POS-560-B1
®
All-in-one Single Board Pentium
Processor-based Computer with
SVGA, Ethernet, and SSD
User's Manual for POS-560-B1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POS-560-B1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech POS-560-B1

Summary of Contents for Advantech POS-560-B1

  • Page 1 POS-560-B1 ® All-in-one Single Board Pentium Processor-based Computer with SVGA, Ethernet, and SSD User's Manual for POS-560-B1...
  • Page 2 C&T is a trademark of Chips and Technologies, Inc. UMC is a trademark of United Microelectronics Corporation. All other product names or trademarks are properties of their respective owners. Part No. 2007056011 2nd Edition Printed in Taiwan August 1998 POS-560-B1 User's Manual...

  • Page 3: Packing List

    Packing List Before installing your board, make sure that the following materi- als have been received: • 1 POS-560-B1 All-in-one single board computer • 1 utility disk with system BIOS, VGA BIOS, and Ethernet utility programs • 1 utility disk with SVGA utility programs and drivers for Windows 3.1/95...

  • Page 4: Table Of Contents

    2.9 44-pin Secondary Mini-pitched IDE Interface (2.5" HDD or SSD) (JP10) ................. 19 2.10 Floppy Drive Connector (JP13) .........19 Connecting the floppy drive ............19 2.11 Primary Parallel Port Connector (LPT1: CN11) ....20 2.12 Secondary Parallel Port (LPT2: CON5) ......20 POS-560-B1 User's Manual...
  • Page 5 2.13 Keyboard Connector (CN1, CN5, CN6) ......20 Special connectors for keyboard and monitor ........21 2.14 PS/2 Mouse/Keyboard Connector (CN5) ......21 2.15 Front Panel Connectors ............. 22 Speaker ....................22 LED interface ..................22 Reset switch ..................22 2.16 Power Connector (J1) ............
  • Page 6 Auto detect hard disk ..............58 Save & exit setup ............... 58 Exit without saving ..............58 Chapter 5: PCI SVGA Setup ......59 5.1 Before You Begin ...............60 5.2 Installation ................60 5.3 Simultaneous Display Mode ..........61 POS-560-B1 User's Manual...
  • Page 7 5.4 Sleep Mode ................. 61 5.5 Driver Installation ............... 62 Necessary prerequisites ..............62 Before you begin .................. 62 5.5.1 Windows 3.1 drivers setup procedure ....... 62 Windows setup ................62 Changing display drivers in Windows ..........63 Changing color schemes ..............63 DOS setup ..................
  • Page 8 System I/O ports ................. 86 1st MB memory map ..............87 ® Appendix C: DOC 2000 Installation Guide ........89 ® C.1 DiskOnChip 2000 Quick Installation Guide ...... 90 ® DiskOnChip 2000 installation instructions ........ 90 Additional information and assistance ........91 POS-560-B1 User's Manual...
  • Page 9 Figure 1-1: POS-560-B1 board configuration ........6 Figure 2-1: POS-560-B1 jumpers and connectors ......10 Figure 2-2: POS-560-B1 digital output solenoid wiring example ..28 Figure 3-1: VGA setup screen ............... 40 Figure 4-1: Setup program initial screen ..........49 Figure 4-2: CMOS setup screen ............
  • Page 10 Table 2-24: Installing Flash/ROM disk as drive A (with 1 FDD) ....34 Table 2-25: Installing Flash/ROM disk as drive C ........34 Table 3-1: POS-560-B1 Connection for Sharp LM64P83 LCD (CN12) ..42 Table 3-2: POS-560-B1 Connection for Toshiba LTM10C042 LCD (CN12) 43 Table 3-3: POS-560-B1 Connection for Sharp LM64C142 LCD (CN12) ..
  • Page 11 Table B-16: Speaker (J2) ................79 Table B-17: IRQ mapping chart ..............79 Table B-18: Universal serial bus (USB) connector (JP18) ..... 80 Table B-19: PS/2 mouse / PS/2 keyboard connector (CN5) ....... 80 Table B-20: IR connector (CON6) ..............80 Table B-21: PCI/ISA slot pin assignments (Pins A and B) ......
  • Page 12 POS-560-B1 User's Manual...

  • Page 13: Chapter 1: General Information

    General Information This chapter gives background information on the POS-560-B1. Sections include: • Board specifications • Board layout and dimensions...

  • Page 14: Introduction

    LCD controller, VGA, solid state disk (SSD) and Ethernet simplify POS system integration. The POS-560-B1 uses a standardized layout based on Western Digital’s LPM/LPX format. It is 100% PC compatible and can be easily connected to any existing PC hardware and software.

  • Page 15: Specifications

    1.2 Specifications Standard SBC functions ® • Processor: Intel Pentium , P55C (MMX) AMD K5, K6 Cyrix 6x86 • BIOS: Award 128 KB Flash BIOS includes Ethernet boot ROM, SSD driver and VGA BIOS. Supports Plug and Play • System chipset: SiS 5571 •...

  • Page 16: Pci Svga/Flat Panel Interface

    • 512 KB SRAM/Flash/ROM, DOS and Windows 3.1 command compatible Digital I/O • Two high-drive digital output; MOS FET output to direct drive relay or solenoid up to 2 A/50 V • Four digital inputs; TTL compatible POS-560-B1 User's Manual...

  • Page 17: Mechanical And Environmental

    Mechanical and environmental • Max. power requirements: 7 A @ 5 V (4.75 to 5.25), 0.15 A @ ±12 V • Operating temperature: 0 to 60° C (32 to 140° F) • Size: 220 mm (L) x 235 mm (W) (8.7” x 9.25”) •...

  • Page 18: Board Layout And Dimensions

    C O M 2 C O M 3 C O M 4 C P U B I O S S S D WD/LPM/LPX Format Overall Size: 220 mm x 230 mm All units in mm Figure 1-1: POS-560-B1 board configuration POS-560-B1 User's Manual...

  • Page 19: Chapter 2: Installation

    Installation This chapter explains how to set up the POS-560-B1 hardware, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin the installation procedure.

  • Page 20: Jumpers And Connectors

    2.1 Jumpers and Connectors Connectors on the board link the POS-560-B1 to external devices such as hard disk drives, a keyboard or floppy drives. The board has a number of jumpers that allow you to configure your system to suit your application. The tables below list the function of each...

  • Page 21: Table 2-2: Pos-560-B1 Jumpers And Switches

    Table 2-2: POS-560-B1 jumpers and switches Label Function Speaker Power LED and keylock Reset switch SSD functions SSD functions Turbo switch Turbo LED HDD LED SSD functions SSD functions CMOS discharge JP11 COM4 RS-232/422/485 select JP12 COM4 RS-232/422/485 select JP14...

  • Page 22: Locating Jumpers And Connectors

    JP26 S W 1 J P 7 J P 6 JP34 JP22 BIOS JP32 JP31 JP14 KEYLOCK SPEAKER TB LED T B S W RESET LED 1 POWER LED HDD LED Figure 2-1: POS-560-B1 jumpers and connectors POS-560-B1 User's Manual...

  • Page 23: Safety Precautions

    2.4 Installing the CPU The POS-560-B1 all-in-one CPU module supports most 586 CPUs. The system's performance depends upon the installed CPU. You can install or upgrade the CPU in the board's ZIF socket by following the procedures outlined below.

  • Page 24: Installing A Cpu

    When you install a new CPU, you may have to adjust other settings on the board, including CPU type, CPU clock, and PCI speed. Make sure that the settings are correct for your CPU. Improper settings may damage the CPU. POS-560-B1 User's Manual...

  • Page 25: Setting Jumpers

    2.5 Setting Jumpers You configure your board to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 26: Cpu Setup

    Open Closed Open Closed Open Closed Closed Closed Open Closed Open Open Closed Closed 3.3* Closed Open Closed Closed Open Closed Closed Closed Closed Closed Closed Closed default setting Table 2-3: CPU core voltage supply select (JP31) POS-560-B1 User's Manual...

  • Page 27: P55C / P54C Selection (Jp34)

    P55C / P54C selection (JP34) Table 2-4: P55C / P54C selection (JP34) P55C closed closed P54C* open open default setting CPU clock speed select (JP19, JP14, JP22) To ensure the proper clock speed setting for your CPU (either AMD, Intel or Cyrix), follow these instructions very carefully: CPU speed = CPU clock speed x frequency ratio Example: (133, 150, 200 MHz) = (50, 60, 66, 75 MHz) x (1.5, 2, 3.3, 3.5, etc.)

  • Page 28: Clock Speed Setup Procedure

    Finally, set the SiS 5571 DLL optimizing timing adjust (JP22) based on your CPU's bus clock speed setting in Step c. POS-560-B1 User's Manual...

  • Page 29: Cmos Discharge Jumper (Jp9)

    You can install up to 64 MB of SIMM DRAM on each socket for a total of 128 MB DRAM with two sockets filled. The POS-560-B1 can also support single SIMM operation. However, DRAM size and type must match when installing two SIMMs in each socket.

  • Page 30: Dimm Dram (Dimm 1)

    DIMM DRAM (DIMM 1) You can also install one 168-pin DIMM (up to 32 MB DRAM) in the DIMM socket. The POS-560-B1 can operate with only DIMM DRAM installed. Note that the POS-560-B1 cannot support SDRAM-type DIMM modules with the CPU clock speed running at 75 MHz.

  • Page 31: Connecting The Hard Drive

    2.10 Floppy Drive Connector (JP13) You can attach up to two floppy disks to the POS-560-B1's on-board controller. You can use any combination of 5¼" (360 KB and 1.2 MB) and/or 3½" (720 KB, 1.44 MB, and 2.88 MB) drives.

  • Page 32: Primary Parallel Port Connector (Lpt1: Cn11)

    IRQ11. You can select the LPT1 SPP/EPP/ECP selection and enable/disable from BIOS (see Chapter 4). 2.13 Keyboard Connector (CN1, CN5, CN6) The POS-560-B1 is uniquely designed to allow several ways for keyboard input: 1) External mini-DIN jack (CN1) 2) External mini-DIN...

  • Page 33: Special Connectors For Keyboard And Monitor

    Note than only one input source can be used at a given time. They cannot be used simultaneously. Choices 3, 4 and 5 are provided for the convenience of the system designer using POS-560-B1. For example, choice 2 would be good for an All-in-one system...

  • Page 34: Front Panel Connectors

    HDD active LED LED2 Ethernet LED The POS-560-B1 can drive an 8 Ω speaker at 0.5 watts. Ensure that alternatives to this specification do not overload the board. The front panel LED indicator for hard disk access is an active low signal (24 mA sink rate).

  • Page 35: Cpu Fan Power Connector (Cn3)

    +5 V/ +12 V/ GND pins. See Appendix B for pin assignments. 2.18 Serial Ports (COM1 - 4) The POS-560-B1 has a total of four on-board RS-232 serial ports, COM1 - 4. They are differentiated by COM1 and COM2 as primary serial ports and COM4 (RS-232/422/485) and COM3 as secondary ports.

  • Page 36: Serial Ports (Com1 - 4) +5 V And +12 V Power Selection (Jp24/25/26/27)

    RS-232 serial ports (COM1 - 4) +5 V and +12 V power selection (JP24/25/26/27) All COM ports on the POS-560-B1 have +5 V or +12 V capability on Pin 1 and Pin 9, depending on where you set the jumpers. You can also select no power on all COM ports if you do not set any jumpers.

  • Page 37: Com4 Rs-232/422/485 Selection (Jp11 And Jp12)

    10-11 10-11 2.20 VGA Interface Connections The POS-560-B1's SVGA interface can drive conventional CRT displays and is capable of driving a wide range of flat panel displays, including electroluminescent (EL), gas plasma, passive LCD and active LCD displays. The board has two connectors to support these displays, one for standard CRT VGA monitors and one for flat panel displays.

  • Page 38: Crt Display Connector (Cn13 And Cn14)

    (For more information on LCD connection information between CN13 and LCD, refer to Chapter 3). Flat panel display 3.3 V/5 V selection The POS-560-B1 is jumper selectable to support either 3.3 V or 5 V LCD to the V voltage line.

  • Page 39: Digital I/O (Cn2: 2 Outputs, 4 Inputs)

    2.21 Digital I/O (CN2: 2 Outputs, 4 Inputs) The POS-560-B1 has two high drive digital outputs (50 V , 2 A max) and four digital inputs (TTL level). You can configure the digital I/O to control the opening of the cash drawer and to sense the closing of the cash drawer.

  • Page 40: Digital Output Solenoid Wiring Examples

    Digital output solenoid wiring examples: The POS-560-B1's CN2 digital I/O connector contains a power pin for +5 and +12 V. +5 V is on pin 2 and +12 V is on pin 10. Example: V c c +12V (Pin #10)

  • Page 41: Digital Input Programming

    Note: The INPUT signal must be TTL compatible. 2.23 Ethernet Configuration The POS-560-B1 is equipped with a high performance 16-bit Ethernet interface which is fully compliant with IEEE 802.3 10Mbps CSMA/CD standards. It is supported by all major network operating systems and is 100% Novell NE-2000 compatible.

  • Page 42: 10Base-T Connector (Ut1)

    I/O devices. 10BASE-T connector (UT1) 10BASE-T connects to the POS-560-B1 via an adapter cable to the RJ-45 standard jack (UT1) located at the rear of the board. Network boot The Network Boot feature is built into the BIOS.

  • Page 43: Memory Devices

    Memory devices The Flash/ROM disk supports the following memory devices, DiskOnChip 2000 series, or their equivalents: • 27C010 128 Kb x 8 EPROM • 27C040 512 Kb x 8 EPROM • 29C010 128 Kb x 8 +5 V Flash Memory (ATMEL only) •...

  • Page 44: Drive Configuration For Flash/Sram/Eprom

    The SSD occupies a window in the memory address range of D000: 0000-1FFF. Positions 3 and 4 on SW1 enable/disable the Flash/ROM disk’s memory address. If you select “Disabled”, the disk will not function. Table 2-21: Memory address selection Position 3 Position 4 SSD Function Disabled Enabled POS-560-B1 User's Manual...

  • Page 45: Drive Emulated (Sw1)

    Positions 5 and 6 of SW1 control the DOS drive emulated by the Flash/ROM disk: 1st, 2nd, 3rd or 4th. Table 2-22: Drive emulation Position 5 Position 6 Drive The actual drive letter assigned by DOS to the Flash/ROM disk depends on the floppy or hard disks installed in the system.

  • Page 46: Example 1

    Inserting memory devices After you have set all the jumpers and switches on the POS-560-B1, insert the appropriate memory devices into the card’s sockets. Remember that you will need to program EPROMs before you insert them. POS-560-B1 User's Manual...

  • Page 47: Formatting The Solid State Disk

    1. Make sure that the pins of the memory chips are perpendicular to the case and both rows are parallel to each other. Many times the chips come with the pins spread out slightly. Place the chip on a table top and carefully bend each line of pins together until they point directly down.

  • Page 48: Diskonchip Configuration

    Note: Due to limitations in the POS-560-B1 system chipset, the POS-560-B1 USB interface cannot be used with a USB keyboard under a DOS environment, since the system will hang. When the same USB peripheral is used under a Windows 95 (OSR2) or a Windows NT environment, the system works fine.

  • Page 49: Chapter 3: Software Configuration

    Software Configuration This chapter details the software configu- ration information. It shows you how to configure the card to match your applica- tion requirements. AWARD System BIOS is covered in Chapter 4. Sections include: • VGA display software configuration • Connections for three standard LCDs •...

  • Page 50: Introduction

    3.1 Introduction The POS-560-B1 system BIOS and custom drivers are located in a 128 KB, 32-pin (JEDEC spec.) Flash ROM device, designated U15. A single Flash chip holds the system BIOS, VGA BIOS, and network Boot ROM image. The display can be configured via software.
  • Page 51 560_STN.BIN Supports 640 x 480 color STN DD 8/16-bit displays (Sharp LM64C142). 560_MON.BIN Supports 640 x 480 dual scan monochrome displays (Sharp LM64P83/64P89). CBROM.EXE This program allows you to combine your own VGA BIOS with system BIOS (560_SYS.BIN). DIAG9008.EXE This program is the UMC 9008 Ethernet controller auto-scan/ setup/diagnostic function.

  • Page 52: Vga Display Software Configuration

    Configure the VGA display as follows: 1. Apply power to the POS-560-B1 with a color TFT display attached. This is the default setting for the POS-560-B1. Ensure that the AWDFLASH.EXE and *.BIN files are located in the working drive.
  • Page 53 3. At the prompt, enter the new BIN file which supports your display. When you are sure that you have entered the file name correctly press <Enter>. 4. The screen will ask “Do you want to save BIOS?” If you change your mind or have made a mistake, press N to abort and end the setup procedure.

  • Page 54: Connections For Three Standard Lcds

    3.4 Connections for Three Standard LCDs Connections to Sharp LM64183P (640 x 480 DSTN MONO LCD) Table 3-1: POS-560-B1 Connection for Sharp LM64P83 LCD (CN12) Pin name Pin name CN1-1 CN1-2 CN1-3 SHFCLK CN1-4 DISP +5 V CN1-5 +5 V...

  • Page 55: Connections To Toshiba Ltm10C042 (640 X 480 Tft Color Lcd)

    Connections to Toshiba LTM10C042 (640 x 480 TFT Color LCD) Table 3-2: POS-560-B1 Connection for Toshiba LTM10C042 LCD (CN12) Pin name Pin name SHFCLK ENAB +5 V +5 V Chapter 3 Software Configuration...

  • Page 56: Connections To Sharp Lm64C142 (640 X 480 Dstn Color Lcd)

    Connections to Sharp LM64C142 (640 x 480 DSTN Color LCD) Table 3-3: POS-560-B1 Connection for Sharp LM64C142 LCD (CN12) Pin name Pin name CN1-1 CN1-2 CN1-3 SHFCLK CN1-4 DISP +5 V CN1-5 +5 V CN1-6 CN1-7 +27 V (external power)

  • Page 57: Ethernet Software Configuration

    Award BIOS Setup. To configure the medium type, to view the current configuration, or to run diagnostics, do the following: 1. Power the POS-560-B1 on. Ensure that the DIAG9008.EXE file is located in the working drive. 2. At the prompt type DIAG9008.EXE and press <Enter>. The Ethernet configuration program will then be displayed.
  • Page 58 POS-560-B1 User's Manual...

  • Page 59: Chapter 4: Award Bios Setup

    Award BIOS Setup This chapter describes how to set BIOS configuration data.

  • Page 60: System Test And Initialization

    3. The CMOS memory has lost power and the configuration information has been erased. The POS-560-B1’s CMOS memory has an integral lithium battery backup. The battery backup should last ten years in normal service, but when it finally runs down, you will need to replace the complete unit.

  • Page 61: Award Bios Setup

    4.2 AWARD BIOS Setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. Entering setup Power on the computer and press <Del>...

  • Page 62: Standard Cmos Setup

    Drive A : 1.44M,3.5 in. Base Memory Drive B : None Extended Memory Video: EGA/VGA Other Memory : 512K Halt On:All,But Keyboard Total Memory : 512K ESC: Quit :Select Item PU/PD/+/-:Modify F1:Help (Shift)F2:Change Color Figure 4-2: CMOS setup screen POS-560-B1 User's Manual...

  • Page 63: Bios Features Setup

    INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the POS-560-B1. MS-DOS R O M P C I / I S A B I O S ( 2 A 5IHAKA ) B I O S F E A T U R E S S E T U P A W A R D S O F T W A R E , I N C .

  • Page 64: Chipset Features Setup

    (Shift)F2 : Color SDRAM CAS Latency : 3T F6 : Load BIOS Defaults CPU to PCI Burst Mem. WR : Disabled ISA Bus Clock Frequency : PC1CLK/4 F7 : Load Setup Defaults Figure 4-4: CHIPSET features setup screen POS-560-B1 User's Manual...

  • Page 65: Power Management Setup

    INITIAL SETUP SCREEN menu, the screen below is dis- played. This sample screen contains the manufacturer’s default values for the POS-560-B1. MS-DOS R O M P C I / I S A B I O S ( 2 A 5 I H A K A ) P O W E R M A N A G E M E N T S E T U P A W A R D S O F T W A R E , I N C .

  • Page 66: Pnp/Pci Configuration Setup

    A W A R D S O F T W A R E , I N C . Esc:Quit : Select Item F1 : Help PU/PD/+/-: Modify F5 : Old Values (Shift)F2 : Color F6 : Load BIOS Defaults F7 : Load Setup Defaults Figure 4-6: PCI configuration setup screen POS-560-B1 User's Manual...

  • Page 67: Integrated Peripherals

    INITIAL SETUP SCREEN menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the POS-560-B1. MS-DOS R O M P C I / I S A B I O S ( 2 A 5 IHAKA ) I N T E G R A T E D P E R I P H E R A L S A W A R D S O F T W A R E , I N C .

  • Page 68: Load Bios Defaults

    (and therefore unusable), these defaults will load automatically when you turn the POS-560-B1 on. R O M P C I / I S A B I O S ( 2 A 5 I H A K A ) C M O S S E T U P U T I L I T Y A W A R D S O F T W A R E , I N C .

  • Page 69: Change Password

    Change password To change the password, choose the PASSWORD SETTING option form the Setup main menu and press <Enter>. 1. If the CMOS is bad or this option has never been used, there is default password which is stored in the ROM. The screen will display the following messages: Enter Password: Press <Enter>.

  • Page 70: Auto Detect Hard Disk

    This record is required for the system to operate. Exit without saving Selecting this option and pressing <Enter> lets you exit the Setup program without recording any new values or changing old ones. POS-560-B1 User's Manual...

  • Page 71: Chapter 5: Pci Svga Setup

    PCI SVGA Setup The POS-560-B1 features an on-board PCI flat panel/VGA interface. This chapter provides instructions for installing and operating the software drivers on the included display driver diskette.

  • Page 72: Before You Begin

    The enhanced display drivers for the POS-560-B1 board are located on the software installation diskette. You must install the drivers and utility software by using the supplied SETUP program for DOS drivers.

  • Page 73: Simultaneous Display Mode

    Both CRT and panel displays can be used simultaneously. The POS-560-B1 can be set in one of three configurations: on a CRT, on a flat panel display, or on both simultaneously. The system is initially set to simultaneous display mode.

  • Page 74: Driver Installation

    Run ..At the command line prompt, type A:\WINSETUP. Press the <ENTER> key or click OK to begin the installation. At this point the setup program locates the directory where Windows is installed. For proper POS-560-B1 User's Manual...

  • Page 75: Changing Display Drivers In Windows

    operation, the drivers must be installed in the Windows subdirec- tory. Press <ENTER> to complete the installation. Once complet- ed, the Display Driver Control Panel appears on the screen. This Control Panel allows you to select and load the installed drivers. Another method of installing these drivers is through the File Manager.

  • Page 76: Dos Setup

    Setup, repeating steps 4 and 5 from the previous page. Besides the special display drivers marked by an asterisk (*), you should be able to use the following standard drivers: 640x480, 16 colors Super VGA 800x600, 16 colors POS-560-B1 User's Manual...

  • Page 77: Panning Drivers

    Special panning drivers are provided to allow high-resolution modes to be displayed on a flat panel or CRT. These drivers will show a section of a larger screen and will automatically pan, or scroll, the screen horizontally and vertically when the mouse reaches the edge of the display.

  • Page 78: Windows Nt Drivers Setup Procedure

    2. Click on Test to test the newly selected graphics mode. A color test screen should appear, followed by the Testing Mode window. 3. Click on Yes to continue. The Display Settings Change window will appear. 4. Click on Restart Now for the new settings to take effect. POS-560-B1 User's Manual...

  • Page 79: Appendix A: Programming The Watchdog Timer

    Programming the Watchdog Timer The POS-560-B1 is equipped with a watchdog timer that resets the CPU if processing comes to a standstill for whatever reason. This feature ensures system reliability in industrial standalone or unmanned environments.
  • Page 80 GOSUB 2000 REM Task #2, takes 1.6 second to complete X=out (&H6D0) REM Disable the watchdog 1000 Subroutine #1, takes less than 1.6 second to complete 1990 RETURN 2000 Subroutine #2, takes 1.6 second to complete 2940 RETURN POS-560-B1 User's Manual...

  • Page 81: Appendix B: Pin Assignments

    Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • Flat panel display connector (CN12) • VGA internal connector (CN14) • VGA external connector (CN13) • Ethernet AUI-BNC connector (CN16) • Primary IDE 40-pin connector (CON2) •...

  • Page 82: Flat Panel Display Connector (Cn12)

    (3.3 V/5 V) ENAVEE SHFCLK M/DE ENABKL DB Data KB CLK KB GND KB V VGA internal connector (CN14) Table B-2: Internal VGA connector (CN14) Signal Signal KB Data GREEN KB Clk BLUE VGND HSYNC VSYNC VGND POS-560-B1 User's Manual...

  • Page 83: Vga External Connector (Cn13)

    VGA external connector (CN13) Table B-3: External VGA connector (CN13) Signal GREEN BLUE VGND VGND VGND VGND VGND VGND VGND Appendix B Pin Assignments...

  • Page 84: Ethernet Aui-Bnc Connector (Cn16)

    DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 SIGNAL GND IO WRITE IO READ IO CHANNEL READY BALE IRQ14 IOCS16 ADDR 1 ADDR 0 ADDR 2 HARD DISK SELECT 0 HARD DISK SELECT 1 IDE ACTIVE POS-560-B1 User's Manual...

  • Page 85: Secondary Ide 44-Pin Connector (Jp10)

    Secondary IDE 44-pin connector (JP10) Table B-6: Secondary IDE 44-pin connector (JP10) Signal Signal IDE RESET* DATA7 DATA8 DATA6 DATA9 DATA5 DATA10 DATA4 DATA11 DATA3 DATA12 DATA2 DATA13 DATA1 DATA14 DATA0 DATA15 SIGNAL GND HDD 0 IO WRITE IO READ HD READY HDACK 0* IRQ14...

  • Page 86: Connections (Com1: Cn9/Cn10, Com2: Cn7/Cn8, Com3: Com3, Com4: Com4)

    Note: Pin 10 on every internal COM1 - 4 is NC 2 4 6 8 10 1 3 5 7 COM1 - 2 Internal COM1 - 4 Keyboard connectors (CN6, CN1) Table B-8: Internal keyboard connectors (CN6) Function K/B clock K/B data +5 V POS-560-B1 User's Manual...

  • Page 87: Floppy Drive Connector (Jp13)

    Table B-9: External keyboard connectors (6-pin mini-DIN) (CN1) Function K/B data (XKBDAT1) MDATC1 +5 V K/B clock (XKBCLK1) MCLKC1 Floppy drive connector (JP13) Table B-10: Floppy drive connector (JP13) Signal Signal DENSITY SELECT DRIVE TYPE INDEX MOTOR 0 DRIVE SELECT 1 DRIVE SELECT 2 MOTOR 1 DIRECTION...

  • Page 88: Parallel Port Connector (Cn11: Lpt1, Con5: Lpt2)

    Parallel port connector (CN11: LPT1, CON5: LPT2) Table B-11: Parallel port connector (CN11: LPT1, CON5: LPT2) Signal \STROBE \ACK BUSY SLCT AUTOFD INIT SLIN LPT1 LPT2 POS-560-B1 User's Manual...

  • Page 89: Digital Input/Output (Cn2)

    Digital input/output (CN2) Table B-12: Digital input/output (CN2) Signal I/O IN 0 I/O IN 1 I/O OUT 0 I/O IN 2 I/O IN 3 I/O OUT 1 +12 V/special power CPU fan connector (CN3) Table B-13: CPU fan connector (CN3) Function 12 V Appendix B Pin Assignments...

  • Page 90: Main Power Connector (J1)

    Main power connector (J1) Table B-14: Main power connector (J1) Signal Special power input for pin 10 of CN2 +12 V -12 V -5 V Power LED and keylock (J3) Table B-15: Power LED & keylock (J3) Signal Keylock POS-560-B1 User's Manual...

  • Page 91: Speaker (J2)

    Speaker (J2) Table B-16: Speaker (J2) Signal Speaker IRQ mapping chart Table B-17: IRQ mapping chart Function Interval timer Keyboard Interrupt from Controller 2 COM2 COM1 Ethernet LPT1 COM4 COM3 LPT2 PS/2 mouse INT from co-processor Primary IDE Secondary IDE Appendix B Pin Assignments...

  • Page 92: Universal Serial Bus (Usb) Connector (Jp18)

    Table B-19: PS/2 mouse / PS/2 keyboard connector (CN5) PS/2 mouse connector (CN5) PS/2 keyboard connector (CN5) Function Function Mouse data MDATC2 MDATC(MDATC1) Mouse clock MCLKC2 MCLKC(MCLKC1) IR connector (CON6) Table B-20: IR connector (CON6) Function IRTX IRRX POS-560-B1 User's Manual...

  • Page 93: Pci/Isa Slot (Component Side View)

    PCI/ISA slot (component side view) Appendix B Pin Assignments...

  • Page 94: Table B-21: Pci/Isa Slot Pin Assignments (Pins A And B)

    Table B-21: PCI/ISA slot pin assignments (Pins A and B) Signal Signal IOCHK IRQ9 -5 V DRQ2 -12 V +12 V IORDY SA19 SA18 SA17 SA16 DACK3 SA15 DRQ3 SA14 DACK1 SA13 DRQ1 SA12 SA11 SCLK SA10 IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 DACK2 POS-560-B1 User's Manual...

  • Page 95: Table B-22: Pci/Isa Slot Pin Assignments (Pins C And D)

    Table B-22: PCI/ISA slot pin assignments (Pins C and D) Signal Signal SBHE MEM16 LA23 IO16 LA22 IRQ10 LA21 IRQ11 LA20 IRQ12 LA19 IRQ15 LA18 IRQ14 LA17 DACKO MEMR DRQ0 MEMW DACK5 DRQ5 DACK6 SD10 DRQ6 SD11 DACK7 SD12 DRQ7 SD13 SD14 MASTER...

  • Page 96: Table B-23: Pci/Isa Slot Pin Assignments (Pins E And F)

    INT 1 INT3 INT 2 INT4 PCLKF GNTO REQ0 GNT1 PCLKE REQ1 AD31 AD30 AD29 AD28 AD27 AD26 AD25 AD24 CBE3 AD22 AD23 AD20 AD21 AD18 AD19 IDSEL1 AD16 AD17 FRAME IRDY CBE2 DEVSEL TRDY LOCK STOP PERR POS-560-B1 User's Manual...

  • Page 97: Table B-24: Pci/Isa Slot Pin Assignments (Pins G And H)

    Table B-24: PCI/ISA slot pin assignments (Pins G and H) Signal Signal SDONE SERR AD15 CBE1 AD14 AD12 AD13 AD10 AD11 CBEO Appendix B Pin Assignments...

  • Page 98: System I/O Ports

    Bisynchronous 1 (not used) 3B0-3BF Monochrome display and printer adapter (LPT1) (not used) 3C0-3CF Reserved 3D0-3DF Color/graphics monitor adapter Serial port 3 3F0-3F7 Diskette controller 3F8-3FF Serial port 1 * MPU-401 select from 300 ~ 330H (2 bytes) POS-560-B1 User's Manual...

  • Page 99: 1St Mb Memory Map

    1st MB memory map Table B-26: 1st MB memory map Addr. range (Hex) Device F000h-FFFFh System ROM C800h-EFFFh Unused C000h-C7FFh Expansion ROM B800h-BFFFh CGA/EGA/VGA text B000h-B7FFh Unused A000h-AFFFh EGA/VGA graphics 0000h-9FFFh Base memory ® D000-D400H* 2000/SSD * default setting Appendix B Pin Assignments...
  • Page 100 POS-560-B1 User's Manual...

  • Page 101: Appendix C: Doc

    ® 2000 Installation Guide This appendix contains information on ® the DiskOnChip 2000 quick installation guide. It includes: ® • DiskOnChip 2000 installation instructions • Additional information and assistance...

  • Page 102: Diskonchip ® 2000 Quick Installation Guide

    (c:) using the DUPDATE utility. (set as c:) DUPDATE D /S: DOC104.EXB /FIRST (set as d:) DUPDATE C /S: DOC104.EXB POS-560-B1 User's Manual...

  • Page 103: Additional Information And Assistance

    Additional information and assistance 1. Visit M-Systems' Web site at www.m-sys.com where you can find Utilities Manual, Data Sheet and Application Notes. In ® addition, you can find the latest DiskOnChip 2000 S/W Utilities. 2. Contact your dealer for technical support if you need additional assistance, and have the following information ready: •...
  • Page 104 POS-560-B1 User's Manual...

Table of Contents
