Chapter 3 System Engine

Mainboard Connector and Jumper Setting List
Label
CN1
CN2
CN3
CN4
CN5
CN6
CN7
CN9
CN10
CN11
CN12
CN13
CN14
CN15 (A,B)
CN16
CN19
CN20
CN21
CN22
CN23
CN24
CN25
CN27
CN30
UJ1
UJP1
J1
J2
JP3
JP2
JP7
JP8
FS1
TPC-1260H User Manual
Function
COM3
COM4
POWER CONNECTOR
BATTERY CONNECTOR
COM5
AUDIO LINE IN
SPEAKER CONNECTOR
AUDIO MIC IN
AUDIO OUT
PC/104 CONNECTOR (2*32)
PC/104 CONNECTOR (2*20)
COM1
LAN CONNECTOR
CARDBUS SLOT
PC/104-PLUS CONNECTOR
PRIMARY IDE CONNECTOR
COMPACT FLASH CONNECTOR
LPT CONNECTOR
PS/2 CONNECTOR
TDM CONNECTOR
VGA CONNECTOR
FLAT PANEL DISPLAY CONNECTOR
INVERTER CONNECTOR
FLAT PANEL DISPLAY CONNECTOR
(FOR 48 BITS PANEL)
USB CONNECTOR
INTERNAL USB 1.1(1*4)
CLEAR CMOS JUMPER
POWER BUTTON
DDR CONNECTOR
RESET
T/S CONNECTOR
INTERNAL RS-232
FUSE CONNECTOR
