KO70

1. INTRODUCTION

The K-array Ko40 and Ko70 are self-powered, Sub Bass speaker systems. They are best suited for high-power
extended bass response applications in arenas, theatres, concert halls, churches, and outdoor events. The 21"
speakers employ neodymium magnets and 6" voice coils driven by powerful D-class amplifiers. The large ports
are designed toa be fully symmetrical to the speakers, which means the back loading on the drivers is consistent
and even with no port air turbulence. The triangle port construction also provides excellent structural integrity and
strength, effectively eliminating any box resonance.

2. APPLICATIONS

• Large scale events
• touring sound reinforcement
• Stadiums, arenas, concert halls, theatres
• Installations in low-load capacity situations

4. UNPACKING

Each K-array loudspeaker is built to the highest standard and thoroughly inspected before leaving the factory.
Upon arrival, carefully inspect the shipping carton, then examine and test your new loudspeaker. If you find any
damage, immediately notify the shipping company. only the consignee may institute a claim procedure regarding
the system's electronic equipment.

5. SAFETY

WARNING
Read all safety information below and operating instructions before using this device to avoid injury.

Safety and handling information

Warning. Failure to follow these safety instructions could result in fire, shock or other injury or
damage to the device or other property.
4

3. KEY FEATURES

• Unique performance-to-size ratio
• Self powered Integrated DSP and remote control
• Variable vertical coverage
• Wide horizontal coverage
• Integrated flying and stacking hardware
• top quality components
performance
• Ultra-fast set-up and dismantling system
for outstanding
REV. B
