Using The Handset Administration Tool - Polycom SpectraLink 6020 Administration Manual

Using the Handset Administration
Tool
PN: 1725-36094-001_C.doc
The Handset Administration Tool uses indicators to alert you to the
status of the action being performed.
• Green – the adjacent label is "true" and this state is desirable or
required.
• Yellow – the adjacent label is "true" and this state requires caution
or attention. For example, a yellow
that the file path will be created. A yellow
cautions that the file will be overwritten.
• Red – the adjacent label is "true" and this state is undesirable or is
accompanied by an error (in which case a message on the prompt
line or a dialog box will describe the nature of the error).
• Gray – the adjacent label is not "true". E.g. the handset is not
connected.
• Blinking – file status indicators blink yellow when the file status is
being queried but is not yet known (for example: when attempting
to access slow drives or unresponsive network devices). File status
indicators blink red when the path is invalid (mistyped). The
indicator blinks when the handset's password needs to be
Handset
entered.
A prompt line at the bottom of the window provides information
about what action should be taken or the status of the utility.
indicator cautions
New folder
indicator
File exists
