Ir Codes - Gefen 4x4 HDMI Matrix User Manual

In the event of IR confl icts, please do the following:
1. Remove the battery cover from the back of the RMT16-IR remote.
2. Locate the Dip Switches above the batteries
3. Switch the Dip Switches on the RMT16-IR to any of the combinations pictured below.
4. Dip Switches 1 and 2 in the RMT16-IR correspond with Dip Switches 3 and 4 inside
the 4x4 HDMI Matrix respectively. Switch the switches inside the 4x4 HDMI Matrix to
match the same Remote Channel as the RMT16-IR. The 4x4 Matrix is now set to a new
IR Code.
Remote Channel 0:
Remote Channel 2:

IR CODES

Remote Channel 1:
1
2
Remote Channel 3:
1 2
7
1 2
1 2
