Model 8/10 PLUS RS-232 Control

Command/Response Table

Definitions and Abbreviations:
V = Input channel, T = Video Format, M = Maximum # of inputs, Q = Software version
! = Delimiter character = Indicates end of input selection character string.
Characters also accepted as delimiters are: @ $ &
= V value = (Model 8 = 1 - 8, Model 10 = 1 - 10)
= T value = (1 = RGBS, 2 = RGsB, 3 = Composite, 4 = S-Video)
= (8 if Model 8, 10 if Model 10)
ASCII/HEX: 0/30 1/31 2/32 3/33 4/34 5/35 6/36 7/37 8/38 9/39 !/26 E/45 i/69 I/49
M/4D n/6E N/4E Q/51 T/54 V/56
ASCII
Command
i
I
!
n
N
(See Below)
(See Below)
Error Code Descriptions
E01 An attempt to select channel 0 or channels higher than the switcher's M value
of 8 or 10 will cause an E01 error response.
E10 The delimiter character must be entered within three seconds of entering the
channel number, otherwise an error type E10 response will be returned to the
Host.
Example Commands and Responses
Command
8!
10!
I
N
Extron • Model 8 PLUS & Model 10 PLUS Switchers • User's Manual
Response
to Host
(Same as I Below)
V ·T ·M ·Q
V
(Same as N Below)
Nxx-xxx-xx
Possible Error Responses
E01
E10
Response
V8
V10
V2 T4 M8 Q1.23
N60-095-01
· = space
= CR/LF
= 0.00 - 9.99
Command
Description; etc
Information Request
( V, T, M and Q defined above)
Switch to Channel
Request for Part Number
xx-xxx-xx = Part number
Invalid Channel Number
Invalid Command Input
Description
Select input channel 8
Select input channel 10
V2 = Input Channel 2
T4 = S-Video Format
M8 = 8 Inputs (Model 8 PLUS)
Q1.23 = Software Version 1.23
Part Number = 60-095-01
Page 3-2
