Chapter 3: Maintenance, Technical Specifications and Regulatory Information
.
26
3. Remove the backlight panel, if it's not already removed.
Place Presenter face down on a flat surface.
Press in the latches on either side of the backlight panel, and lift it
up, as shown in Figure 3-1.
Latches
Removing the BackLight Panel
Figure 3-1
4. Use the cloth to wipe the back coated-glass surface gently.
5. Replace the backlight panel.
Tilt the panel and insert the lower edge into the slots on the
Presenter.
Lower the panel over the Presenter, aligning the two catches.
Press down lightly until you hear a click as the catches engage.
