Press the  and Enter buttons to start the remote digital loopback test. The TEST IN PROGRESS LCD appears. To
stop the test, press the  and Enter buttons again. Same as the &T6 command.
Note: Digital Loopback and Remote Digital Loopback tests must be performed using AT Commands. The LCD option
to run these tests has been temporarily removed.
Phone Number Memory Options
Use the following LCDs to list, enter, and dial stored phone numbers. Up to four phone numbers can be stored. The
number in memory location 0 is used for DTR dialing, if DTR dialing is enabled.
Only 16 characters can be displayed at a time. To display characters 17–30, press the  button. To go to the
Note:
previous LCD, press the  button. To go to the next LCD, press the  button.
LIST PHONE NUMBERS
Press the  button several times to display the phone number stored in each memory location.
ENTER PHONE NUMBERS
Use to store up to four phone numbers in memory locations 0–3. Each number can have up to 30
characters. To scroll through a list of digits and characters, press the   and  buttons. To go to
the next position, press the  button. To back up or to exit without saving, press the  button
several times. To save the number, press the Enter button. Same as the &Z= commands.
DIAL STORED NUMBERS
Press the  and Enter buttons to dial a stored phone number. Same as the DS= commands.

Caller ID Options

Press the  and Enter buttons to enable formatted (FCID) or unformatted (UCID) Caller ID or to disable Caller ID
altogether. Same as the +VCID=0, +VCID=1, and +VCID=2 commands.
Note: Because Caller ID information is sent between the first and second ring, register S0 must be set to 2 or more
rings for the modem to receive Caller ID information.
Region Select Options
Note: See page 10.
