Audio Input; Audio Output - Extron electronics P/2 DA2 MT User Manual

CMRR ............................................ >75dB @ 20 Hz to 20 kHz

Audio input

Number/signal type ................... 1 stereo, unbalanced
Connectors ................................... 1 3.5 mm female stereo jack, 2-channel; tip
Impedance .................................... >5 kohms unbalanced, DC coupled
Maximum level ............................ +8.5dBu (unbalanced

Audio output

Number/signal type ................... 1 stereo, balanced/unbalanced
Connectors ................................... 1 3.5 mm captive screw connector, 5 pole
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Maximum level (Hi-Z) ................ >+14dBu, balanced or unbalanced at stated
Maximum level (600 ohm) ......... >+0dBu, balanced or unbalanced at stated
0dBu = 0.775 volts (RMS).
General
Power ............................................ 100VAC to 240VAC , 50/60 Hz, 5 watts,
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
Rack mount .................................. No
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.0" H x 5.7" W x 4.5" D
Product weight ............................. 0.6 lbs (0.3 kg)
Shipping weight ........................... 3 lbs (1.4 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Listings .......................................... UL, CUL
Compliances ................................. CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
Extron Electronics, USA Extron Electronics, Europe
1230 South Lewis Street Beeldschermweg 6C
Anaheim, CA 92805 3821 AH Amersfoort
USA The Netherlands
714.491.1500 +31.33.453.4040
www.extron.com
Fax 714.491.1517 Fax +31.33.453.4050
© 2002 Extron Electronics. All rights reserved.
(L), ring (R), sleeve (GND)
%THD+N
%THD+N
external, autoswitchable; to 9VDC, 1A
power supply.
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
2.5 cm H x 14.5 cm W x 11.4 cm D
Safe Transit Association)
