Summary of Contents for Advantech TPC-100W Series
- Page 1 User Manual TPC-100W Series Touch Panel Computer 7"/10.1"/15.6"/21.5" Touch Panel Computer with the ® ® Cortex -A53 Processor...
- Page 2 Note 3. “-” indicates that the restricted substance is not present in the product. 製造商：研華股份有限公司 地址：台北市內湖區瑞光路 26 巷 20 弄 1 號 電話：02-27927818 Manufacturer: ADVANTECH Co., Ltd. Address: No. 1 Alley 20 Lane 26, Ruiguang Rd., Neihu District, Taipei City Telephone: 02-27927818 TPC-100W Series User Manual...
- Page 3 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
- Page 4 TPC110WN32YB2401-T, TPC110WN32YB2402-T, TPC110WN32YB2403-T TPC110WN32YB2404-T, TPC-110WN32YB2405-T, TPC110WN32YB2406-T TPC110WN32YB2501-T, TPC110WN32YB2502-T, TPC110WN32YB2503-T TPC110WN32YB2504-T, TPC-110WN32YB2505-T, TPC110WN32YB2506-T TPC110WN32YB2601-T, TPC110WN32YB2602-T, TPC110WN32YB2603-T TPC110WN32YB2604-T, TPC-110WN32YB2605-T, TPC110WN32YB2606-T TPC110WN32YB2701-T, TPC110WN32YB2702-T, TPC110WN32YB2703-T TPC110WN32YB2704-T, TPC-110WN32YB2705-T, TPC110WN32YB2706-T TPC110WN32YB2801-T, TPC110WN32YB2802-T, TPC110WN32YB2803-T TPC110WN32YB2804-T, TPC-110WN32YB2805-T, TPC110WN32YB2806-T TPC110WN32YB2901-T, TPC110WN32YB2902-T, TPC110WN32YB2903-T TPC110WN32YB2904-T, TPC-110WN32YB2905-T, TPC110WN32YB2906-T TPC-100W Series User Manual...
- Page 5 TPC115WN32AB2401-T, TPC115WN32AB2402-T, TPC115WN32AB2403-T TPC115WN32AB2404-T, TPC115WN32AB2405-T, TPC115WN32AB2406-T TPC115WN32AB2501-T, TPC115WN32AB2502-T, TPC115WN32AB2503-T TPC115WN32AB2504-T, TPC115WN32AB2505-T, TPC115WN32AB2506-T TPC115WN32AB2601-T, TPC115WN32AB2602-T, TPC115WN32AB2603-T TPC115WN32AB2604-T, TPC115WN32AB2605-T, TPC115WN32AB2606-T TPC115WN32AB2701-T, TPC115WN32AB2702-T, TPC115WN32AB2703-T TPC115WN32AB2704-T, TPC115WN32AB2705-T, TPC115WN32AB2706-T TPC115WN32AB2801-T, TPC115WN32AB2802-T, TPC115WN32AB2803-T TPC115WN32AB2804-T, TPC115WN32AB2805-T, TPC115WN32AB2806-T TPC115WN32AB2901-T, TPC115WN32AB2702-T, TPC115WN32AB2903-T TPC115WN32AB2904-T, TPC115WN32AB2905-T, TPC115WN32AB2906-T TPC-100W Series User Manual...
- Page 6 TPC121WN32AB2401-T, TPC121WN32AB2402-T, TPC121WN32AB2403-T TPC121WN32AB2404-T, TPC121WN32AB2405-T, TPC121WN32AB2406-T TPC121WN32AB2501-T, TPC121WN32AB2502-T, TPC121WN32AB2503-T TPC121WN32AB2504-T, TPC121WN32AB2505-T, TPC121WN32AB2506-T TPC121WN32AB2601-T, TPC121WN32AB2602-T, TPC121WN32AB2603-T TPC121WN32AB2604-T, TPC121WN32AB2605-T, TPC121WN32AB2606-T TPC121WN32AB2701-T, TPC121WN32AB2702-T, TPC121WN32AB2703-T TPC121WN32AB2704-T, TPC121WN32AB2705-T, TPC121WN32AB2706-T TPC121WN32AB2801-T, TPC121WN32AB2802-T, TPC121WN32AB2803-T TPC121WN32AB2804-T, TPC121WN32AB2805-T, TPC121WN32AB2806-T TPC121WN32AB2901-T, TPC121WN32AB2902-T, TPC121WN32AB2903-T TPC121WN32AB2904-T, TPC121WN32AB2905-T, TPC121WN32AB2906-T TPC-100W Series User Manual...
-
Page 7: Product Warranty (2 Years)
Product Warranty (2 Years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation. -
Page 8: Declaration Of Conformity
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Please contact your local supplier for ordering information. -
Page 9: Warnings, Cautions, And Notes
équivalent recom- mandé par le fabricant. Jetez les piles usagées conformément aux instructions du fabricant. Note! Notes provide additional optional information. Les remarques fournissent des informations facultatives supplémen- taires. TPC-100W Series User Manual... -
Page 10: Safety Instructions
Attention: Le fil du conducteur de liaison de protection doit être vert et jaune, 22AWG/0,3 mm2 minimum. DISCLAIMER: These instructions are provided according to IEC 704-1 standards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. TPC-100W Series User Manual... - Page 11 設備有明顯的外觀破損。 請不要把設備保存在超出我們建議的溫度範圍的環境，即不要低於 -30°C （-4 °F）或高於 70°C （140°F） ，否則可能會損壞設備。 注意：如果電池放置不正確，將有爆炸的危險。因此，只可以使用製造商推薦的 同一種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。 根據 IEC 704-1:1982 的規定，操作員所在位置的音量不可高於 70dB(A)。 限制區域：請勿將設備安裝於限制區域使用。 免責聲明：該安全指示符合 IEC 704-1 的要求。研華公司對其內容的準確性不 承擔任何法律責任。 使用過度恐傷害視力。 使用 30 分鐘請休息 10 分鐘。 未滿 2 歲幼兒不看螢幕，2 歲以上每天看螢幕不要超過 1 小時。 本產品為國內裝置使用時，其電源僅限使用架構電源模組所提供電源直流輸入， 不得使用交流電源及附加其他電源轉換裝置提供電源這者，其電源輸入電壓及電 流請依說明書規定使用。 TPC-100W Series User Manual...
-
Page 12: Wichtige Sicherheishinweise
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend der IEC-704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in die- sem Zusammenhang getätigten Aussagen ab. Assurez-vous que la tension de la source d'alimentation est correcte avant de connecter l'équipement à... - Page 13 Don't touch any components on the CPU card or other cards while the PC is on. Disconnect power before making any configuration changes. The sudden rush of power as you connect a jumper or install a card may damage sensitive elec- tronic components. xiii TPC-100W Series User Manual...
- Page 14 TPC-100W Series User Manual...
-
Page 15: Table Of Contents
Table A.1: 8.5mm Half-Size 75-Pin M.2 Slot (E-Key) ....22 COM Port ....................23 Table A.2: 9-Pin Com Port Connector (COM1)......23 Table A.3: 9-Pin Com Port Connector (COM2/CAN) ....23 Table A.4: CAN Bus Terminal (CN2) ......... 24 Table A.5: COM2 Terminal (CN4)..........24 TPC-100W Series User Manual... - Page 16 TPC-100W Series User Manual...
-
Page 17: Chapter 1 General Information
Chapter General Information... -
Page 18: Introduction
Introduction The TPC-100W series is a compact touch panel computer designed for industrial ® ® use. It is equipped with an NXP Cortex -A53 i.MX8M Mini quad-core processor, a TFT display available in 7", 10.1", 15.6", or 21.5 sizes, a multi-touch glass sensor, and 16GB of eMMC storage. -
Page 19: Specifications
-20 ~ 60°C Storage (-22 ~ 158°F) (-22 ~ 158°F) (-22 ~ 158°F) (-4 ~ 140°F) 1.2.4 Touchscreen Touch Points: 10 Points Light Transmission: above 85% Pencil Hardness: 7H Type: Projected capacitive (P-CAP) touch TPC-100W Series User Manual... -
Page 20: Environment
on LAN B Power Consumption: – TPC-107W: 6W (Typ.); 9W (Max.) – TPC-110W: 10W (Typ.); 12W (Max.) – TPC-115W: 13W (Typ.); 16W (Max.) 1.2.8 External I/O The arrangement of I/O ports is shown below. TPC-100W Series User Manual... -
Page 21: Mounting
Hook the clamp into the holes and fasten the screws (Torque: 5 kgf-cm) These screws will push the mounting panel and secure the unit. Table 1.3: Panel Mounting Size Screw (M4 x 25mm) & Clamper Quantity TPC-100W Series User Manual... -
Page 22: Dimensions And Cutout
Dimensions and Cutout TPC-107W TPC-110W TPC-100W Series User Manual... - Page 23 TPC-115W TPC-121W 558.40 549.80 548.81 PANEL CUTOUT DIMENSION: 549.8mm X 341.3mm TPC-100W Series User Manual...
- Page 24 LED Indicator Off - “dark” ON - “Blue” Standby - “orange” TPC-100W Series User Manual...
-
Page 25: Chapter 2 System Setup
Chapter System Setup... -
Page 26: Transportation And Unpacking
Before powering on the device, open the rear bracket and select the appropriate mode. Configuration can be adjusted using the switch located on the TPC-100W’s rear board, as illustrated below. TPC-100W Series User Manual... - Page 27 Table 2.1: Boot Mode Options (SW2) SD boot (install image) 1. OFF 2. ON 3. ON eMMC boot default 1. ON 2. OFF 3. OFF Table 2.2: 7” CN6001 CN6001(1-3,2-4) SW6001 1.ON 2.OFF Table 2.3: 10” CN6001 CN6001(1-3,2-4) SW6001 1.ON 2.OFF TPC-100W Series User Manual...
- Page 28 Table 2.4: 15.6'' FHD CN6001 CN6001(3-5,4-6) SW6001 1.ON 2.OFF Table 2.5: 21'' FHD CN6001 CN6001(3-5, 4-6) SW6001 1.ON 2.OFF Table 2.6: AT/ATX (SW1) 2.ON 1.OFF 2.OFF 1.ON TPC-100W Series User Manual...
-
Page 29: E-Key 2230 Express And Poe Module Installation
Wi-Fi and Bluetooth. To install or configure an M.2 module, open the rear bracket and follow the instructions. For detailed infor- mation about the M.2 E-Key slot, refer to Appendix A1. TPC-100W Series User Manual... -
Page 30: Poe Module Installation
2.3.2 PoE Module Installation Remove the 4 posts. Remove the 4 screws. TPC-100W Series User Manual... - Page 31 Remove the rear cover. Affix the module PCB with 4 screws (Screw P/N:1930002181, Screw M2.5x4L R/S D=4.3 H=1.6 (1+) ST Ni NK). TPC-100W Series User Manual...
- Page 32 Connect the 2 cables. Put the rear cover back in place. TPC-100W Series User Manual...
- Page 33 Affix the cover with 4 screws. Fix the 4 posts back in place. TPC-100W Series User Manual...
-
Page 34: Powering On The System
SELV) standards with the following ratings: 24Vdc, 0.83A min. or 24Vdc, 1.2A min. to match the unit rating. Its output rating is: 48Vdc, 0.53A min. for PoE input. Please contact Advantech for further information. The terminal block is suitable for 16~26 AWG (10A). The recommended torque value is 2.5 lb-in. -
Page 35: Embedding The Tpc-100W System And Earth Grounding Setup19
Install the TPC-100W system into the cabinet. A: Connect the cabinet to the earth ground. B: Install the TPC-100W system into the cabinet without I/O or power cables. TPC-100W Series User Manual... - Page 36 Power should only be supplied after the wiring outlined in steps A to F has been per- formed. Caution! Ensure that all wires follow the installation guidelines or damage to the system may occur. Assurez-vous que tous les fils suivent les directives d'installation ou qu'ils sont endommagés. système peut se produire. TPC-100W Series User Manual...
-
Page 37: Appendix A Pin Assignments
Appendix Pin Assignments... -
Page 38: Slot (E-Key)
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved SYSCLK Functional reset to Reserved RESET# the card Reserved Reserved Reserved Reserved I2C_DATA Reserved I2C_CLK Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved +3.3V +3.3V TPC-100W Series User Manual... -
Page 39: Com Port
COM Port 9-Pin Com Port Connector (COM1) Table A.2: 9-Pin Com Port Connector (COM1) RS232 RS422 RS485 9-Pin Com Port Connector (COM2/CAN) Table A.3: 9-Pin Com Port Connector (COM2/CAN) RS485 GND (isolation) TPC-100W Series User Manual... - Page 40 CAN Bus Pin Definitions COM2 Pin Definitions Table A.4: CAN Bus Terminal (CN2) CN2 (1-2) CN2 (2-3) 120 Ω terminal default Table A.5: COM2 Terminal (CN4) CN4 (1-2) default CN4 (2-3) 120 Ω terminal TPC-100W Series User Manual...
- Page 41 TPC-100W Series User Manual...
- Page 42 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024...
