(Supplement to the FieldServer Instruction Manual)
APPLICABILITY & EFFECTIVITY
Effective for all systems manufactured after November 2009
Driver Manual
FS-8700-17 Opto22
A Sierra Monitor Company
Driver Version:
1.01
Document Revision:
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Optomux FS-8700-17 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FieldServer Optomux FS-8700-17

Summary of Contents for FieldServer Optomux FS-8700-17

  • Page 1 Driver Manual (Supplement to the FieldServer Instruction Manual) FS-8700-17 Opto22 APPLICABILITY & EFFECTIVITY Effective for all systems manufactured after November 2009 A Sierra Monitor Company Driver Version: 1.01 Document Revision:...

  • Page 2: Table Of Contents

    Appendix B.2. Command Response Status ... 21 Appendix B.3. Driver Stats ... 21 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Party Equipment ... 2 Table of Contents...

  • Page 3: Optomux Driver Description

    FS-8700-17_Opto22.doc Manual OPTOMUX DRIVER DESCRIPTION The Optomux Driver allows the FieldServer to transfer data to and from devices over either RS-232 or RS-485 using the Optomux Driver protocol. The Optomux driver is a client only driver. This means that the driver can poll an Optomux protocol compliant device but cannot emulate one.

  • Page 4: Provided By Supplier Of 3 Rd Party Equipment

    Part # Description Optomux System FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Description Driver Manual. Party Equipment Page 2 of 24...

  • Page 5: Hardware Connections

    Bridging 4-wire RS-422 to get 2-wire RS-485 may not work in certain applications, and in this case it is recommended that a RS-232 to RS-422 converter is used in between the FieldServer and the OPTO 22 devices . FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com...

  • Page 6: Data Array Parameters

    , Bit DA_DO_01 , Bit FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Legal Values Up to 15 alphanumeric characters Float, Packed_Bit, Byte, Packed_Byte,...

  • Page 7: Configuring The Fieldserver As An Optomux Driver Client

    This section documents and describes the parameters necessary for configuring the FieldServer to communicate with an Optomux Device. The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable the FieldServer for Optomux Driver communications, the driver independent FieldServer buffers need to be declared in the “Data Arrays”...

  • Page 8: Client Side Nodes

    Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available on specific hardware. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com , Port , R1...

  • Page 9: Driver Related Map Descriptor Parameters

    One data element is used per Map Descriptor. The element is determined by the Data_Array_Offset parameter. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Page 7 of 24 Legal Values...

  • Page 10: Timing Parameters

    Scan_Interval Rate at which data is polled FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Legal Values >0.1s Page 8 of 24...

  • Page 11: Map Descriptor Example - Read On/Off Status

    FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com , Data_Array_Offset , Function , Node_Name...

  • Page 12: Appendix A. Useful Features

    FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Page 10 of 24 , Function , Node_Name...

  • Page 13: Appendix A.1.2. Map Descriptor Example - Static Specification Using A Mask To Address Specific Module Positions

    0x0003 = Module Positions 1 & 2 ….. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Page 11 of 24 , Function...

  • Page 14: Appendix A.1.3. Map Descriptor Example -Specifying Module Positions Dynamically

    LOW_ARRAY starting at position Data_Array_Offset. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Page 12 of 24 element for the 2...

  • Page 15: Appendix A.1.4. Map Descriptor Example - Triggered Action

    FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Page 13 of 24 , Function , Node_Name...

  • Page 16: Appendix A.2. Store Unpacked Bit Data

    , Data_Array_Offset DEVICE77_STAT , DISC_INPUTS FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com Page 14 of 24 and 5 , Data_Array_Offset , Function...

  • Page 17: Appendix B. Reference

    INPUTS CONFIGURE AS OUTPUTS READ MODULE CONFIGURATION FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com MASTER LENGTH NOTES CONSIDERED (See Notes) Uses 1 element of Data Array. Legal values are 0,1,2,3 Uses 1 element of Data Array.

  • Page 18: Activate Outputs

    READ LATCHES READ AND CLEAR LATCHES CLEAR LATCHES FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com MASTER LENGTH NOTES CONSIDERED (See Notes) Uses up to Length (max=16) array elements.
  • Page 19 GENERATE N PULSES START ON PULSE START OFF PULSE FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com MASTER LENGTH NOTES CONSIDERED (See Notes) All positions are affected by command.

  • Page 20: Read Analog Outputs

    COUNTERS WRITE ANALOG OUTPUTS READ ANALOG OUTPUTS FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com MASTER LENGTH NOTES CONSIDERED (See Notes) All Module positions are affected by this command.
  • Page 21 TEMPERATURE INPUTS READ AVERAGE TEMPERATURE INPUTS FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com MASTER LENGTH NOTES CONSIDERED (See Notes) Only specified module positions get written.
  • Page 22 SET OFFSETS CALCULATE GAIN COEFFICIENTS SET GAIN COEFFICIENTS FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com MASTER LENGTH NOTES CONSIDERED (See Notes)

  • Page 23: Appendix B.2. Command Response Status

    A nak was received but was badly formatted Message was not acknowledged correctly. Appendix B.3. Driver Stats FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com MASTER LENGTH NOTES...
  • Page 24 FS-8700-17_Opto22.doc Manual In addition to the standard FieldServer communication statistics described in the FieldServer User’s Manual the Optomux Driver can also expose some driver statistics by writing data to a Data Array. A special Map Descriptor is required. The driver recognizes the Map Descriptor by its name which must be "opto22-stats”.
