Summary of Contents for Vanco 280332
-
Page 1: Instruction Manual
Instruction Manual 1x2 Digital HDMI Splitter/Extender Model: 280332... -
Page 2: Table Of Contents
Table Of Contents Introduction Specifications Checking Package Contents Connecting The Hardware Operating The Unit Installation of Mounting Components Troubleshooting Limited Warranty Regulatory Compliance... -
Page 3: Introduction
HDMI type devices without signal degradation or loss of encryption. Liability Statement Every effort has been made to ensure that this product is free of errors. Vanco International cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use. -
Page 4: Specifications
External Power Supply +5V@1A Regulatory Approvals Splitter/Extender FCC, CE, RoHS Power Supply UL, CE, CSA, RoHS Accessories Included 1x AC Power Adapter US, UK or Euro Type 280332 Instructions Manual 1x Instruction Manual Product Item Number 280332 1X2 HDMI Distribution Amp... -
Page 5: Checking Package Contents
Note: Please retain the original packing material should the need ever arise to return the unit. If you find any items are missing, contact Vanco immediately. Have the Model Number, Serial Number and Invoice available for reference when you call. -
Page 6: Operating The Unit
Since HDTV can be any of several different resolutions, the 1x2 Splitter/Extender (Part No. 280332) must be able to sense and process the various resolutions on both input and outputs. On the input, the Splitter/Extender will sense and accept any standard resolution... -
Page 7: Troubleshooting
INSTALLATION OF OPTIONAL MOUNTING COMPONENTS The 1x2 Digital Splitter/Extender (Part No. 280332) can be mounted on any flat surface. Mounting the 1x2 Splitter/Extender Attach the two “L” shaped mounting brackets to the product using the furnished hardware and then attach the combined assembly to the desired location. -
Page 8: Limited Warranty
In no event shall Vanco be responsible or liable for any damage arising from the use of such defective products whether such damages be direct, indirect, consequential or otherwise, and...
