Appendix B – Cellular Information

GSM Antenna Requirements/Specifications

Frequency Range
Impedance
VSWR
Typical Radiated Gain
Radiation
Polarization
Antenna Loss
TRP/TIS

PTCRB Requirements for the Antenna

There cannot be any alteration to the authorized antenna system. The antenna system must maintain the same
specifications. The antenna must be the same type, with similar in-band and out-of-band radiation patterns.

Antennas Available from Multi-Tech Systems, Inc.

Part Number Description
Quad Band
ANQB-1HRA Hinged Right Angle 800/900/1800/1900 MHz Cellular Antenna, 7.5"
ANQB-10HRA Hinged Right Angle 800/900/1800/1900 MHz Cellular Antenna, 7.5"
ANQB-50HRA Hinged Right Angle 800/900/1800/1900 MHz Cellular Antenna, 7.5"
Dual Band
ANF1-1HRA Hinged Right Angle 900/1800 MHz Cellular Antenna, 4"
ANF1-10HRA Hinged Right Angle 900/1800 MHz Cellular Antenna, 4"
ANF1-50HRA Hinged Right Angle 900/1800 MHz Cellular Antenna, 4"
ANCF2-1HRA Hinged Right Angle 800/1900 MHz Cellular Antenna, 4"
ANCF2-10HRA Hinged Right Angle 800/1900 MHz Cellular Antenna, 4"
ANCF2-50HRA Hinged Right Angle 800/1900 MHz Cellular Antenna, 4"
Mag Mount Dual Band
ANF1-1MMHW Mag Mount 900/1800 MHz 1/2 Wave Cellular Antenna, 12.5"
ANF1-10MMHW Mag Mount 900/1800 MHz 1/2 Wave Cellular Antenna, 12.5"
ANF1-50MMHW Mag Mount 900/1800 MHz 1/2 Wave Cellular Antenna, 12.5"
ANF1-1MMQW Mag Mount 900/1800 MHz 1/4 Wave Cellular Antenna, 4"
ANF1-10MMQW Mag Mount 900/1800 MHz 1/4 Wave Cellular Antenna, 4"
ANF1-50MMQW Mag Mount 900/1800 MHz 1/4 Wave Cellular Antenna, 4"
ANCF2-1MMHW Mag Mount 850/1900 MHz 1/2 Wave Cellular Antenna, 12.5"
ANCF2-10MMHW Mag Mount 850/1900 MHz 1/2 Wave Cellular Antenna, 12.5"
ANCF2-50MMHW Mag Mount 850/1900 MHz 1/2 Wave Cellular Antenna, 12.5"
ANCF2-1MMQW Mag Mount 850/1900 MHz 1/4 Wave Cellular Antenna, 4"
ANCF2-10MMQW Mag Mount 850/1900 MHz 1/4 Wave Cellular Antenna, 4"
ANCF2-50MMQW Mag Mount 850/1900 MHz 1/4 Wave Cellular Antenna, 4"
MultiModem Cell User Guide
824 – 960 MHz / 1710 – 1990 MHz
50 Ohms
VSWR shall not exceed 2.0:1 at any point across the bands of operation
3 dBi on azimuth plane
Omni-directional
Vertical
Free space not to exceed -3db
Including cable loss the total radiate power (TRP) at the antenna shall be
no less than +22/24.5 dBm for 850/1900 MHz respectively, and the total
isotropic sensitivity (TIS) at the antenna shall be no less than -99/101.5
dBm for 850/1900 MHz respectively.
Quantity
1
10
50
1
10
50
1
10
50
1
10
50
1
10
50
1
10
50
1
10
50
36
