Multitech MultiModem II MT5600BA-V92 User Manual page 8

Receiver Sensitivity
AGC Dynamic Range
Connectors
Cables
Indicators
Speaker
Manual Controls
Operating
Temperature*
Humidity Range
Storage Temperature
Power Requirement
Power Supply
Requirement:
Dimensions
Weight
Limited Warranty
Certifications
Intelligent Features
* UL Listed @ 40° C. Limited by power supply. UL Certification does not apply or extend to an ambient
above 40° C and has not been evaluated by UL for ambient greater than 40° C.
Multi-Tech Systems, Inc. MT5600BA-V92 User Guide
-43 dBm under worst-case conditions
33 dB
One DB25F (RS-232C/D) connector; three RJ-11s
Three modular telephone cords (USA); country- or region-specific cordage for
International models; one 9-pin to 25-pin serial cable for International
models; external power transformer
Note: Any cables connected to the computer should be shielded to reduce
interference.
32-character backlit LCD for status and configuration information; LEDs for
Transmit Data, Receive Data, Carrier Detect, Off Hook, Terminal Ready, and
Test Mode
1-inch speaker for call progress monitoring
Power switch, speaker volume control, four LCD control buttons
32°–120° F (0°–50° C) ambient under closed conditions
UL Listed at 40°C
25–85% (non-condensing)
14°– 185° F (-10° to +85° C)
9 to 12Vdc @ 650mA
Listed ITE power supply, marked "LPS" or "Class II",
output rated: 9 to 12Vdc, 650mA
6.2" wide × 1.4" high x 9.0" deep (15.8 cm × 3.6 cm x 22.9 cm)
2 lbs. (0.9 kg)
2 years
CE Mark
EMC: FCC Part 15 Class B, EN 55024, EN55002 Class B
Safety: cUL, EN 60950, UL 60950
Telecom: CS03, FCC Part 68, TBR21
Plug and Play; remote configuration for centralized setup and management;
pass-through and fixed callback security; AT command compatible; autodial,
redial, repeat dial; pulse or tone dial; dial pauses; auto answer; caller ID;
adaptive line probing; automatic symbol and carrier frequency during start-
up, retrain, and rate renegotiation; DTMF detection; call status display, auto-
parity and data rate selection; keyboard- and front panel-controlled modem
options; monitor and LCD displays for modem options; non-volatile memory;
storage of up to four command strings or telephone numbers of up to 40
characters each.
Chapter 1 – Product Description and Features
8
