1.2.3 Safety and Environment

Safety
• FCC Class A
• CE certificated
• The front bezel is compliant with NEMA 4 and IP65
Environment
• Operating Temperature: 0 ~ 50° C (32 ~ 122° F)
• Storage Temperature: -20 ~ 60° C (-4 ~ 140° F)
• Humidity: 40° C @ 10~95% relative humidity (non-condensing)
• Vibration:
X-Axis: 0.25 grms (5~500Hz)
Y-Axis: 0.5 grms (5~500Hz)
Z-Axis: 1 grms (5~500Hz)

1.3 LCD Specifications

• Display Type: TFT color LCD
• Size (diagonal): 12.1"
• Maximum Resolution: 800 x 600 (SVGA)
• Maximum Colors: 256,000
• Pixel Pitch (W x H, mm): 0.3075 x 0.3075
• Viewing Angle: 120°
• Luminance (cd/m² ): 350
• Contrast Ratio: 500
• Operating Temperature: 0 ~ 50° C (32 ~ 122° F) (Ambient)
• VR Control: Brightness Adjustable
• Backlight: 2 CCFL
• Backlight Life Time: 50,000 hours
Note
TPC-1260H User Manual
There might be several bright or dark pixels on
the LCD. This phenomenon is normal in today's
LCD manufacturing.
