11. Remove the front center console:
• Slide the front seat completely rearward.
• Open the lid, and take out the console box mat.
• Remove the two bolts from the inside of the
pocket.
• Remove the two clips, then slide the front
center console to the rear to release the four
retaining tabs. Take care not to damage the
retaining tabs.
CONSOLE
BOX MAT
BOLT
FRONT CENTER
CONSOLE
12. Open the hatch, and remove the center shelf.
CENTER
SHELF
© 2004 American Honda Motor Co., Inc - All Rights Reserved.
CLIP
RETAINING
TAB
BOLT
Open the lid.
13. Turn over the cargo area mat, and remove the
cargo area floor.
CARGO
AREA
FLOOR
14. Remove the cargo area mat (three clips).
CLIP
CARGO
AREA
MAT
AII 27936 (0408)
CARGO AREA MAT
CLIPS (3)
CLIP
