TPC-1260G
12.1" TFT LCD Display Touch
Panel Computer with
Transmeta™ Crusoe™
5800 1 GHz CPU

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPC-1260G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Advantech TPC-1260G

  • Page 1: User Manual

    TPC-1260G 12.1” TFT LCD Display Touch Panel Computer with Transmeta™ Crusoe™ 5800 1 GHz CPU User Manual...
  • Page 2 No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reli- able.
  • Page 3 Product Warranty (1 year) Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for one year from the date of purchase. This warranty does not apply to any products which have been repaired or...
  • Page 4 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
  • Page 5 TPC-1260GX-A5 • 8 x Panel mounting clampers • 8 x Panel mounting screws • 1 x 3-Pin power connector • 1 x TPC-1260G support CD • 1 x CompactFlash to IDE adapter board Safety Instructions Read these safety instructions carefully.
  • Page 6 The sound pressure level at the operator's position according to IEC 704- 1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. TPC-1260G User Manual...
  • Page 7 Wichtige Sicherheishinweise 1. Bitte lesen sie Sich diese Hinweise sorgfältig durch. Heben Sie diese Anleitung für den späteren Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Ver- wenden Sie Keine Flüssig-oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein.
  • Page 8 Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend der IEC-704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab. TPC-1260G User Manual viii...
  • Page 9: Table Of Contents

    Figure 2.5:Touch Screen Calibration-1 ....... 15 Figure 2.6:Touch Screen Calibration-2 ....... 15 Chapter 3 System Engine..........18 Chapter 4 Windows CE ..........20 Figure 4.1:Windows CE for TPC-1260G ....20 TPC Utilities..............21 4.1.1 Soft-Keyboard .............. 21 Figure 4.2:Soft-Keyboard ..........21 4.1.2 LCD Display Tuning ...........
  • Page 10 Figure 4.20:Remote Display Host Application .... 32 Figure 4.21:Remote Display Application ....32 Figure 4.22:Connect ............. 33 Figure 4.23:Remote Display Host Application with the display of TPC-1260G ........33 Figure 4.24:TPC CE Notepad ........34 Figure 4.25:TPC Version Information ......34 Networking..............35 4.2.1...
  • Page 11 Jumper Settings ............... 46 Software Setting .............. 46 Figure A.1:Device Manager ........47 Figure A.2:COM5 Properties ........47 Appendix B Fuse Specifications ........50 Fuse Specifications............50 Fuse Replacement ............50 Figure B.1:Fuse Replacement ........50 Appendix C Watchdog Timer Programming....52 DeviceIOControl .............
  • Page 12 TPC-1260G User Manual...
  • Page 13 General Information This chapter gives background infor- mation on TPC-1260G.. Sections include: • Introduction • Specifications • I/O Ports Arrangement • Panel Mounting • Exploded Diagrams • Dimensions & Cutout...
  • Page 14: Chapter 1 General Information

    TPC-1260G provides a powerful I/O interface for easily communicat- ing with other devices. The I/O interface includes serial ports, a paral- lel port, Ethernet and USB 2.0 support. TPC-1260G also supports the expansion slot PC/104-Plus. This makes it easy to expand with the required PC/104-Plus modules.
  • Page 15: Specifications

    1.2 Specifications 1.2.1 System Kernel • CPU: Transmeta Crusoe TM5800 (clock rate 1 GHz) • BIOS: Award 256 KB flash memory • South Bridge: VIA 82C686B • VGA: Silicon Motion SMI721 VGA/LCD controller; PCI 2.1 compli- ant; 4 MB embedded DRAM •...
  • Page 16: Safety And Environment

    • Operating Temperature: 0 ~ 50° C (32 ~ 122° F) (Ambient) • VR Control: Brightness Adjustable • Backlight: 1 CCFL • Backlight Life Time: 20,000 hours Note There might be several bright or dark pixels on the LCD. This phenomenon is normal in today’s LCD manufacturing. TPC-1260G User Manual...
  • Page 17: Touchscreen Specifications

    1.4 Touchscreen Specifications • Touch Type: Resistive • Base Glass Construction: Tempered Glass • Resolution: Continuous • Light Transmission: 75% typical • Controller: RS-232 Interface • Power Rating: 3.3 to 5 V • Software Driver: Windows CE (embedded) • Durability: 100 million touches 1.5 Power •...
  • Page 18: Panel Mounting

    Make sure the waterproof gasket is in position before installing TPC-1260G into the panel opening. Install the TPC-1260G into the panel opening. Find the eight clampers and eight long screws in the accessory pack. Hook the clampers to the holes around the four sides of the bezel.
  • Page 19: Exploded Diagrams

    1.8 Exploded Diagrams Figure 1.3: Exploded LCD Diagram Chapter 1...
  • Page 20: Figure 1.4:Exploded Backside Diagram

    Figure 1.4: Exploded Backside Diagram Figure 1.5: Exploded Mainboard Diagram TPC-1260G User Manual...
  • Page 21: Dimensions And Cutout

    1.9 Dimensions and Cutout • Weight: 2.2 kg (without HDD) • Dimensions: 311 x 237 x 75.85 mm (W x H x D) • Cutout: 302 x 228 mm (suggested) Figure 1.6: Dimensions Chapter 1...
  • Page 22 TPC-1260G User Manual...
  • Page 23 System Setup This chapter provides a brief explana- tion for operating TPC-1260G.
  • Page 24: Figure 2.1:Unpack The Package

    Chapter 2 System Setup You can easily get TPC-1260G started by following the below steps. • Step 1: Unpack the TPC-1260G package. Check the packing list at the beginning of this manual to make sure all items have been included.
  • Page 25: Figure 2.2:Install Compactflash Memory Card

    • Step 2: Install a CompactFlash card containing Windows CE, embed- ded Windows XP or another operating system. Figure 2.2: Install CompactFlash Memory Card Warning It is suggested to turn OFF system power as you plug in or pull out the memory card, even though the CompactFlash memory is hot swappable.
  • Page 26: Power Button

    2.5. Then, click the tab “Calibrate” to calibrate by selecting standard calibration or advanced calibration. Note This calibration is for Windows 2000. If your operating system is Windows CE .NET, the detailed procedure is described in section 4.1.4. TPC-1260G User Manual...
  • Page 27: Figure 2.5:Touch Screen Calibration-1

    Figure 2.5: Touch Screen Calibration-1 Figure 2.6: Touch Screen Calibration-2 Chapter 2...
  • Page 28 TPC-1260G User Manual...
  • Page 29 System Engine...
  • Page 30: Chapter 3 System Engine

    CN25 FLAT PANEL DISPLAY CONNECTOR CN27 INVERTER CONNECTOR CN30 FLAT PANEL DISPLAY CONNECTOR (FOR 48 BITS PANEL) USB CONNECTOR UJP1 INTERNAL USB 1.1(1*4) CLEAR CMOS JUMPER POWER BUTTON DDR CONNECTOR RESET T/S CONNECTOR INTERNAL RS-232 FUSE CONNECTOR TPC-1260G User Manual...
  • Page 31 Windows CE This chapter shows how to use Win- dows CE with TPC-1260G. Sections include: • TPC Utilities • Networking • Application Program Development...
  • Page 32: Figure 4.1:Windows Ce For Tpc-1260G

    Chapter 4 Windows CE Figure 4.1: Windows CE for TPC-1260G Note The default Windows CE version for TPC-1260G is the English version. Please contact local Advantech representatives for local language support. TPC-1260G User Manual...
  • Page 33: Tpc Utilities

    4.1 TPC Utilities There are several utilities built into the Windows CE .NET of TPC series. 4.1.1 Soft-Keyboard TPC-1260 provides a software keyboard built into the standard TPC- 1260 Windows CE .NET OS. Upon boot-up, a small keyboard icon will appear on the status bar.
  • Page 34: Figure 4.3:Display

    Figure 4.4. Figure 4.4: Display Properties Note TPC-1260G doesn’t provide a screen saving function. It will not turn off backlight even though the user enables the above settings. This fea- ture will be enabled in the coming version.
  • Page 35: Figure 4.5:Advanced Backlight Utility

    Click the “Advanced” button to activate the advanced backlight utility as shown in Figure 4.5. Click the “+” button to increase the LCD brightness, or the “-“ button to decrease the LCD brightness. You can also click the slider, hold it, and move it to the designated value and then release the button.
  • Page 36: Figure 4.7:General

    IP. The “Ping” button is used to test the connection with the specified IP address. Figure 4.8: Network Utility To get more detailed IP information click “Advanced...”. This will dis- play the default gateway, DHCP server, WINS and DNS server addresses as shown in Figure 4.8 below. TPC-1260G User Manual...
  • Page 37: Figure 4.9:Advanced Network

    Figure 4.9: Advanced Network Watchdog Timer A watchdog timer automatically resets TPC-1260G if the system freezes. A program that does not respond in time will make the watchdog restart the machine automatically. This is useful for systems that are not fre- quently monitored, but need to be restarted quickly if anything is wrong.
  • Page 38: Figure 4.11:Misc

    Click the “Add” button to insert a file to the star- tup. If you would like to remove the file from the startup or the combo box, please click “Delete”. Note Do NOT try to add a Non-Executable file into the startup program. TPC-1260G User Manual...
  • Page 39: Figure 4.12:Reboot

    Reboot: Reboot TPC-1260G by clicking the “Reboot” button. Once this button is clicked, the dialog below will be displayed. Figure 4.12: Reboot There are two additional ways to reboot the system. One is to click the small machine icon on the status bar and the other is to execute a com- mand, reboot.exe, through the command line program.
  • Page 40: Figure 4.14:Registry Editor

    Figure 4.15 after the “Backup” button is clicked. The default filenames are AdvSystem.hv and AdvUser.hv. If the two files already exist in the selected folder, the pop-up window will show and ask whether the user want to replace the file. Figure 4.15: Registry Backup TPC-1260G User Manual...
  • Page 41: Figure 4.16:Registry Restore

    If you want to restore the registry data, press the “Restore” button and then select the folder where the registry data was saved. A reboot is required after the registry data is restored. Figure 4.16: Registry Restore If you want to have the default contents of the registry, please click the “Load Default”...
  • Page 42: Advantech Tools

    4.1.4 Advantech Tools There are several useful programs in the Advantech program. Please go to “Start”, “Programs”, “Advantech” to run the tools as shown in Figure 4.17. The tools include: “ActiveSync”, “Registry Editor”, “Registry Saver”, “Remote Display Application”, "Touch Screen Calibration", “TPC CE Notepad”, “TPC Configurator”...
  • Page 43: Figure 4.19:Touch Screen Calibration Utility

    Figure 4.19: Touch Screen Calibration Utility ActiveSync This program synchronizes data and monitors the connection between TPC-1260 and a host computer. Click the “Active Sync” button to make an ActiveSync connection. For more information on how to make an ActiveSync connection, please refer to the “ActiveSync User Guide of TPC”.
  • Page 44: Figure 4.20:Remote Display Host Application

    It works with the Windows CE Remote Dis- play Host application. The connection is through the network, thus the network function of the host machine and TPC-1260G must work prop- erly. Users can see the display of TPC-1260G and control TPC-1260G from a host machine via the remote display application.
  • Page 45: Figure 4.22:Connect

    Figure 4.22: Connect Once the connection is successfully established, you can see the display of TPC-1260G and control it from the host machine as shown in Figure 4.23. Figure 4.23: Remote Display Host Application with the display of TPC- 1260G...
  • Page 46: Figure 4.24:Tpc Ce Notepad

    TPC Configurator is an integrated utility to configure the basic settings of TPC-1260G. Please refer to section 4.1.3. TPC Version Information TPC Version Information shows the version information of the operating system in TPC-1260G as shown in Figure 4.25. Figure 4.25: TPC Version Information TPC-1260G User Manual...
  • Page 47: Network Via Ethernet

    For example, double click the PCI-GETCEB1 icon to configure. Note PCI-GETCEB1 is the device name of the net- work device on the TPC-1260G Figure 4.27: Selected Connection Chapter 4...
  • Page 48: Figure 4.29:Setting Name Servers

    4. Select “Name Server” tab. Figure 4.29: Setting Name Servers 5. Press ‘Start’ in the task bar of Windows and select “Run”. Execute “regsave” to save the registry settings to the storage card. Figure 4.30: Save Registry TPC-1260G User Manual...
  • Page 49: Network Via Serial Port

    4.2.2 Network via Serial Port This section introduces how to build the connection between a TPC prod- uct and a host PC via Microsoft ActiveSync. ActiveSync Setting Procedure 1. Insert the TPC CD into the CD-ROM drive of the host PC. 2.
  • Page 50: Figure 4.33:Save Registry

    “regsave” to save the registry settings to a storage card. Figure 4.33: Save Registry Setting the Communication Environment of the Host 1. Double click the icon for ActiveSync on your host computer. Figure 4.34: Microsoft ActiveSync 2. Select “File”->”Connection Settings” Figure 4.35: Select Connection Setting TPC-1260G User Manual...
  • Page 51: Figure 4.36:Configure Connection Setting

    3. Configure the connection setting. Figure 4.36: Configure Connection Setting 4. A window will pop up after you press “Get Connected”. Figure 4.37: Get Connected Chapter 4...
  • Page 52: Figure 4.38:Run Repllog.exe On The Tpc

    Figure 4.39: Connection on the TPC 8. Once the TPC and the host PC are connected, a window will pop up as shown below on the host computer. Select “No” and then press “Next”. Figure 4.40: Connection on the Host PC TPC-1260G User Manual...
  • Page 53: Figure 4.41:Exploring The Tpc

    9. Select “Explore” in the Microsoft ActiveSync window, the window, Mobile Device, will pop up to display the file resources and information of TPC. For example, you could click the icon “My documents” to see the contents stored in TPC. Figure 4.41: Exploring the TPC 4.3 Application Program Development 4.3.1 System Requirements for Developers...
  • Page 54: Building Windows Ce .Net Runtime

    Install the TPC Software Development Kit for eMbedded Visual C++ from the support CD-ROM. Install Microsoft ActiveSync from the support CD-ROM. Build the connection between the host and TPC via ActiveSync. For further information about ActiveSync, please refer to section 5.2.2. Execute eMbedded Visual C++. TPC-1260G User Manual...
  • Page 55: Figure 4.42:Starting A New Project

    Select “File”->”New” to open a new project. Select your project type in the left side of the window and enter the new project name/ location in the right side of the window. Figure 4.42: Starting a New Project Note For the CPU type, Win32 (WCE X86) must be selected.
  • Page 56: Figure 4.43:Selecting

    Figure 4.43: Selecting After you complete the configuration procedure, you can start to develop your application. Press “Build” to compile your program to an .exe file and download it to TPC. Figure 4.44: Compiling your Program TPC-1260G User Manual...
  • Page 57 Serial Port Settings...
  • Page 58: Jumper Settings

    Appendix A Serial Port Settings The serial port COM5 on TPC-1260G is adjustable. It can be set to RS- 232, RS-422 or RS-485. This port is designed with auto data flow control capability. In other words, the TPC-1260G can automatically detect the data flow direction at this port when the two-wired RS-485 communica- tion is activated.
  • Page 59: Figure A.1:Device Manager

    Figure A.1: Device Manager Figure A.2: COM5 Properties Appendix A...
  • Page 60 TPC-1260G User Manual...
  • Page 61 Fuse Specifications...
  • Page 62: B.1 Fuse Specifications

    Step 2: Replace the damaged fuse with a new one Step 3: Replace the fuse cover Figure B.1: Fuse Replacement Warning Do NOT replace the fuse unless it is damaged. Do NOT replace the fuse with a different rated fuse. TPC-1260G User Manual...
  • Page 63 Watchdog Timer Programming...
  • Page 64: Appendix C Watchdog Timer Programming

    Appendix C Watchdog Timer Program- ming There is a built-in watchdog timer in Windows CE 4.2 for TPC-1260G. You can access it through the WIN32 API. TPC-1260G provides a WDT driver to allow users to enable/disable the watchdog timer. The driver name is “WDT1:”.
  • Page 65: Parameters

    C.1.1 Parameters • hDevice [in] Handle to the device that is to perform the operation. Call the Cre- ateFile function to obtain a device handle. • dwIoControlCode [in] Specifies the control code for the operation. This value identifies the specific operation to be performed and the type of device on which the operation is to be performed.
  • Page 66: How To Use The Control Code

    WDT driver, your application must trigger the watchdog once during the watchdog timer period. If your application has not triggered at the specified period, the device will reboot automatically. lpInBuffer: unused. nInBufferSize: unused. lpOutBuffer: unused. nOutBufferSize: unused. TPC-1260G User Manual...
  • Page 67: Ioctl_Wdt_Gettimeout

    C.2.4 IOCTL_WDT_GETTIMEOUT: Gets the Watchdog time setting. lpInBuffer: unused. nInBufferSize: unused. lpOutBuffer: The DWORD points to your watchdog time setting. The Watchdog time setting is just a number. 0 means 2 seconds, 1 means 5 seconds, 2 means 10 seconds, 3 means 15 seconds, 4 means 30 seconds, 5 means 45 seconds and 6 means 60 seconds.
  • Page 68: Examples

    // assign the WDT driver name wsprintf(szClassName, TEXT("WDT1:")); // Open the WDT driver m_hWDT = CreateFile(szClassName, GENERIC_READ GENERIC_WRITE, 0, NULL, OPEN_EXISTING, FILE_ATTRIBUTE_NORMAL, NULL); if ( m_hWDT == INVALID_HANDLE_VALUE ) { DebugMsg(CString("WDT driver fail")); return; DWORD dwTemp; DWORD nIndex=2; TPC-1260G User Manual...
  • Page 69 // Set the Watchdog Timer as 10 seconds. Number 2 means 10 seconds. DeviceIoControl(m_hWDT, IOCTL_WDT_SET_TIMEOUT, &nIndex, sizeof(nIndex), NULL, 0, &dwTemp, NULL); // Enable the Watchdog timer DeviceIoControl(m_hWDT, IOCTL_WDT_ENABLE, NULL, 0, NULL, 0, &dwTemp, NULL); While (1) { // do your job here. Sleep(8000);...
  • Page 70 TPC-1260G User Manual...
  • Page 71 Accessory Kit Assem- bly Procedure This appendix shows how to connect to a CD-ROM via the CompactFlash slot.:...
  • Page 72: Appendix D Accessory Kit Assembly Procedure

    Please follow this assembly procedure to use the CompactFlash slot to connect with a CD-ROM drive. Connect the IDE cable to the adapter board. Figure D.1: Adapter Board and IDE Cable Figure D.2: Connect the Adapter Board with the IDE Cable TPC-1260G User Manual...
  • Page 73: Figure D.3:Compactflash Slot

    Note Pin 1 is marked red Insert the adapter board into the CompactFlash slot. Figure D.3: CompactFlash Slot Figure D.4: Insert the Adapter Board into the CF slot Figure D.5: Inserted Adapter Board Appendix D...
  • Page 74: Figure D.6:Connect The Cd-Rom Via The Ide Cable

    Note Please make sure Windows 2000 Service Pack 4 is installed before you install the USB 2.0 driver on Windows 2000. Service Pack 1 must be installed on Windows XP before you install the USB 2.0 driver. TPC-1260G User Manual...
