- Page 1 HDMI® EXTENDER O V E R S I N G L E COAX I A L C A B L E PRODUCT MANUAL Vanco Part Number 280577 VPW- www.vanco1.com • 888.769.4156...
- Page 2 DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. This product is 100% inspected and tested in the United States to verify HDMI performance parameters.
- Page 3 FEATURES The Vanco 280557 HDMI Coaxial Extender uses coaxial cable as the transmission media. Benefits of using the Vanco 280557 HDMI Coaxial Extender are: 1. The length of HDMI cable is normally offered in fixed length increments and cannot be changed after it is produced.
-
Page 4: Specifications
SPECIFICATIONS Operating Temperature Range ........-5 to +35°C (+23 to +95 °F) Operating Humidity Range .......... 5 to 90 % RH (no condensation) Input Video Signal ............0.5-1.0 volts p-p Input DDC Signal ............5 volts p-p (TTL) Video Format Supported ..........DTV/HDTV; 1080p/1080i/720p/576i/480i Output Video ............. -
Page 5: Connect And Operate
CONNECT AND OPERATE Coax Cable 1. Connect the HDMI input source ( such as HD-DVD, PS3, STB, etc.) to the Transmitter unit. 2. Connect a CATV coaxial cable from COAX output of the Transmitter to the COAX input of the Receiver. 3. - Page 6 CONNECT AND OPERATE - CONTINUED DIP switch setting instruction: Transmitter Position1 Function Range scaling disable. Range scaling enable. Position2 Position3 Function 1080P stereo (Using Embedded EDID) (note1) 1080P 5.1 (Using Embedded EDID) (note2) 1080P 7.1 (Using Embedded EDID) (note3) EDID auto copy (note4) Note1: The OP5 will use the embedded 1080p stereo EDID when the DIP switch is in this mode.
- Page 7 PANEL DISCRIPTIONS - TRANSMITTER 888.769.4156...
- Page 8 PANEL DISCRIPTIONS - RECEIVER www.vanco1.com...
-
Page 9: Troubleshooting
TROUBLE-SHOOTING 1. Best results are usually achieved when the source and display resolutions are the same. If resolutions differ, the extenders will try to adjust the signal to match the resolution of the HD TV with the lowest resolution. This will result in a picture with a lower resolution on the other HD TV sets. 2. -
Page 10: Liability Statement
Vanco, at its option, will repair or replace this product without charge. Any defective parts replaced become the property of Vanco. This warranty does not apply to those products which have been damaged due to accident, unauthorized alterations, improper repair, modifications, inadequate maintenance and care, or use in any manner for which the product was not originally intended. -
Page 11: Technical Support
TECHNICAL SUPPORT In case of problems, please contact Vanco Technical Support by dialing 1-800-626-6445 or 1-888-769-4156. You can also email technical support issues to info@vanco1.com When calling, please have the Model Number, Serial Number (affixed to the bottom of the unit) and Invoice available for reference during the call. - Page 12 ® Vanco International 506 Kingsland Drive Batavia, Illinois 60510 call: 888.769.4156 fax: 630.879.9189 visit: www.vanco1.com...
