Honda 08B06-SDR-100 Installation Instructions Manual

Cassette/ multi-media player attachment 2006 accord hybrid
Hide thumbs


Advertisement

INSTALLATION
INSTRUCTIONS
PARTS LIST
Attachment Kit (sold separately):
P/N 08B06-SDR-100
Right player bracket
Left player bracket
Panel bracket
Player panel
2 Latches (black)
2 Panel grommets (white)
2 Screw grommets
© 2005 American Honda Motor Co., Inc. - All Rights Reserved.
Accessory
CASSETTE/
MULTI-MEDIA PLAYER
ATTACHMENT
(WITH NAVI)
Bus cable
2 Wire ties
3 EPT sealers
2 Self-tapping screws
Washer bolt
(Used for RES-equipped vehicles)
FM modulator bracket
(Used for RES-equipped vehicles)
Bus Cable 2-Port (sold separately):
P/N 08A31-0F1-000
2-port bus cable
AII 31211 (0510)
Application
2006 ACCORD
HYBRID
Publications No.
AII 31211
Issue Date
OCT 2005
1 of 9
08B06-SDR-1000-91

Advertisement

Table of Contents
loading

  Related Manuals for Honda 08B06-SDR-100

  Summary of Contents for Honda 08B06-SDR-100

  • Page 1 (Used for RES-equipped vehicles) 2 Latches (black) Bus Cable 2-Port (sold separately): P/N 08A31-0F1-000 2 Panel grommets (white) 2-port bus cable 2 Screw grommets 1 of 9 © 2005 American Honda Motor Co., Inc. - All Rights Reserved. AII 31211 (0510) 08B06-SDR-1000-91...
  • Page 2: Tools And Supplies Required

    P/N 08A06-4E1-200 equipment to your vehicle. These procedures should not be attempted by “do-it-yourselfers.” Multi-media player 4 Washer-screws, 5 x 8 mm Owner’s Manual 2 of 9 AII 31211 (0510) © 2005 American Honda Motor Co., Inc. - All Rights Reserved.
  • Page 3 Unplug the two seat heater connectors (if equipped), and remove the trim ring. CLIPS (2) CLIPS (4) TRIM RING SEAT HEATER 2206041K CONNECTOR (if equipped) 3 of 9 © 2005 American Honda Motor Co., Inc. - All Rights Reserved. AII 31211 (0510)
  • Page 4 Disconnect the vehicle connectors from the rear of RETAINING VEHICLE CLIPS (2) CONNECTOR the navigation unit, and remove the navigation unit from the pocket panel opening. 2730010K 4 of 9 AII 31211 (0510) © 2005 American Honda Motor Co., Inc. - All Rights Reserved.
  • Page 5 13. Secure the 2-port bus cable to the vehicle harness with one wire tie. 14. Wrap the plugged connectors with one EPT sealer. 5 of 9 © 2005 American Honda Motor Co., Inc. - All Rights Reserved. AII 31211 (0510)
  • Page 6 4419141Y VEHICLE CONNECTOR RIGHT PLAYER BRACKET MASKING TAPE Cassette Player CASSETTE PLAYER BUS CABLE CONNECTOR 4802030Y BUS CABLE 2306090T (Supplied with attachment kit.) 6 of 9 AII 31211 (0510) © 2005 American Honda Motor Co., Inc. - All Rights Reserved.
  • Page 7 21. Attach the two grommet screws onto the player panel in the square holes shown. PLAYER PANEL GROMMET 4419150Y GROMMET 2306131T SCREW 7 of 9 © 2005 American Honda Motor Co., Inc. - All Rights Reserved. AII 31211 (0510)
  • Page 8 3,500 rpm and 4,000 rpm (in Park or Neutral) until the IMA batter level displays at least three segments. 8 of 9 AII 31211 (0510) © 2005 American Honda Motor Co., Inc. - All Rights Reserved.
  • Page 9 37. Pull up on the driver’s window switch to close the window completely, then hold the switch for 2 seconds or more. 38. Test the window AUTO function. 9 of 9 © 2005 American Honda Motor Co., Inc. - All Rights Reserved. AII 31211 (0510)
