10" COMPOUND MITER SAW
SET UP AND OPERATINg INSTRUCTIONS
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
Distributed exclusively by Harbor Freight Tools
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAl.
Copyright
2004 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
3491 Mission Oaks Blvd., Camarillo, CA 93011
91995
. All rights reserved. No portion of this
®
.
®
Revised 07k

Advertisement

Table of Contents
loading

Related Manuals for Chicago Electric 91995

Summary of Contents for Chicago Electric 91995

  • Page 1 10” COMPOUND MITER SAW Model 91995 SET UP AND OPERATINg INSTRUCTIONS Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. Distributed exclusively by Harbor Freight Tools ®...

  • Page 2: Specifications

    Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools create sparks which may ignite flammables. Rev 07k SKU 91995 For technical questions, please call 1-800-444-3353. Page 2...

  • Page 3: Electrical Safety

    Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. SKU 91995 For technical questions, please call 1-800-444-3353. Page 3...

  • Page 4: Tool Use And Care

    Many accidents are caused by poorly maintained tools. Use only accessories that are recommended by the manufacturer for your model. Accessories that may be suitable for one tool may become hazardous when used on another tool. SKU 91995 For technical questions, please call 1-800-444-3353. Page 4...

  • Page 5: Specific Safety Rules

    10”, an RPM rating of at least 7000, and has an arbor hole of 5/8” diameter. To avoid accidental injury, always wear heavy duty work gloves when changing a Saw Blade. Rev 07k SKU 91995 For technical questions, please call 1-800-444-3353. Page 5...
  • Page 6 Saw Blades produce a narrow kerf causing excessive friction, Saw Blade binding and kickback. Make sure all Saw adjustments are tight and secure before making a cut. If Saw adjustments shift while cutting, it may cause binding and kickback. SKU 91995 For technical questions, please call 1-800-444-3353. Page ...
  • Page 7 Do not use this product if under the influence of alcohol or drugs. Read warning labels on prescriptions to determine if your judgement or reflexes are impaired while taking drugs. If there is any doubt, do not attempt to use this product. SKU 91995 For technical questions, please call 1-800-444-3353. Page ...
  • Page 8 The operator must understand that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. SAVE THESE INSTRUCTIONS SKU 91995 For technical questions, please call 1-800-444-3353. Page ...

  • Page 9: Extension Cords

    As the distance from the supply outlet increases, you must use a heavier gauge extension cord. Using extension cords with inadequately sized wire causes a serious drop in voltage, resulting in loss of power and possible tool damage. (See Table A.) SKU 91995 For technical questions, please call 1-800-444-3353. Page 9...
  • Page 10 * Based on limiting the line voltage drop to five volts at 150% of the rated amperes. Symbology Double Insulated Volts Alternating Current Canadian Standards Association Amperes No Load Revolutions per Minute n 0 xxxx/min. Underwriters Laboratories, Inc. (RPM) SKU 91995 For technical questions, please call 1-800-444-3353. Page 10...
  • Page 11 Pin (2). Raise and hold the Cover Case (9) of the Miter Saw fully upward. Turn the Cross Pin 90 degrees. Then, insert the Cross Pin into the deep slot in its locked position. (See Figures E and F, next page.) Rev 07k SKU 91995 For technical questions, please call 1-800-444-3353. Page 11...
  • Page 12 The Cross Pin allows the operator to lock the Saw Blade in position, preventing the Saw Blade from being raised or lowered. (See Figures E and F.) CROSS PIN (28) FIgURE E SAW BlADE (56) IN “lOCKED UP” POSITION FIgURE F SKU 91995 For technical questions, please call 1-800-444-3353. Page 12...

  • Page 13: Spindle Lock

    BOlT (50) WRENCH (110) SAFETY COVER (53) FIgURE g Depress the Spindle Lock (4) to keep the Saw Blade (5) from turning. (See Figure H.) SPINDlE lOCK (84) FIgURE H SKU 91995 For technical questions, please call 1-800-444-3353. Page 13...
  • Page 14 CAUTION! Make sure to pull out on the Cross Pin (28). Turn the Cross Pin 90 degrees. Then, insert the Cross Pin into the shallow slot in its unlocked position. NEVER use the Cross Pin in any cutting operation. (See Figure E.) SKU 91995 For technical questions, please call 1-800-444-3353. Page 14...

  • Page 15: Clamp Assembly

    Do not disconnect or remove the Safety Cover (53). Do not operate the Miter Saw if the Safety Cover is damaged or missing. (See Figure l.) If the transparent Safety Cover (53) becomes so dirty that the Saw Blade (5) SKU 91995 For technical questions, please call 1-800-444-3353. Page 15...
  • Page 16 Do not operate the Miter Saw if the Power Switch is not operating properly. To turn on the Miter Saw, simply squeeze the Power Switch. To turn off the tool, release pressure on the Power Switch. (See Figure M.) POWER SWITCH (98) FIgURE M SKU 91995 For technical questions, please call 1-800-444-3353. Page 1...
  • Page 17 After adjusting the Screw (92), press down on the Miter Saw and make sure the Saw Blade (5) does not contact the bottom of the Table (1) or any other part of the Saw Base (). (See Figure O.) SKU 91995 For technical questions, please call 1-800-444-3353. Page 1...
  • Page 18 (See Figure O.) To Adust The Bevel Of Cut: WARNINg! Prior to performing this procedure, make sure the Power Cord (102) of the Miter Saw is unplugged from its electrical outlet. SKU 91995 For technical questions, please call 1-800-444-3353. Page 1...
  • Page 19 Check to make sure the Power Switch (9) is operating properly. Place the workpiece on the Table (1) and against the Guide Fence (3). Use the Clamp Assembly (3) to hold the workpiece in place. SKU 91995 For technical questions, please call 1-800-444-3353. Page 19...

  • Page 20: Inspection, Maintenance, And Cleaning

    If abnormal noise or vibration occurs, have the problem corrected before further use. Do not use damaged equipment. Never work with a dull saw blade. SKU 91995 For technical questions, please call 1-800-444-3353. Page 20...

  • Page 21: Please Read The Following Carefully

    AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 91995 For technical questions, please call 1-800-444-3353. Page 21...

  • Page 22: Parts List

    Screw Safety Cover Screw Spring Gasket Plate Screw Wrench (Not Shown) NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 91995 For technical questions, please call 1-800-444-3353. Page 22...

  • Page 23: Assembly Diagram

    ASSEMBlY DIAgRAM 110: WRENCH NOT SHOWN. NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 91995 For technical questions, please call 1-800-444-3353. Page 23...
