- Page 1 C O ˘ N T R O L ™ N E T W O R K S Y S T E M T H E R M O S T A T INSTALLATION AND OPERATION GUIDE Uponor Climate Co ˘ ntrol Network System ™ Thermostat Installation and Operation Guide...
- Page 2 Uponor Climate Co ˘ntrol Network™ System Thermostat Installation and Operation Guide Published by Uponor 5925 148th Street West Apple Valley, MN 55124 USA Phone: (800) 321-4739 Fax: (952) 891-1409 Uponor, Ltd. 655 Park Street Regina, SK S4N 5N1 CANADA Phone: (888) 994-7726 Fax: (800) 638-9517 www.uponor-usa.com...
-
Page 3: Table Of Contents
Viewing the Thermostat Software Revision ....15 Section 4 ....17 — Wiring Diagram Uponor Climate Co ˘ ntrol™ Network System Thermostat Installation and Operation Guide... - Page 4 • www.uponor.ca...
-
Page 5: Uponor Climate Co ˘Ntrol
• Flush-mount skin • Mounting wings • #4 screws (for attaching the mounting wings to the case) Flush Mount Horizontal • User manual (A9010530) Table 1-1: Thermostat Package Contents Uponor Climate Co ˘ ntrol™ Network System Thermostat Installation and Operation Guide... - Page 6 • www.uponor.ca...
-
Page 7: Installation Methods
2. Place case back on the wall and on the case back. mark areas for the screw and connector holes with a pencil. Figure 2-3: Case back of Figure 2-6: Mount thermostat procedure thermostat procedure Uponor Climate Co ˘ ntrol™ Network System Thermostat Installation and Operation Guide... -
Page 8: Flush Mount
7. Turn the wing screws slowly. Initially, the wings will turn 90 degrees behind the drywall. As you continue tightening, they will Figure 2-8: Flush secure the thermostat in place. mount thermostat Important: Do not overly tighten the wings. www.uponor-usa.com • www.uponor.ca... -
Page 9: Wiring Thermostat
(wood, color. Use the red wire to concrete, gypcrete, etc.). connect the positive terminal on the thermostat to the positive terminal on the controller. Uponor Climate Co ˘ ntrol™ Network System Thermostat Installation and Operation Guide... - Page 10 • www.uponor.ca...
-
Page 11: Operation
2. Press cycle twice. The display shown in Figure 3-2. Secondary will look like this: heating and primary heating will show the same options on the thermostat. Uponor Climate Co ˘ ntrol™ Network System Thermostat Installation and Operation Guide... -
Page 12: Setting The Radiant Heating Water Temperature Channel
Figure 3-6 2. Press cycle seven times. The display will look like this: 3. Use the + and − buttons to toggle between the different valves (0 to 16, with 0 indicating no zone valve). www.uponor-usa.com • www.uponor.ca... -
Page 13: Setting The Air Water Zone Pump
3. Use the + and − buttons to toggle between the different air handler numbers (0 to 4, with 0 indicating no air handler used). Uponor Climate Co ˘ ntrol™ Network System Thermostat Installation and Operation Guide... -
Page 14: Setting The Heat Recovery Ventiliator (Hrv) Number
2. Press cycle 13 times. The display the following procedure. will look like this: 1. Press both the mode and cycle buttons at the same time. 2. Press cycle 16 times. The display will look like this: Figure 3-15 www.uponor-usa.com • www.uponor.ca... -
Page 15: Setting The Temperature Offset
2. Press cycle 17 times. The display will look like this: Figure 3-18 3. Use the + and − buttons to toggle between the different temperature offsets (-9.9 to 9.9). Uponor Climate Co ˘ ntrol™ Network System Thermostat Installation and Operation Guide... - Page 16 • www.uponor.ca...
-
Page 17: Wiring Diagram
