- Page 1 HOME THEATER HDMI Extenders ® over UTP Vanco Part Numbers 280723 (164ft) 280713 (100ft) 280725 (164ft wall plate) 280715 (100ft wall plate) Technical Support www.vanco1.com • info@vanco1.com • 800-626-6445...
-
Page 2: Dear Customer
DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. This product is 100% inspected and tested in the United States to verify HDMI performance parameters. - Page 3 FEATURES Super IR Control These active extenders units have the capability of transporting IR signals over the UTP cables. These extenders can control the source from the display. This is accomplished by using an optional IR Receiver pigtail (Part # 280721) attached to the receiver pointing away from the display and the IR Transmitter pigtail (Part # 280720) attached to the sender and pointed at the source.
- Page 4 HDMI® Extender over 2 UTP Cables with IR Control (30m/100 ft) Part # 280713 • Allows HDMI Audio/Video Signals to be • Supports Digital Audio Format, DTS-HD/Dolby- transmitted over Dual Cat6 Cables True HD/LPCM7.1/AC3/DTS/DSD • Transmission Range: Extends 1080p • Unique Circuit Design Allows for Protection resolutions up to 100 ft over Cat6 Cables against High Voltage and Peak Currents • High Speed Chip Set that Supports 3D, 4K x 2K...
-
Page 5: Specifications
HDMI® Wall Plate Extender over 2 UTP Cables with IR Control (30m/100 ft) Part # 280715 • Allows HDMI Audio/Video Signals to be • Supports Digital Audio Format, DTS-HD/Dolby- transmitted over Dual Cat6 Cables True HD/LPCM7.1/AC3/DTS/DSD • Transmission Range: Extends 1080p • Unique Circuit Design Allows for Protection resolutions up to 100 ft over Cat6 Cables against High Voltage and Peak Currents... -
Page 6: Package Contents
PACKAGE CONTENTS Before attempting to use this unit, please check the packaging and make sure the following items are contained in the shipping carton: • One HDMI Transmitter (Sender) • One HDMI Receiver • Power Supply (not required for the 30 meter wall-plate extender) •... -
Page 7: Connection Diagrams
CONNECTION DIAGRAMS DVD/Satellite box–Signal Source Video Output DVD/Satellite box–Signal Source HDMI Output Super IR Control System Over UTP Cable Blu-Ray HDTV Player Sender Receiver HDMI HDMI 2 UTP Cables IR TX Pigtail IR Remote (1 per display) RX Pigtail 800-626-6445... - Page 8 280723 PRODUCT IMAGES 280713 PRODUCT IMAGES www.vanco1.com...
- Page 9 280725 PRODUCT IMAGES 280715 PRODUCT IMAGES 800-626-6445...
-
Page 10: Troubleshooting
TROUBLE-SHOOTING 1. Best results are usually achieved when the source and display resolutions are the same. If resolutions differ, the splitters will try to adjust the signal to match the resolution of the HD TV with the lowest resolution. This will result in a picture with a lower resolution on the other HD TV sets. 2. -
Page 11: Limited Warranty
LIMITED WARRANTY With the exceptions noted in the next paragraph, Vanco warrants to the original purchaser that the equipment it manufactures or sells will be free from defects in materials and workmanship for a period of one year from the date of purchase. Should this product, in Vanco’s opinion, prove defective within this warranty period, Vanco, at its option, will repair or replace this product without charge. - Page 12 Vanco® International 506 Kingsland Drive Batavia, Illinois 60510 call: 800.626.6445 fax: 630.879.9189 visit: www.vanco1.com...
