5 STATISTICS
5.1

dns

Description: current dns server ip addresses : ARRAY
Element Type Description
dhcpLease ARRAY array of dns servers issued to dhcp clients with lease
servers ARRAY array of dns servers available for domain name resolution
5.2

gps

Description: statistics and positional information of gps device : OBJECT
Element Type Description
alt STRING altitude
data ARRAY a list of NMEA data strings containing latest gps information
fix STRING fix quality (0=Invalid, 1=GPS fix, 2 = DGPS fix)
lat STRING latitude coordinate
lng STRING longitude coordinate
sats STRING number of satelites
time STRING time
5.3

gre

Description: statistics on gre tunnels (keys are tunnel names) : OBJECT
Element Type
tunnel OBJECT
localIp STRING
mode STRING
remoteIp STRING
rx OBJECT
Mcasts UINT
bytes UINT
csumErrors UINT
errors UINT
outOfSequence UINT
packets UINT
ttl STRING
tx OBJECT
bytes UINT
deadLoop UINT
errors UINT
noBuffs UINT
noRoute UINT
packets UINT
Multi-Tech Systems, Inc. MultiConnect
Description
statistics on ipsec lan interface transmitted bytes
the ip address assigned to this interface
tunnel mode
the ip address of the remote end of this tunnel
statistics on gre tunnel received bytes
number of multicast packets received
number of received bytes
number of packets dropped because of checksum failures
number of received byte errors
number of packets dropped because they arrived out of sequence
number of received packets
time to live (specified in seconds or inherited)
statistics on gre tunnel transmitted bytes
number of transmitted bytes
number of packets which were not transmitted because the tunnel is looped back
to itself
number of transmitted errors
number of packets which were not transmitted because the kernel failed to allo-
cate a buffer
number of packets which were not transmitted because there is no IP route to
the remote endpoint
number of transmitted packets
