■ Antenna

A key element n the performance of any communcaton
systems s an antenna. Contact your dealer for more nfor-
maton regardng antennas and how to nstall them.

■ Fuse replacement

A fuse s nstalled n the suppled DC power cable. If a fuse
blows or the transcever stops functonng, track down the
source of the problem f possble, and then replace the dam-
aged fuse wth a new rated one.
❑ Fuse ratng: 20 A
USE the 20 A fuse only.
■ Cleaning
If the transcever becomes dusty or drty, wpe t clean wth a
soft, dry cloth.
AVOID the use of solvents such as benzene or
alcohol, as they may damage the transcever sur-
faces.
CONNECTION AND MAINTENANCE
■ Options
• RMK-3 +
separation kit
OPC-607/OPC-608/OPC-609
separation cable
Allows you to nstall the transcever man unt separately from the
front panel for operatng convenence.
• OPC-1132/OPC-347
dc power cable
OPC-1132: 3 m (9.8 ft)
OPC-347: 7 m (23 ft)
• HM-152/HM-152T/HM-148
hand microphone
HM-152 : Hand mcrophone
HM-152T : DTMF mcrophone
HM-148 : Heavy duty mcrophone
• SM-25
desktop microphone
• SP-5/SP-10/SP-22
external speaker
Input mpedance : 4 ø
Max. nput power : 5 W
SP-5 : Large speaker for good audo qualty.
SP-10 : For all-round moble operaton.
SP-22 : Compact and easy-to-nstall.
• UT-109R/UT-110R
scrambler units
Non-rollng type (UT-109R)/Rollng type (UT-110R) voce scrambler
unt provdes hgher communcaton securty.
• UT-96R
5 tone unit
• UT-126H
/
digital modulator demodulator unit
Provdes 6.25 kHz dgtal mode operaton.
( UT-126H s a upgrade verson of UT-119H. UT-119H can be used
dependng on the verson. Ask your dealer for detals.)
