3) the insert. When the flue is in its proper position, install the fasteners two bolts down through the bracket to secure it.
-
Page 18: Service Parts
Harman 300i Wood Insert 300i Service Parts beginning manufacturing date: Sept. 2010 wood Insert Ending manufacturing date: Active 1-70-300100-1 (black), Ending manufacturing date: june 2011 1-70-300100-2 (Charcoal), 1-70-300100-3 (goldenfi re)) Part number list on following page. 05/14... - Page 19 Harman 300i Wood Insert 300i Service Parts beginning manufacturing date: Sept. 2010 Ending manufacturing date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked hearth and home Technologies does not sell directly to consumers distributor.
-
Page 20: Firebox Assembly
Harman 300i Wood Insert 300i Service Parts beginning manufacturing date: Sept. 2010 Ending manufacturing date: Active #18 Airslide Assembly #21 Firebox Assembly 21.3 21.2 21.1 18.1 21.4 21.12 18.2 18.3 21.6 21.5 21.11 21.7 21.10 21.9 21.8 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or... - Page 21 Harman 300i Wood Insert 300i Service Parts beginning manufacturing date: Sept. 2010 Ending manufacturing date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked hearth and home Technologies does not sell directly to consumers distributor.
-
Page 22: Warranty
Harman 300i Wood Insert hearth & home Technologies lImITEd lIFETImE wArrANTY Hearth & Home Technologies, on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. wArrANTY COvErAgE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance will be free from defects in materials and workmanship at the time of manufacture. After installation, if covered compo- nents manufactured by HHT are found to be defective in materials or workmanship during the applicable warranty period, HHT will, at its option, repair or replace the covered components. HHT, at its own discretion, may fully discharge all of its obligations under such warranties by replacing the product itself or refunding the verified purchase price of the product itself. The maximum amount recoverable under this warranty is limited to the purchase price of the product. This warranty is subject to conditions, exclusions and limitations as described below. wArrANTY PErIOd: Warranty coverage begins on the date of original purchase. In the case of new home construction, warranty coverage begins on the date of first occupancy of the dwelling or six months after the sale of the product by an independent, authorized HHT dealer/ distributor, whichever occurs earlier. The warranty shall commence no later than 24 months following the date of product shipment from HHT, regardless of the installation or occupancy date. The warranty period for parts and labor for covered components is produced in the following table. The term “Limited Lifetime” in the table below is defined as: 20 years from the beginning date of warranty coverage for gas appliances, and 10 years from the beginning date of warranty coverage for wood, pellet, and coal appliances. These time periods reflect the minimum expected useful lives of the designated components under normal operating conditions. Warranty Period HHT Manufactured Appliances and Venting Components Covered Parts Labor Wood Pellet... - Page 23 Harman 300i Wood Insert wArrANTY CONdITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation. • This warranty is only valid in the country in which the HHT authorized dealer or distributor that sold the appliance resides. • Contact your installing dealer for warranty service. If the installing dealer is unable to provide necessary parts, contact the nearest HHT authorized dealer or supplier. Additional service fees may apply if you are seeking warranty service from a dealer other than the dealer from whom you originally purchased the product. • Check with your dealer in advance for any costs to you when arranging a warranty call. Travel and shipping charges for parts are not covered by this warranty. wArrANTY ExCluSIONS: This warranty does not cover the following: • Changes in surface finishes as a result of normal use. As a heating appliance, some changes in color of interior and exterior surface finishes may occur. This is not a flaw and is not covered under warranty. • Damage to printed, plated, or enameled surfaces caused by fingerprints, accidents, misuse, scratches, melted items, or other external sources and residues left on the plated surfaces from the use of abrasive cleaners or polishes. • Repair or replacement of parts that are subject to normal wear and tear during the warranty period. These parts include: paint, wood, pellet and coal gaskets, firebricks, grates, flame guides, batteries and the discoloration of glass. • Minor expansion, contraction, or movement of certain parts causing noise. These conditions are normal and com- plaints related to this noise are not covered by this warranty. • Damages resulting from: (1) failure to install, operate, or maintain the appliance in accordance with the installation instructions, operating instructions, and listing agent identification label furnished with the appliance; (2) failure to install the appliance in accordance with local building codes; (3) shipping or improper handling; (4) improper opera- tion, abuse, misuse, continued operation with damaged, corroded or failed components, accident, or improperly/ incorrectly performed repairs; (5) environmental conditions, inadequate ventilation, negative pressure, or drafting...
- Page 24 At Harman, we build each product to a standard, not a price. This powerful heating appliance boasts uncompromising attention to detail and helps preserve our planet by using environmentally responsible fuels. (Signature of Boxer) Your premium quality hearth product designed and assembled by the experienced and skilled members at Harman in Halifax, PA, USA.
