INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: SAVE THESE INSTRUCTIONS
Model(s):
P35i-C Pellet Insert
!
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Contact local building or fire officials about restrictions
and installation inspection requirements in your area.
!
Tested and approved for wood pellets only burning of
any other type of fuel voids your warranty. When burning
higher ash content pellets more frequent cleanings may
be required.
1
Installation Manual
Installation and Appliance Setup
CAUTION
CAUTION
Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20
!
Please read this entire manual before
installation and use of this pellet fuel-
burning room heater.
Failure to follow these instructions could
result in property damage, bodily injury
or even death.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not overfire - If any external part starts to glow, you
are overfiring. Reduce feed rate. Overfiring will void
your warranty.
• Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
!
HOT SURFACES!
Glass and other surfaces are hot during
operation and cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
stove.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other flammable
materials away.
NOTE
To obtain a French translation of this manual, please
contact your dealer or visit www.harmanstoves.com
Pour obtenir une traduction française de ce manuel, s'il
vous plaît contacter votre revendeur ou visitez www.
harmanstoves.com
WARNING
WARNING
8390-784i
Advertisement
Table of Contents
Related Manuals for Harman P35i-C
Summary of Contents for Harman P35i-C
- Page 1 When burning Pour obtenir une traduction française de ce manuel, s’il higher ash content pellets more frequent cleanings may vous plaît contacter votre revendeur ou visitez www. be required. harmanstoves.com Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i...
-
Page 2: Table Of Contents
I. Fire Safety ........20 J. Inspect Appliance & Components ....20 Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 3: Installation Standard Work Checklist
Comments: Further description of the issues, who is responsible (Installer/Builder/Other Trades, etc.) and corrective action needed __________________________________________________________________________________________ _________________________________________________________________________________________________ _________________________________________________________________________________________________ Comments communicated to party responsible____________________ by ________________________ on __________ (Builder / Gen Contractor) (Installer) (Date) 04/17 Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 4: Product Specific And Important Safety Information
THE STRUCTURAL INTEGRITY OF THE Harman is a registered trademark of Hearth & Home ® MANUFACTURED HOME FLOOR, WALL, AND Technologies. CEILING/ROOF MUST BE MAINTAINED. DO NOT INSTALL IN SLEEPING ROOM. Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 5: Non-Combustible Materials Specification
This product and the fuels used to operate this product (wood), and the products of combustion of such fuels, can expose you to chemicals including carbon black, which is known to the State of California to cause cancer, and carbon monoxide, which is know to the State of California to cause birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 6: Getting Started
• Insulated exterior chase in cooler climates • Avoid outside wall Windward Leeward Multi-level Roofs Recommended: NOT recommended: Outside Air Intake Outside Air Intake on windward side on leeward side Figure 2.1 Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 7: Tools And Supplies Needed
WARNING RISK OF FIRE OR EXPLOSION! Damaged parts could impair safe operation. DO NOT install damaged, incomplete or substitute components. Keep appliance dry. Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 8: Clearances
Clearances A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. 9-1/4” (235mm) Glass 24” 610mm Standard Surround Oversized Surround #1-00-774221 #1-00-774250 22” 40" (1016 mm) 46" (1168 mm) 559mm 31" (787 mm) 34" (864 mm) 2” 50mm Figure 3.1 Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 9: Clearances To Combustibles & Floor Protection
F Door opening to side Figure 3.2 C. Minimum Opening - Masonry and Manufactured Fireplaces Location Inches Millimeters F Minimum Width G Minimum Depth 14-1/2 H Minimum Height #1-70-774235 23-1/2 H Minimum Height #1-70-774195 19-1/2 Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 10: Termination Location And Vent Information
DO NOT REMOVE BRICKS OR MORTAR FROM THE possibility of condensation. Insulation EXISTING FIREPLACE. alone should not be used to seal the damper opening. For quick and easy installation, purchase the steel Harman Block Off Plate, 1-00-25625. Figure 4.2 Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... - Page 11 12” Min. 36” CAUTION KEEP COMBUSTIBLES (SUCH AS GRASS, LEAVES, ETC.) AT LEAST 3 FEET AWAY FROM THE FLUE 12” min. OUTLET ON THE OUTSIDE OF THE BUILDING. Figure 4.4 Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i...
- Page 12 Figure 4.5 Note: If the Harman® P35i-C Pellet Insert is installed into a factory built wood burning fireplace, this label (Harman® part #3-90-674204) MUST be attached to the altered fireplace. This label is included in the Manufactured fireplace installation kit.
- Page 13 Installing the P35i-C Pellet Insert into a Harman Zero Clearance Cabinet If you don’t have a factory built fireplace or masonry fireplace, the P35i-C Pellet Insert can also be installed into the Harman Zero Clearance Cabinet, Part # 1-00-774235. This is the only permissible way to install the P35i-C Pellet Insert without a suitable fireplace. After the Harman Zero Clearance Cabinet is installed, type PL vent pipe, wall pass-throughs and terminations are used (Note: Flex pipe is not approved these types of installation). Detailed installation instructions are included with the Zero Clearance Cabinet. These same installation instructions can also be found on-line at www.harmanstoves.com. Below are two sample installations using the Harman Zero Clearance Cabinet. Harman Zero Clearance Cabinet Requirements for Terminating the Venting through an Exterior Wall. The clearance to a window or door that may be opened must be a minimum of 48" to the side and 48" below the window/...
-
Page 14: Venting & Use Of Elbows
3 screws at each joint. Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 15: Battery Back-Up Power
Use only Harman® approved battery back-up devices. Note: The UPS provides safe shut-down only. It is not Other products may not operate properly, can create intended for continued operation. unsafe conditions or damage your appliance. Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 16: Outside Air
After adjusting the intake assembly for the flue size, secure the assembly to the top of the chimney with some form of anchors or screws. Masonry Flue Liner Masonry Chimney Figure 4.8 Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 17: Negative Pressure
• Inadequate draft due to environmental conditions • Down drafts • Tight sealing construction of the structure • Mechanical exhausting devices Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... - Page 18 For this reason and the fact that the Lining Systems for New Masonry Chimneys. P35i-C Pellet Insert operates with a positive vent pressure, we specify that the joints also be sealed with silicone. Where passing through an exterior wall or roof, be sure to use the appropriate pass-through device providing an adequate vapor barrier. Venting manufacturers generally provide these pas-through devices. Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i...
-
Page 19: Mobile Home Installation
Roof Flashing 8. Installation shall be in accordance with the Manufacturers Home & Safety Standard (HUD) CFR 3280, Part 24. WARNING Asphyxiation Risk: Joist Shield/Firestop NEVER INSTALL INTO A SLEEPING ROOM Approved Class”L” or “PL” Pellet Vent Consumes oxygen in the room WARNING Installation must comply with Manufactured Home and Safety Standard (HUD), CFR 3280, Part 24 Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 20: Fire Safety
MINIMUM LOW BURN RATE THAT MUST NOT BE ALTERED. IT IS AGAINST FEDERAL REGULATIONS TO ALTER THIS SETTING OR OTHERWISE OPERATE THIS WOOD HEATER IN A MANNER INCONSISTENT WITH OPERATING INSTRUCTIONS IN THIS MANUAL. Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 21: Appliance Setup
Note: Installation out away from the frame. Set unit to the side, Figure 5.3. instructions for the surround are located inside the box with Note: This may take 2 people to achieve. the surround panels. Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 22: Control Board Installation
Figure 5.7. APPLIANCE. DO NOT RUN THE CORD UNDER OR IN FRONT OF THE APPLIANCE. Note: The use of all 4 leveling bolts may not be necessary. Tighten the 1/2" jack bolts against the lintel. Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 23: Installing The Venting
• Sticking out through the punched hole at the lower right corner of the control panel. Note: When installing the room sensor externally, limit the Note: When installed in a rear vent configuration, the maximum distance from the stove to 25 feet or less. BTU may be reduced due to elevated ESP temperatures associated with the horizontal exhaust stream. Figure 5.10 Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 24: Flame Guide Extension
Notice the bend points away from the Heat Exchanger. Heat Exchanger Steel Flame Guide Extension Bends away from heat Exchanger Cast Flame Guide Burn Pot Figure 5.14 Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 25: Firebox Draft And Combustion Fan Rpm
(Note: During this test , the combustion fan will not achieve its top RPM of 3200 due to the density of the ambient air.) All RPM displays could vary +/- 50 from that of the set RPM’s. Allow several minutes for the fan motor to warm up. Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... -
Page 26: Reference Materials
WARNING When installing the Harman® P35i-C Pellet Insert, respect basic safety standards. Read these instructions carefully MOBILE/MANUFACTURED HOME GUIDELINES DO before you attempt to install or operate the P35i-C Pellet NOT ALLOW INSTALLATION IN A SLEEPING ROOM. Insert. Failure to do so may result in damage to property or personal injury and may void the product warranty. Consult with your local building code agency and insurance... -
Page 27: Wiring Diagram
B. Wiring Diagram Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i... - Page 28 352 Mountain House Road, Halifax, PA 17032 www.harmanstoves.com Please contact your Harman dealer with any questions or concerns. ® For the location of your nearest Harman dealer, ® please visit www.harmanstoves.com. Printed in U.S.A Harman® • P35i-C Installation Manual_R2 • 2019 -___ • 02/20 8390-784i...
