Service Provider WiFi: Support for Integrated Ethernet Over GRE

How to Configure the EoGRE Feature

SUMMARY STEPS
1. enable
2. configure terminal
3. interface interface-name
4. ip unnumbered loopback interface-name or ip address ip-address
5. tunnel source interface-type interface-number
6. (For simple IP mode) mac-address H.H.H
7. tunnel mode ethernet gre ipv4 or tunnel mode ethernet gre ipv6
8. (Optional) tunnel vlan vlan-id
9. end
DETAILED STEPS
Command or Action
Step 1
enable
Example:
Router> enable
Step 2 configure terminal
Example:
Router# configure terminal
Step 3 interface interface-name
Example:
Router(config)# interface Tunnel 0
Step 4 ip unnumbered loopback interface-name or ip
address ip-address
Example:
Router(config-if)# ip unnumbered loopback 0
or
Router(config-if)# ip address 20.1.1.2
255.255.255.0
OL-30226-03
How to Configure the EoGRE Feature
Purpose
Enables the privileged EXEC mode.
Enter your password, if prompted.
Enters the global configuration mode.
Specifies the logical interface for the EoGRE tunnel.
For PMIPv6 and GTP scenarios, an unnumbered address or
a specified IP address can be configured on the tunnel
interface.
For a simple IP scenario, only a specified IP address can be
configured on the tunnel interface. This IP address can be used
as a default gateway IP address.
