  • Page 1 TPC-1261H GX3 LX800 Touch Panel Computer with 12.1" SVGA TFT LCD User Manual...
  • Page 2 Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp. All other product names or trademarks are properties of their respective owners. This Manual Covers the Following Models • TPC-1261H-A1 • TPC-1261H-A1E Part No. 2003126120 Printed in Taiwan TPC-1261H User Manual 1st Edition May 2006...
  • Page 3 Product Warranty (1 year) Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for one year from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper instal- lation.
  • Page 4 - Product name and serial number - Description of your peripheral attachments - Description of your software (operating system, version, appli- cation software, etc.) - A complete description of the problem - The exact wording of any error messages TPC-1261H User Manual...
  • Page 5 Before setting up the system, check that the items listed below are included and in good condition. If any item does not accord with the table, please contact your dealer immediately. • 1 x TPC-1261H-A1 • 8 x Panel mounting clampers • 8 x Panel mounting screws •...
  • Page 6 The sound pressure level at the operator's position according to IEC 704- 1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. TPC-1261H User Manual...

  • Page 7: Table Of Contents

    Chapter 1 General Information ... 2 Introduction ... 2 Specifications ... 3 1.2.1 1.2.2 1.2.3 LCD Specifications ... 4 Touchscreen Specifications... 4 Power... 5 I/O Ports Arrangement ... 5 Panel Mounting ... 5 Dimensions and Cutout ... 6 Chapter 2 System Setup... 10 Chapter 3 System Engine...
  • Page 8 DeviceIOControl ... 58 C.1.1 How to Use the Control Code ... 60 C.2.1 TPC-1261H User Manual Figure 4.14:Update Driver - 1 ... 25 Figure 4.15:Update Driver - 2 ... 25 Figure 4.16:Update Driver - 3 ... 26 Figure 4.17:Slave Bridge Installation Complete ... 26 Figure 4.18:PCI-1602 Device Manager ...
  • Page 9 C.2.2 C.2.3 C.2.4 C.2.5 C.2.6 Examples ... 62 Appendix D Accessory Kit Assembly Procedure ... 66 CompactFlash to IDE Transfer Kit ... 66 Appendix E HDD Kit Assembly... 70 Ruggedized HDD Kit ... 70 Internal HDD Kit Assembly... 77 Appendix F Touchscreen Installation & Configuration. 84 Driver Installation ...
  • Page 10 Touchscreen Calibration ... 87 Appendix G Fuse Specifications ... 96 Fuse Specifications... 96 Fuse Replacement ... 96 TPC-1261H User Manual Figure F.2:Install Wizard - 1 ... 84 Figure F.3:Install Wizard - 2 ... 85 Figure F.4:Install Wizard - 3 ... 85 Figure F.5:Uninstall -1 ...
  • Page 11 General Information This chapter gives background infor- mation on TPC-1261H.. Sections include: • Introduction • Specifications • I/O Ports Arrangement • Panel Mounting • Exploded Diagrams • Dimensions & Cutout...

  • Page 12: Chapter 1 General Information

    TPC-1261H provides a powerful I/O interface for easily communicat- ing with other devices. The I/O interface includes serial ports, a paral- lel port, Ethernet and USB 1.1 support. TPC-1261H also supports the expansion slot PCI/104. This makes it easy to expand with the required PCI/104 modules.

  • Page 13: Specifications

    1.2 Specifications 1.2.1 System Kernel • CPU: GeodeLink Control Processor LX800 500MHz • BIOS: Award 512KB flash memory • South Bridge: GeodeLink Control Processor CS5535 • VGA: GeodeLink Control Processor LX800 500MHz • Ethernet: Realtek RTL8100BL; IEEE 802.3u protocol compatible •...

  • Page 14: Lcd Specifications

    LCD manufacturing. 1.4 Touchscreen Specifications • Touch Type: Resistive • Base Glass Construction: Tempered Glass • Resolution: 1024 x 1024 • Light Transmission: 75% typical • Controller: USB Interface • Lifespan: 1 million touches at single point TPC-1261H User Manual...

  • Page 15: Figure 1.1:I/O Port Arrangement

    Make sure the waterproof gasket is in position before installing TPC-1261H into the panel opening. Install the TPC-1261H into the panel opening. Find the eight clampers and eight long screws in the accessory pack. Hook the clampers to the holes around the four sides of the bezel.

  • Page 16: Figure 1.2:Panel Mounting

    1.8 Dimensions and Cutout • Weight: 4.1 kg (without HDD) • Dimensions: 311 x 237 x 58 mm (W x H x D) • Cutout: 302 x 228 mm (suggested) TPC-1261H User Manual Figure 1.2: Panel Mounting...

  • Page 17: Figure 1.3:Dimensions

    Figure 1.3: Dimensions Chapter 1...
  • Page 18 TPC-1261H User Manual...
  • Page 19 System Setup This chapter provides a brief explana- tion for operating TPC-1261H.

  • Page 20: Figure 2.1:Unpack The Package

    Chapter 2 System Setup You can easily get TPC-1261H started by following the below steps. • Step 1: Unpack the TPC-1261H package. Check the packing list at the beginning of this manual to make sure all items have been included.

  • Page 21: Figure 2.4:Power Receptor & Button Pin Assignment

    • Step 2: Install a CompactFlash card containing Windows CE, embed- ded Windows XP or another operating system. Figure 2.2: Install CompactFlash Memory Card Warning It is suggested to turn OFF system power as you plug in or pull out the memory card, even though the CompactFlash memory is hot swappable.

  • Page 22: Figure 2.6:Touchscreen Calibration

    • Step 5: Push the power button to power on the system (figure 2.4). • Step 6: Calibrate the touchscreen (click "PM" in the bottom corner). Note: We are using Windows XP as the example. Please refer appendix F for detail. Figure 2.6: Touchscreen Calibration TPC-1261H User Manual Figure 2.5: Touchscreen Icon...
  • Page 23 System Engine...

  • Page 24: Table 3.1:Mainboard Connectors & Jumper Settings

    CN16 COM4 PANEL TOUCH 5V/3V 1*3 PIN HEADER POWER SWITCH BATTERY FUSE TPC-1261H User Manual Description LCD INVERTER Connector CompactFlash socket Internal IDE 44pin(2mm) connector RJ45 LAN PORT Printer Port Serial port:COM2 RS232 Serial port:COM1 RS232 DC Power in Connector,HOUSING 5.08 MM 3P Two USB Type-A Female to on panel.

  • Page 25: Figure 3.1:Main Board Connectors - 1

    Figure 3.1: Main Board Connectors - 1 Figure 3.2: Main Board Connectors - 2 Chapter 3...
  • Page 26 TPC-1261H User Manual...
  • Page 27 Software Configuration Sections include: • VGA Driver Installation • Advantech COM Installation • Entertainment Encryption/ Decryption Driver Installation...

  • Page 28: Figure 4.1:Device Manager

    Chapter 4 Software Configuration A support CD-ROM for TPC-1261H is available and along with the product. There are related utilities and drivers of TPC-1261H for Windows XP. Please insert the support CD-ROM into your CD-ROM driver and install the VGA graphics driver, Advantech com driver, Touchscreen driver and WDM driver sequentially.

  • Page 29: Figure 4.3:Update Wizard-1

    Figure 4.2: Update Driver Step 3: Then follow the update wizard processures. Figure 4.3: Update Wizard-1 Chapter 4...

  • Page 30: Figure 4.4:Update Wizard-2

    Figure 4.4: Update Wizard-2 Figure 4.5: Update Wizard-3 TPC-1261H User Manual...

  • Page 31: Figure 4.6:Update Wizard-4

    Figure 4.6: Update Wizard-4 Figure 4.7: Update Wizard-5 Chapter 4...

  • Page 32: Figure 4.9:Driver Installation Complete

    Figure 4.8: Update Wizard-6 Step 4: After you successfully update the driver, you can see the VGA successfully installed from the device manager. Figure 4.9: Driver Installation Complete TPC-1261H User Manual...

  • Page 33: Figure 4.11:Pci Icom Installation - 1

    4.2 Advantech COM Driver Install Two com ports named COM3 and COM4 on TPC-1261H are Advantech Special com port. Please follow the steps below to install the driver. Step 1: Insert the CD-ROM into your CD-ROM drive. Go to the direc- tory: …\TPC-1261H\Driver\Com Port Driver and then excute...

  • Page 34: Figure 4.12:Pci Icom Installation - 2

    Figure 4.12: PCI ICOM Installation - 2 Step 3: Then, go to “Device Manager” to update the driver. Click “?PCI Serial Port” and then select “Driver” Tab to update driver as shown in Figure 4.9 Figure 4.13: Device Manager Screen TPC-1261H User Manual...

  • Page 35: Figure 4.14:Update Driver - 1

    Figure 4.14: Update Driver - 1 Step 4: Follow the hardware update wizard as the figures below. Figure 4.15: Update Driver - 2 Chapter 4...

  • Page 36: Figure 4.17:Slave Bridge Installation Complete

    Figure 4.16: Update Driver - 3 Step 5: Complete the PCI-1602 Series Slave Bridge installation. Figure 4.17: Slave Bridge Installation Complete TPC-1261H User Manual...

  • Page 37: Figure 4.18:Pci-1602 Device Manager

    Step 6: Then, go to “Device Manager”. You can find “Advantech PCI- 1602 Series Slave Bridge” is on the list. Figure 4.18: PCI-1602 Device Manager Step 7: And then click “? PCI Serial Port” to update the driver. Chapter 4...

  • Page 38: Figure 4.19:Pci Serial Port Device Manager

    Figure 4.19: PCI Serial port Device Manager Figure 4.20: Update Driver - 1 TPC-1261H User Manual...

  • Page 39: Figure 4.21:Update Driver - 2

    Step 8: Follow the hardware update wizard as the figures below. Figure 4.21: Update Driver - 2 Figure 4.22: Update Driver - 3 Chapter 4...

  • Page 40: Figure 4.24:Pci Serial Port Installation - 1

    Step 9: Complete the Advantech PCI-1602 Series Master Bridge installa- tion. Figure 4.23: PCI-1602 Master Installation Step 10: Then, follow the wizard the install the software for Advantech PCI serial ports as the below. Figure 4.24: PCI Serial Port Installation - 1 TPC-1261H User Manual...

  • Page 41: Figure 4.25:Pci Serial Port Installation - 2

    Figure 4.25: PCI Serial Port Installation - 2 Figure 4.26: PCI Serial Port Installation - 3 Chapter 4...

  • Page 42: Figure 4.27:Pci Serial Port Installation - 4

    Figure 4.27: PCI Serial Port Installation - 4 Figure 4.28: PCI Serial Port Installation - 5 TPC-1261H User Manual...

  • Page 43: Figure 4.29:Pci Serial Port Installation - 6

    Figure 4.29: PCI Serial Port Installation - 6 Figure 4.30: PCI Serial Port Installation - 7 Chapter 4...

  • Page 44: Figure 4.31:Installation Complete

    Go to “Device Manager” and find the list as below. Figure 4.31: Installation Complete 4.3 Entertainment Encryption/Decryption Driver Step 1: Insert the CD-ROM and go to “Device Manager”. Click “Enter- tainment Encryption/ Decryption Controller” TPC-1261H User Manual Figure 4.32: Device Manager...

  • Page 45: Figure 4.33:Install Wizard - 1

    Step 2: Following the install shield wizard to finish the setup. Figure 4.33: Install Wizard - 1 Figure 4.34: Install Wizard - 2 Chapter 4...

  • Page 46: Figure 4.36:Driver Installation Complete

    Figure 4.35: Install Wizard - 3 Step 4: The driver is successfully installed. You can check via “Device Manager” as the below. Figure 4.36: Driver Installation Complete TPC-1261H User Manual...
  • Page 47 Features in Windows XP Embedded Sections include: • EWF • HORM • Advantech Utilities...

  • Page 48: Chapter 5 Features In Windows Xp Embedded

    Enable read-only media, such as CD-ROM or flash, to boot and run. Prolong the lifespan of write-sensitive storage, such as CompactFlash. TPC-1261H XPE provides EWF RAM RDG mode on system partition. All wirte to system partition will be redirected to RMA once this mode is enabled.

  • Page 49: Horm

    In other words, the hibernation file is 512MB that is the same as memory size used on TPC-1261H-A1 or TPC-1261H-B1. 5.3 Advantech Utilities TPC-1261H provides the useful utilities for users to configure the HORM and EWF. Chapter 5...

  • Page 50: Version Information

    Please follow the steps before running this utility to create full HORM environment. Enable Hibernation via Power Options in Control Panel Make C: partition EWF-enabled via OSLock Make sure that all volumes to be dismounted are not in use. TPC-1261H User Manual...
  • Page 51 Chapter 5...
  • Page 52 TPC-1261H User Manual...
  • Page 53 Serial Port Settings...

  • Page 54: Appendix A Serial Port Settings

    Appendix A Serial Port Settings A.1 COM1/ COM2/ COM3 Connector Definition Note: COM1 and COM2 only support half-duplex (Maximum baud rate: 115.2Kbps) TPC-1261H User Manual Signal NDCD NDTR NDSR NRTS NCTS...

  • Page 55: A.2 Com4 Setting

    A.2 COM4 Setting The serial port COM4 on the TPC-1570H is adjustable. It can be set to RS-232, RS-422 or RS-485. This port is designed with auto data flow control capability. In other word, the TPC-1570H can automatically detect the data flow direction at this port when the two wired RS-485 communication is activated.
  • Page 56 RS-232 NDCD NDTR NDSR NRTS NCTS TPC-1261H User Manual RS-422 RS-485...
  • Page 57 Watchdog Timer Programming...

  • Page 58: B.1 Overview

    Appendix B Watchdog Timer B.1 Overview The TPC-1261H watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function after the programmed period. This section describes the operation of the watchdog timer, and how to program it.

  • Page 59: Figure B.1:Watchdog Timer Programming Procedure

    B.2 Watchdog Timer Programming The I/O port address of the watchdog timer is 2E(hex) and 2F(hex), 2E (hex) is the address port. 2F(hex) is the data port. You must first assign the address of register by writing address value into address port 2E(hex), then write/read data to/from the assigned register through data port 2F (hex).

  • Page 60: Table B.1:Watchdog Timer Registers

    F5 (hex) Write 0 to bit 3: set second as counting unit. [default] Write 1 to bit 3: set minute as counting unit F6 (hex) F7 (hex) AA (hex) TPC-1261H User Manual Attribute Description Value (2F) description ----- Write this address to I/O address...

  • Page 61: B.3 Example Programs

    B.3 Example Programs 1. Enable watchdog timer and set 10 sec. as timeout interval ;----------------------------------------------------------- Mov dx,2eh ; Unlock W83627HF Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ;...
  • Page 62 Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Set minute as counting unit Mov al,0f5h TPC-1261H User Manual...
  • Page 63 Out dx,al Inc dx In al,dx Or al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 5 minutes and start counting Mov al,0f6h Out dx,al Inc dx Mov al,5 Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al 3.
  • Page 64 4. Enable watchdog timer to be reset by keyboard ;----------------------------------------------------------- Mov dx,2eh ; unlock W83627H Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- TPC-1261H User Manual...
  • Page 65 Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable watchdog timer to be strobed reset by keyboard Mov al,0f7h Out dx,al Inc dx In al,dx Or al,40h Out dx,al ;-----------------------------------------------------------...
  • Page 66 Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register Inc dx In al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al TPC-1261H User Manual...
  • Page 67 Watchdog Timer Programming on WinCE...

  • Page 68: C.1 Deviceiocontrol

    Appendix C Watchdog Timer Program- ming on WinCE There is a built-in watchdog timer in Windows CE 4.2 for TPC-1261H. You can access it through the WIN32 API. TPC-1261H provides a WDT driver to allow users to enable/disable the watchdog timer. The driver name is “WDT1:”.

  • Page 69: C.1.1 Parameters

    C.1.1 Parameters • hDevice [in] Handle to the device that is to perform the operation. Call the Cre- ateFile function to obtain a device handle. • dwIoControlCode [in] Specifies the control code for the operation. This value identifies the specific operation to be performed and the type of device on which the operation is to be performed.

  • Page 70: C.2.2 Ioctl _Wdt_Disable

    WDT driver, your application must trigger the watchdog once during the watchdog timer period. If your application has not triggered at the specified period, the device will reboot automatically. lpInBuffer: unused. nInBufferSize: unused. lpOutBuffer: unused. nOutBufferSize: unused. TPC-1261H User Manual...

  • Page 71: C.2.4 Ioctl_Wdt_Gettimeout

    C.2.4 IOCTL_WDT_GETTIMEOUT: Gets the Watchdog time setting. lpInBuffer: unused. nInBufferSize: unused. lpOutBuffer: The DWORD points to your watchdog time setting. The Watchdog time setting is just a number. 0 means 2 seconds, 1 means 5 seconds, 2 means 10 seconds, 3 means 15 seconds, 4 means 30 seconds, 5 means 45 seconds and 6 means 60 seconds.

  • Page 72: C.3 Examples

    // assign the WDT driver name wsprintf(szClassName, TEXT("WDT1:")); // Open the WDT driver m_hWDT = CreateFile(szClassName, GENERIC_READ GENERIC_WRITE, 0, NULL, OPEN_EXISTING, FILE_ATTRIBUTE_NORMAL, NULL); if ( m_hWDT == INVALID_HANDLE_VALUE ) { DebugMsg(CString("WDT driver fail")); return; DWORD dwTemp; DWORD nIndex=2; TPC-1261H User Manual...
  • Page 73 // Set the Watchdog Timer as 10 seconds. Number 2 means 10 seconds. DeviceIoControl(m_hWDT, IOCTL_WDT_SET_TIMEOUT, &nIndex, sizeof(nIndex), NULL, 0, &dwTemp, NULL); // Enable the Watchdog timer DeviceIoControl(m_hWDT, IOCTL_WDT_ENABLE, NULL, 0, NULL, 0, &dwTemp, NULL); While (1) { // do your job here. Sleep(8000);...
  • Page 74 TPC-1261H User Manual...
  • Page 75 Accessory Kit Assembly Procedure This appendix shows how to connect to a CD-ROM via the CompactFlash slot.:...

  • Page 76: Figure D.1:Adapter Board And Ide Cable

    Please follow this assembly procedure to use the CompactFlash slot to connect with a CD-ROM drive. Connect the IDE cable to the adapter board. Figure D.1: Adapter Board and IDE Cable Figure D.2: Connecting the Adapter Board TPC-1261H User Manual...

  • Page 77: Figure D.4:Insert The Adapter Board Into The Cf Slot

    Note Pin 1 is marked red Insert the adapter board into the CompactFlash slot. Figure D.3: CompactFlash Slot Figure D.4: Insert the Adapter Board into the CF slot Figure D.5: Inserted Adapter Board Appendix D...

  • Page 78: Figure D.6:Connect The Cd-Rom Via The Ide Cable

    Connect the CD-ROM to the adapter board via the IDE cable and then connect the external power line to the CD-ROM. Figure D.6: Connect the CD-ROM via the IDE Cable Figure D.7: Plugging in the CD-ROM Drive TPC-1261H User Manual...
  • Page 79 HDD Kit Assembly...

  • Page 80: E.1 Ruggedized Hdd Kit

    Appendix E HDD Kit Assembly TPC-1261H provides two way to assemble the HDD into the system. The ruggized HDD kit is to resist against the high vibration. E.1 Ruggedized HDD Kit Please follow the assembly procedure to install the HDD into the system.

  • Page 81: Figure E.2:Required Parts

    Figure E.2: Required Parts Appendix E...

  • Page 82: Figure E.4:Fastening The Bracket

    Place the base bracket on the rear case and carefully pull out the FPC cable through the hole of the bracket Fasten the base on the rear case of the system by 5 screws. Figure E.4: Fastening the bracket TPC-1261H User Manual Figure E.3: Opening the Top...

  • Page 83: Figure E.6:Placing The Hdd Insulator On The Hdd

    Carefully connect the FPC cable to the HDD and then put the HDD insultor on the HDD. Figure E.5: Connectting the FPC with the HDD Figure E.6: Placing the HDD insulator on the HDD Appendix E...

  • Page 84: Figure E.7:Reverse Side Of The Hdd Holder

    Fasten the HDD holder with the HDD and HDD insulator. Please turn over the HDD holder and fasten them with 4 screws. Figure E.7: Reverse side of the HDD holder Figure E.8: Fastening the HDD holder TPC-1261H User Manual...

  • Page 85: Figure E.10:Mounting The Cushions - 2

    Mount the HDD cushions with the HDD holder. Figure E.9: Mounting the cushions - 1 Figure E.10: Mounting the cushions - 2 Appendix E...

  • Page 86: Figure E.11:Placing The Hdd Holder - 1

    Place the HDD holder on the rear cover of the system and then fas- ten the holder with the system by four screws. Then, the assembly of high vibration resistance HDD module is done. Figure E.11: Placing the HDD holder - 1 Figure E.12: Placing the HDD holder - 2 TPC-1261H User Manual...

  • Page 87: E.2 Internal Hdd Kit Assembly

    Figure E.13: Fastening the HDD holder E.2 Internal HDD Kit Assembly Please follow the steps to assemble the internal HDD kit. Remove the default HDD cover from the system. Figure E.14: Removing the HDD cover Appendix E...

  • Page 88: Figure E.15:Placing A Screw Into Its Rubber Casing

    There are four rubber screw casings, and four screws. Places the screws into their casings Figure E.15: Placing a screw into its rubber casing Mount the rubber HDD cushions on the HDD cover. Figure E.16: Mounting the rubber casings TPC-1261H User Manual...

  • Page 89: Figure E.17:Connecting The Fpc Cable

    Connect the FPC cable to the HDD Figure E.17: Connecting the FPC cable Put the HDD into the hole of the rear case. Figure E.18: Inserting the HDD Appendix E...

  • Page 90: Figure E.20:Placing The Cover Back Into Position

    Lay the HDD insulator in right direction. Figure E.19: Laying in the HDD insulator Place the default HDD cover on the system. Figure E.20: Placing the cover back into position TPC-1261H User Manual...

  • Page 91: Figure E.21:Re-Fastening The Cover - 1

    Fasten the default HDD cover with the system. Figure E.21: Re-fastening the cover - 1 Figure E.22: Re-fastening the cover - 2 Appendix E...

  • Page 92: Figure E.23:Fastening The Pci/104 Bracket - 1

    Place the bracket of PCI/104 on the slot and fasten it into place. Figure E.23: Fastening the PCI/104 bracket - 1 Figure E.24: Fastening the PCI/104 bracket - 2 TPC-1261H User Manual...
  • Page 93 Touchscreen Installation & Configuration This appendix demonstrates how to install the PenMount touchscreen and set the configuration on TPC-1261H. This section uses Windows XP as an example.

  • Page 94: Figure F.1:Setup.exe

    F.1 Driver Installation Please insert the x86 TPC series support CD and go to the driver folder: (TPC-1261H\Driver\USB touchscreen). Click setup.exe The screen displays the installation wizard for the PenMount USB soft- ware. Click “Next”. Follow the installation wizard step by step TPC-1261H User Manual Figure F.1: Setup.exe...

  • Page 95: Figure F.3:Install Wizard - 2

    Figure F.3: Install Wizard - 2 Figure F.4: Install Wizard - 3 Appendix F...

  • Page 96: F.2 Uninstall The Driver

    Please go to Settings and then select Control Panel. Please click Add/ Remove Programs. Select PenMount USB. Click Remove button. Then, select “Yes” to remove the PenMountUSB driver and reboot the system TPC-1261H User Manual Figure F.5: Uninstall -1 Figure F.6: Uninstall -2...

  • Page 97: F.3 Touchscreen Calibration

    F.3 Touchscreen Calibration The “PM”, the icon of the PenMount Control Panel, is in the menu bar after the touchscreen installation. Please click the icon “PM” to call Pen- Mount Control Panel. It contains six functions: Calibrate, Draw, Option, and About. About shows the driver version. Calibrate Two ways to calibrate the touchscreen include “Standard Calibration”...

  • Page 98: Figure F.8:Standard Calibration -2

    Figure F.8: Standard Calibration -2 Figure F.9: Standard Calibration -3 TPC-1261H User Manual...

  • Page 99: Figure F.10:Advanced Calibration -1

    Note Touch the red squares in sequence. The cali- bration is completed after the fifth touch red point is calibrated. Press “ESC” to skip. Advanced Calibration is for the aged touchscreens by using 4, 9, 16 or 25 points to calibrate touch panel. Figure F.10: Advanced Calibration -1 Appendix F...

  • Page 100: Figure F.11:Advanced Calibration -2

    Figure F.11: Advanced Calibration -2 Figure F.12: Plot Calibration Data TPC-1261H User Manual...

  • Page 101: Figure F.13:Draw

    Note Plot Calibration Data enabled provides the blue lines to show linearity before calibration and black lines to show linearity after calibration when you finished the advanced calibration. Draw This is to test the touchscreen operation. Its display shows touch loca- tion.

  • Page 102: Figure F.14:Clear Screen

    Point mode is only let the mouse a click function. The dragging on-screen is disabled. Users can turn on / off the beep sound by clicking the “enable beep sound”. TPC-1261H User Manual...

  • Page 103: Figure F.15:Option

    Figure F.15: Option Appendix F...
  • Page 104 TPC-1261H User Manual...
  • Page 105 Fuse Specifications...

  • Page 106: G.1 Fuse Specifications

    Step 2: Replace the damaged fuse with a new one Step 3: Place the fuse cover back into position. Warning Do NOT replace the fuse unless it is damaged. Do NOT replace the fuse with a different rated fuse. TPC-1261H User Manual Figure G.1: Fuse Replacement...
