Element Type
authentication OBJECT
password STRING
type STRING
username STRING
connectTimeout UINT
dialOnDemand BOOL
diversity BOOL
enabled BOOL
idleTimeout UINT
keepAlive OBJECT
dataRecv OBJECT
enabled BOOL
window UINT
enabled OBJECT
hostname STRING
icmpCount UINT
pingInterval UINT
tcpPort UINT
type STRING
maxRetries UINT
modem OBJECT
apnString STRING
baudRate UINT
commands ARRAY
connectString STRING
dialNumber STRING
dialPrefix STRING
initStrings ARRAY
simPin STRING
nat BOOL
powerOnInitString STRING
wakeUpOnCall OBJECT
ackString STRING
callerIds OBJECT
action STRING
text STRING
type STRING
delay UINT
enabled BOOL
fromLan BOOL
initStrings ARRAY
onCallerId BOOL
onRing BOOL
onSms BOOL
22
Description
PPP authentication settings
password of ppp account
type of authentication to use when connecting to ppp, PAP, CHAP or PAP-CHAP
(default:'PAP-CHAP')
username of ppp account
time in seconds to wait for a connection while in receive mode (default:90)
enable or disable dial on demand : (default:false)
enable or disable antenna diversity (default:true)
enable or disable ppp connection (default:false)
timeout in seconds before connection is considered idle and disconnected (de-
fault:180)
PPP keep alive settings
keep ppp connection alive as long as data is being received
enable or disable data receive monitor (default:false)
time in minutes (default:0)
enable or disable keep alive feature
host to connect to
number of pings to send (default:10)
interval in seconds to send pings (default:60)
port on host to connect to (default:0)
method to use for keep alive, ICMP or TCP (default:ICMP)
maximum number of retries to attempt before failing (default:0)
modem settings
apn connection string from service provider
baud rate of modem (default:115200)
list of at commands to send to modem after successfully connecting
string to send modem on successful connection (default:'CONNECT')
number for modem to dial for connection (default:'*99***1#')
prefix to add to number (default:'ATDT')
list of init strings to send to modem (default:['AT+CSQ'])
pin used to unlock sim for use
enable or disable nat feature (default:true)
string to send to radio on boot up
wake-up on call settings
sequence of characters sent to the cellular modem upon receiving a valid caller
ID
list of valid caller ids for wake-up
action to perform on wake-up
text of wake-up SMS message or caller-id value
type of call: CALLER or SMS
seconds to wait after call before reconnecting (default:10)
enable or disable wake-up on call (default:false)
enable or disable wake-up on lan activity (default:false)
list of cellular radio AT init strings
enable or disable wake-up on caller id (default:false)
enable or disable wake-up on ring (default:false)
enable or disable wake-up on sms (default:false)
