INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your local dealer with questions on installation, operation or service.
NOTICE: SAVE THESE INSTRUCTIONS
Model(s):
Accentra52i-TC Pellet Insert
!
Tested and approved for wood pellets only burning of
any other type of fuel voids your warranty. When burning
higher ash content pellets more frequent cleanings may
be required.
!
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Contact local building or fire officials about restrictions
and installation inspection requirements in your area.
1
Owner's Manual
Care and Operation
CAUTION
CAUTION
Harman® • Accentra52i-TC Owner's Manual_R3 • 2017 -___ • 09/17
!
Please read this entire manual before
installation and use of this pellet fuel-
burning room heater.
Failure to follow these instructions could
result in property damage, bodily injury
or even death.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not overfire - If any external part starts to glow, you
are overfiring. Reduce feed rate. Overfiring will void
your warranty.
• Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
!
HOT SURFACES!
Glass and other surfaces are hot during
operation and cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
stove.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other flammable
materials away.
NOTE
To obtain a French translation of this manual, please
contact your dealer or visit www.harmanstoves.com
Pour obtenir une traduction française de ce manuel, s'il
vous plaît contacter votre revendeur ou visitez www.
harmanstoves.com
WARNING
WARNING
3-90-00584c
Advertisement
Table of Contents
Related Manuals for Harman Accentra52i-TC
Summary of Contents for Harman Accentra52i-TC
-
Page 1: Care And Operation
Pour obtenir une traduction française de ce manuel, s’il • Contact local building or fire officials about restrictions vous plaît contacter votre revendeur ou visitez www. and installation inspection requirements in your area. harmanstoves.com Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... - Page 2 LABEL SIZE: 11” x 5.75” PART # / REV: 3-90-00584_R1 ADHESIVE: N/A ORIGINATOR: Spidlet MATERIAL: 24 Gauge Aluminum Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c DATE: 01/17 INK: Screened Black Background (2) Slotted Holes = .156 x .25...
-
Page 3: Table Of Contents
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. • NOTICE: Used to address practices not related to personal injury. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... -
Page 4: Appliance Certification / Specifications
This wood heater needs periodic inspection and repair for proper operation. It is against federal regulations to operate Harman is a registered trademark of Hearth & Home ® this wood heater in a manner inconsistent with operating Technologies. instructions in this manual. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... -
Page 5: Appliance Safety
MINIMUM LOW BURN RATE THAT MUST NOT BE ALTERED. IT IS AGAINST FEDERAL REGULATIONS TO ALTER THIS SETTING OR OTHERWISE OPERATE THIS WOOD HEATER IN A MANNER INCONSISTENT WITH OPERATING INSTRUCTIONS IN THIS MANUAL. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... -
Page 6: Helpful Hints
• Damp pellet fuel could turn back into sawdust which connection to the appliance is necessary. does not flow properly through the feed system. Vent leakage - All interior seams and joints should be sealed with silicone where applicable. Follow vent manufacturers instructions for proper sealing. CAUTION This appliance must be vented to the outside Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... - Page 7 THE STOVE FOR HIGHER HEAT OUTPUT MAY CAUSE DAMAGE TO THE STOVE AND COULD RESULT IN A HOUSE FIRE. USE ONLY APPROVED FUELS AND FOLLOW ONLY THESE OPERATION GUIDELINES. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c...
-
Page 8: Quick Start Guide
H. Quick Start Guide Initial start-up Only 1. Select Language 2. Fill hopper with pellets 3. Adjust arrows to set room desired temperature. 4. Touch the On/Off Power Icon. Refer to Touch Manual for all other operations. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... -
Page 9: Frequently Asked Questions
Ensure holes in burnpot are clear of obstructions above the igniter. See Burnpot Maintenance. Check to see if the ignitor is getting hot, if not replace ignitor. *See addendum for manual ignition instructions for emergency heating needs. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... -
Page 10: Cleaning Prompts, Messages And Errors
Touch Control has lost communication to the stove. Call your Harman Dealer. Exhaust Sensing Probe (ESP) as failed. Clean the ESP. If issue persists, call your Harman Dealer. Clean your stove. Call your Harman Dealer if problem persists. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... -
Page 11: Maintenance And Service
YOU VACUUM THE STOVE. LIVE PELLET EMBERS, IF SUCKED INTO THE VACUUM, WILL LIGHT THE VACUUM • Risk of shock if appliance not unplugged before ON FIRE AND MAY ULTIMATELY CAUSE A HOUSE FIRE. servicing appliance. Follow the detailed instructions found in this section for each step listed in the chart below. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... -
Page 12: Quick Reference Maintenance Chart
4. Yearly cleaning is also known as a Total Clean. This requires completing all the Daily, Weekly, Monthly and Yearly maintenance mentioned. This should be done before you begin burning the unit each heating season. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... -
Page 13: Unit Maintenance
3. Pull downward on the corners of the medallion until the top is released from the retainer that keeps the top aligned when in place. Figure 2.2. Note: The heat exchanger covers will tilt to the front when the center medallion is removed. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... - Page 14 Simply push the allen wrench down through each hole Clean Ash Accumulation ensuring it is clear of any build-up paying attention not to damage the igniter element in the process. Figure 2.6. Figure 2.8 Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c...
-
Page 15: Yearly Maintenance
This gives you access have access to clean the combustion blower chamber area. to the lower combustion chamber. Figure 2.11. Figure 2.13. Cleanout Cover Latch Upper Combustion Chamber Cleanout Combustion Cover Figure 2.10 Figure 2.13 Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... - Page 16 Figure 2.16. Inspect door gasket during cleaning and inspection Replace glass only with high temperature ceramic glass. (4) Glass Clips Open Spring Latch Figure 2.16 (4) 1/4-20 X 1/2” Button Head Screw Glass Gasket Figure 2.14 Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c...
- Page 17 Its is recommend that a certified chimney sweep perform service and inspection to your chimney system to insure your unit is vented safely and in accordance to local code. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c...
-
Page 18: Reference Materials
Ending Manufacturing Date: 20” Hopper: 22” Hopper: 24” Hopper: 1-90-584200-1 (Black) 1-90-584220-1 (Black) 1-90-584240-1 (Black) 1-90-584200-14 (Majolica Brown) 1-90-584220-14 (Majolica Brown) 1-90-584240-14 (Majolica Brown) Part number list on following page. 09/17 Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... - Page 19 Cast Side Panel, Qty 2 req Majolica Brown 1-10-574054-14 Black Paint 4-00-574322P Cast Wing Right Majolica Brown 1-10-574322-14 Burn Pot Weldment See following page Additional service parts on following page. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c...
- Page 20 Hinge Pin Plate w/Hardware 1 Set 1-00-777560 Dowel Pin, 1/4 x 3/4 Pkg of 15 3-30-2015-15 Hopper Lid Latch Release Kit w/Hardware 1-00-584345 Additional service parts on following page. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c...
- Page 21 25.5 Thumb Screw, 1/4-20 x 5/8 Pkg of 10 3-31-782108-10 Restrictor Plate 2-00-574302A Gasket, Burn Pot Qty 2 req 3-44-237639 Flame Guide 3-00-03000 Additional service parts on following page. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c...
- Page 22 Gasket Ultra Air Intake Pkg of 10 3-44-677160-10 33.14 Pellet Air Intake Assembly 1-10-06810A Gasket Feeder Air Intake Pkg of 6 3-44-72224-6 33.15 Additional service parts on following page. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c...
- Page 23 Power Entry Module 3-20-803744 Return Air Sensor 3-20-08780 Room/Return Sensor Extension 14 FT 3-20-584023 Touch Up Paint. Black 12 oz Can 3-42-19905 Touch Up Paint Majolica Brown 1-00-0014 Wiring Harness 3-20-08888 Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c...
-
Page 24: Limited Lifetime Warranty
Firebox and heat exchanger, Grate and Stainless Limited 3 years Steel Burners, FlexBurn® System (engine, inner Lifetime cover,access cover and fireback) 90 Days All replacement parts beyond warranty period 4021-645J • 08-03-17 Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... - Page 25 Consideration must be given to the appliance location and configuration, environmental conditions, insulation and air tightness of the structure. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c...
- Page 26 EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c 4021-645J • 08-03-17...
-
Page 27: Loss Of Power Addendum
• If the fire is still burning, it will resume normal 4. Add firestarter to pellets following manufacturer’s operation. instructions. Contact your dealer if you have questions about UPS 5. Light pellet gel with a match, and close the door, touch compatibility with your appliance. the On/Off icon on the home screen. Operation will begin when the fire reaches the proper temperature. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... -
Page 28: Troubleshooting
• Air-fuel ratio is too rich. - Feed rate too high. - Draft too low caused by a gasket leak. Low heat output • Feed rate too low • Draft too low because of gasket leak. • Poor quality or damp pellets • Combination of 1 and 2. Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c... - Page 29 Harman® • Accentra52i-TC Owner’s Manual_R3 • 2017 -___ • 09/17 3-90-00584c...
-
