Technical Specifications
The table below lists the technical specifications for the Presenter liquid
crystal display.
Technical Specifications for the Presenter
Table 3-1
Electro-Optical Pixel resolution
Color resolution
Color gamut
Contrast ratio
Brightness
Response time
Viewing angle
Display surface
Video Interface to
workstation
Audio Interface to
workstation
Output
Control

Technical Specifications

1024 H (x3 RGB stripe) x 768 V
12-bit and 15-bit (12-bit True + 3-bit
Frame Rate Modulation
Red: x = 0.61, y = 0.36;
Green: x = 0.27, y = 0.62
Blue: x = 0.13, y = 0.11
100:1 minimum
2
80 Cd/m minimum
≤50 ms maximum, rise + fall
Horizontal: ±45°;
Vertical: +30°/-10° (optimized for
12:00)
Front: Anti-glare 3H hardcoat
Rear: Clear 3H hardcoat
Adapter board connects to the
video connectors on the graphics
board, generating 24-bit
high-resolution digital video to
drive the flat panel display.
Analog stereo
Stereo, .6 W per channel, 150 Hz to
18 KHz (used with workstation
speaker)
2
I C interface (Phillips bus structure)
to control speaker volume,
backlight brightness, tone, and
stereo balance
