Front Panel Method
1. Turn on the modem.
2. Starting at the STATUS LCD, press the following buttons on the front panel to turn callback
security on and off:



Assigning Callback Passwords

AT Command Method
1. Open a terminal program, such as HyperTerminal.
2. To store a callback password for the first callback memory location, type AT#CBP01=xxxxxxxxxx,
where xxxxxxxxxx is the first password, and press E
characters in length.
3. To store a callback password for the second callback memory location, type
AT#CBP02=xxxxxxxxxx, where xxxxxxxxxx is the second password, and press E
memory location number in the command is incremented by one.
4. Repeat as many times as necessary, up to memory location 30, until all passwords have been
entered.
Front Panel Method
1. Turn on the modem.
2. Starting at the STATUS LCD, press the following buttons on the front panel:  , , , , ,
, . The ENTER PASSWORD #1? LCD appears.
3. Press the Enter button on the front panel to select callback memory location 1. The ENTER
PASSWORD LCD appears.
4. Press the  or  button several times to select the first letter in the password.
5. Press the  button to go to the next letter in the password.
Note: To backspace or to cancel an entry, press  several times.
6. The password must be six to ten characters in length. Repeat steps 4 and 5 until the password is
entered, and then press the Enter button to store it. The PASSWORD STORED LCD should
appear.
7. Press the Enter button again to go to the PASSWORD SETUP LCD.
8. Press ,  to go to the ENTER PASSWORD #2? LCD.
9. Repeat steps 3–7 to enter the next password.
10. Repeat as many times as necessary, up to memory location 30, until all passwords have been
entered.
Warning:
attempt to look at a password entry by pressing the Enter button for an ENTER PASSWORD #n?
LCD, it is possible to accidentally erase the entry.
Multi-Tech Systems, Inc. MT5600BA-V92 User Guide
To turn on callback security, press , , , , , ,  to display the -
CALLBACK ON? option, and then press the Enter button to select the option. When
remote callback security is turned on, each caller is asked to enter a password, then is
disconnected and called back by the modem. Also, dialing number locations 0–3, for use
with the DS=y dialing command, are replaced by callback dialing number locations 1–30.
To turn off callback security, press , , , , , , ,  to display the CALLBACK
OFF? option, and then press the Enter button to select the option. Callers no longer
need a password to connect to the modem, the modem is unable to call them back, and
stored dialing number locations 0–3 become available.
There is no way to review an entry to confirm that it has been entered correctly. If you
Chapter 6 – Callback Security
. The password must be six to ten
NTER
. Note that the
NTER
34
