- Page 1 HDMI® EXTENDER W I T H K V M Vanco Part Number EVEXKVM1 HDMI® Extender with KVM www.vanco1.com • 800.626.6445...
- Page 2 DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. This product is 100% inspected and tested in the United States to verify HDMI performance parameters.
- Page 3 FEATURES INTRODUCTION The Evolution by Vanco EVEXKVM1 HDMI Extender over Single Cat5e/6 with KVM, auto EDID/EQ, and PoE extends high definition video and audio signals, KVM (Keyboard, Video, Mouse) signals, and power at a distance of up to 164ft/50m over a single Cat5e/6 cable. KVM capability using USB 2.0 allows for controlling a security NVR/DVR, computer, NAS system, or any other component that is controlled by USB with this extender.
-
Page 4: Specifications
SPECIFICATIONS Transmitters ............. HDMI input, USB to host (Type B),RJ45 Ethernet interface, 12V DC in Receivers ..............HDMI output, 4 USB to device (Type A), RJ45 Ethernet interface, 3.5mm audio/MIC out,12V DC in Power ..............<2W TX or <3W RX (not including external USB device power consumption) POE ................. -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS EVEXKVM1-TX (Transmitting Unit) 1. USB 2.0 type B port (connect the included USB cable to the source for KVM control) 2. HDMI INPUT: Connect a source such as a Security NVR/DVR, computer, NAS system, etc. 3. DC 12V: Connect the included power supply to power the extender unit (Powering this unit up requires no power supply needed at the RX unit) 4. - Page 6 PANEL DESCRIPTIONS EVEXKVM1-RX (Receiver Unit) 1. STATUS LEDs: “Video” illuminates when a signal is being received from the TX unit; “USB” illuminates when USB port is connected to a compatible source 2. RJ45 PORT (connect a single home run Cat5e/6 cable) 3.
-
Page 7: Connection Diagram
CONNECTION DIAGRAM CONNECT AND OPERATE 1. Connect a source such as a Blu-Ray Player, game console, A/V Receiver, Cable or Satellite Receiver, etc. to the HDMI input on the Transmitting unit. 2. Connect a display such as an HDTV or HD Projector to the HDMI output on the Receiving unit. 3. - Page 8 EDID Extended Display Identification Data (EDID) is a data structure provided by a digital display to describe its capabilities to a video source (e.g. graphics card or set-top box). In a nutshell, the display provides its EDID info to the source to send the proper signal format, this is essential for a proper handshake to occur. The EVEXKVM1 is equipped with EDID management, however there is no need to adjust any dip switches or dials, the unit automatically reads the EDID from the display and saves it internally.
-
Page 9: Resolutions Supported
NOTICE 1. Vanco HDMI and Cat5e/6 cables are strongly recommended for use with this product to ensure best results. 2. The transmission length is largely affected by the type of Cat5e/6 cables utilized, the type of HDMI sources, and the type of HDMI display. The testing result shows solid UTP cables (usually in the form of 300m [1,000ft] bulk cables) can transmit a lot longer signals than stranded UTP cables (usually in the form of fixed length patch cords). -
Page 10: Troubleshooting
4. If you are still encountering issues, attempt the “hot-plug concept. With all of the HDMI cables disconnected, turn on the source and plug in the HDMI cable into it’s output, then power up the Vanco unit and plug the HDMI cable into it’s input, finally turn on the display and plug the HDMI cable from the receiver into it. -
Page 11: Limited Warranty
If repairs are needed during the warranty period the purchaser will be required to provide a sales receipt/sales invoice or other acceptable proof of purchase to the seller of this equipment. The seller will then contact Vanco regarding warranty repair or replacement. - Page 12 ® Vanco International 506 Kingsland Drive Batavia, Illinois 60510 call: 800.626.6445 fax: 630.879.9189 visit: www.vanco1.com...
