Overview of the Intelligent Wireless Access Gateway
DETAILED STEPS
Command or Action
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3 class-map type traffic match-any class-map-name
Example:
Router(config)# class-map type traffic match-any
TC_OPENGARDEN
Step 4 match access-group output {access-group | name
access-group-name}
Example:
Router(config-traffic-classmap)# match access-group
output name ACL_OUT_OPENGARDEN
Step 5
match access-group input {access-group | name
access-group-name}
Example:
Router(config-traffic-classmap)# match access-group input
name ACL_IN_OPENGARDEN
Step 6 policy-map type service policy-map-name
Example:
Router(config)# policy-map type service
OPENGARDEN_SERVICE
Step 7 [ priority ] class type traffic {class-map-name | default {in-out |
input | output } }
Example:
Router(config-service-policymap)# 20 class type traffic
TC_OPENGARDEN
Step 8 accounting aaa list aaa-method-list
Example:
Router(config-service-policymap)# accounting aaa list
PROXY_TO_CAR
OL-30226-03
Configuring the iWAG for 3G Mobile IP Users
Purpose
Enables the privileged EXEC mode.
Enter your password, if prompted.
Enters the global configuration mode.
Creates or modifies a traffic class map that is used
for matching packets to a specified Cisco ISG
traffic class.
Configures the match criteria for a Cisco ISG
traffic class map on the basis of the specified
access control list (ACL).
Configures the match criteria for a Cisco ISG
traffic class map on the basis of the specified ACL.
Creates or modifies a service policy map that is
used to define a Cisco ISG subscriber service.
Creates or modifies a traffic class map that is used
for matching packets to a specified Cisco ISG
traffic class.
Enables Cisco ISG accounting and specifies an
AAA method list to which accounting updates are
forwarded.
