Handset Administration Tool
Installation

Installing the USB Driver

PN: 1725-36094-001_C.doc
The Handset Administration Tool is a software utility for
downloading software updates to the handset and for configuration
of the handset. This utility is installed on a PC with a USB port that
can be cabled to the USB port of the Dual Charger. It is designed as a
time-saving device for rapid administration and configuration of a
number of handsets. Configuration options include:
• Change the password or disable password protection
• Assist troubleshooting by recording error information
• Upgrade handset software
Necessary components:
• PC running Windows 2000 or Windows XP with a USB port
• Dual Charger for the SpectraLink 6020 Wireless Telephone
• Power supply for the appropriate country or region
• SpectraLink USB cable or comparable cable (with 5-pin "mini-B"
connector)
1. Set up a folder for SpectraLink 6020 Wireless Telephone
configuration on the PC and download the programming software
from the Polycom website
softwareUpdates
the zip file. The zip file from the website will contain the
file.
If retrieving files from the Polycom Installation Manuals CD, the files
are available as two separate links on the Administration Software
page.
http://www.spectralink.com/
into this folder. Extract the individual files from
3
USB.zip
11
