Appendix B – Cellular Information

GSM Antenna Requirements/Specifications

Frequency Range
Impedance
VSWR
Typical Radiated Gain
Radiation
Polarization
Antenna Loss
TRP/TIS

PTCRB Requirements for the Antenna

There cannot be any alteration to the authorized antenna system. The antenna system must maintain the same
specifications. The antenna must be the same type, with similar in-band and out-of-band radiation patterns.

Antennas Available from Multi-Tech Systems, Inc.

Part Number
Quad Band
ANQB-1HRA
ANQB-10HRA
ANQB-50HRA
Dual Band
ANF1-1HRA
ANF1-10HRA
ANF1-50HRA
ANCF2-1HRA
ANCF2-10HRA
ANCF2-50HRA
Mag Mount Dual Band
ANF1-1MMHW
ANF1-10MMHW
ANF1-50MMHW
ANF1-1MMQW
ANF1-10MMQW
ANF1-50MMQW
ANCF2-1MMHW
ANCF2-10MMHW
ANCF2-50MMHW
ANCF2-1MMQW
ANCF2-10MMQW
ANCF2-50MMQW
Multi-Tech Systems, Inc. MultiModem Cell User Guide
824 – 960 MHz / 1710 – 1990 MHz
50 Ohms
VSWR shall not exceed 2.0:1 at any point across the bands of operation
3 dBi on azimuth plane
Omni-directional
Vertical
Free space not to exceed -3db
Including cable loss the total radiate power (TRP) at the antenna shall be
no less than +22/24.5 dBm for 850/1900 MHz respectively, and the total
isotropic sensitivity (TIS) at the antenna shall be no less than -99/101.5
dBm for 850/1900 MHz respectively.
Description
Hinged Right Angle 800/900/1800/1900 MHz Cellular Antenna, 7.5"
Hinged Right Angle 800/900/1800/1900 MHz Cellular Antenna, 7.5"
Hinged Right Angle 800/900/1800/1900 MHz Cellular Antenna, 7.5"
Hinged Right Angle 900/1800 MHz Cellular Antenna, 4"
Hinged Right Angle 900/1800 MHz Cellular Antenna, 4"
Hinged Right Angle 900/1800 MHz Cellular Antenna, 4"
Hinged Right Angle 800/1900 MHz Cellular Antenna, 4"
Hinged Right Angle 800/1900 MHz Cellular Antenna, 4"
Hinged Right Angle 800/1900 MHz Cellular Antenna, 4"
Mag Mount 900/1800 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 900/1800 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 900/1800 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 900/1800 MHz 1/4 Wave Cellular Antenna, 4"
Mag Mount 900/1800 MHz 1/4 Wave Cellular Antenna, 4"
Mag Mount 900/1800 MHz 1/4 Wave Cellular Antenna, 4"
Mag Mount 850/1900 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 850/1900 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 850/1900 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 850/1900 MHz 1/4 Wave Cellular Antenna, 4"
Mag Mount 850/1900 MHz 1/4 Wave Cellular Antenna, 4"
Mag Mount 850/1900 MHz 1/4 Wave Cellular Antenna, 4"
Quantity
1
10
50
1
10
50
1
10
50
1
10
50
1
10
50
1
10
50
1
10
50
