CONNECTION AND MAINTENANCE

■ Supplied Accessories

1
Microphone*
or
DC power cable
Mounting bracket
* 1 The microphone type is different depending on
the version.
* 2 Used for labelling the programmable function
keys according to their assinged functions.
*
3 Used for the optional unit installation.
Ask your dealer for details.
15
Microphone hanger
and screw set
Function name Microphone
2
stickers* hanger cable
Sponges*
Flat washers Bracket bolts
Spring washers Mounting screws
(M5×12)
Nuts
Self-tapping screws
(M5×16)

■ Mounting the transceiver

The unversal mountng bracket suppled wth your trans-
cever allows overhead mountng.
• Mount the transcever securely wth the 4 suppled screws
to a thck surface whch can support more than 1.5 kg.
Flat washer
3
Felt*
Spring washer
Felt*
When using
self-tapping screws
*Felts reduce the vibration effects.
