Section 3 –

Using the Thermostat

Outdoor Temperature

Press the cycle button once to view the outdoor
temperature. The LCD shows both the outside temperature
and the outdoor temperature icon as shown in Figure 3-1.
Figure 3-1: Outdoor Temperature Icon
Viewing the Room
Temperature Setpoint
The thermostat displays the current room temperature
while static or while no button is pressed. The display
returns to the current room temperature after five seconds
of the last button press.
Changing the Room
Temperature Setpoint
The room temperature setpoint is the target temperature
for the room that the thermostat controls. When viewing
the room temperature on the display, use the (+) or (–)
buttons to change the room temperature setpoint.
• Press the (+) button to increase the room temperature
setpoint by 1.0°F or 0.5°C degree increments
depending on the temperature units displayed.
• Press the (–) button to decrease the room temperature
setpoint by 1.0°F or 0.5°C degree increments
depending on the temperature units displayed.
Uponor Climate Co ˘ ntrol™ Network System Thermostat User Manual
Viewing the Slab Temperature
Note: The slab temperature readings and settings are only
available if the slab sensor is installed.
The slab temperature is the current temperature of the
radiant panel. This temperature is viewable for radiant
heating and/or radiant cooling.
To view the slab temperature, press the cycle button three
times or until the display shows the slab icon blinking.
The display now shows the temperature of the slab.
Figure 3-2: Slab Temperature Icon
Changing the Slab
Temperature Setpoint
Note: Slab temperature readings and settings are only
available if the slab sensor is installed.
The slab temperature setpoint is the target temperature
of the radiant panel. To change the slab temperature
setpoint, use the following procedure:
• Press the cycle button three times or until the
blinking slab icon appears.
• Press the (+) button to increase the slab temperature
setpoint by 1°F or 0.5°C degree increments depending
on the temperature units displayed. Press the (–)
button to decrease the slab temperature setpoint by
1°F or 0.5°C degree increments depending on the
temperature units displayed.
7
